# Deep Learning from first principles in Python, R and Octave – Part 3

“Once upon a time, I, Chuang Tzu, dreamt I was a butterfly, fluttering hither and thither, to all intents and purposes a butterfly. I was conscious only of following my fancies as a butterfly, and was unconscious of my individuality as a man. Suddenly, I awoke, and there I lay, myself again. Now I do not know whether I was then a man dreaming I was a butterfly, or whether I am now a butterfly dreaming that I am a man.”
from The Brain: The Story of you – David Eagleman

“Thought is a great big vector of neural activity”
Prof Geoffrey Hinton

# Introduction

This is the third part in my series on Deep Learning from first principles in Python, R and Octave. In the first part Deep Learning from first principles in Python, R and Octave-Part 1, I implemented logistic regression as a 2 layer neural network. The 2nd part Deep Learning from first principles in Python, R and Octave-Part 2, dealt with the implementation of 3 layer Neural Networks with 1 hidden layer to perform classification tasks, where the 2 classes cannot be separated by a linear boundary. In this third part, I implement a multi-layer, Deep Learning (DL) network of arbitrary depth (any number of hidden layers) and arbitrary height (any number of activation units in each hidden layer). The implementations of these Deep Learning networks, in all the 3 parts, are based on vectorized versions in Python, R and Octave. The implementation in the 3rd part is for a L-layer Deep Netwwork, but without any regularization, early stopping, momentum or learning rate adaptation techniques. However even the barebones multi-layer DL, is a handful and has enough hyperparameters to fine-tune and adjust.

Checkout my book ‘Deep Learning from first principles: Second Edition – In vectorized Python, R and Octave’. My book starts with the implementation of a simple 2-layer Neural Network and works its way to a generic L-Layer Deep Learning Network, with all the bells and whistles. The derivations have been discussed in detail. The code has been extensively commented and included in its entirety in the Appendix sections. My book is available on Amazon as paperback ($18.99) and in kindle version($9.99/Rs449).

The implementation of the vectorized L-layer Deep Learning network in Python, R and Octave were both exhausting, and exacting!! Keeping track of the indices, layer number and matrix dimensions required quite bit of focus. While the implementation was demanding, it was also very exciting to get the code to work. The trick was to be able to shift gears between the slight quirkiness between the languages. Here are some of challenges I faced.

1. Python and Octave allow multiple return values to be unpacked in a single statement. With R, unpacking multiple return values from a list, requires the list returned, to be unpacked separately. I did see that there is a package gsubfn, which does this.  I hope this feature becomes a base R feature.
2. Python and R allow dissimilar elements to be saved and returned from functions using dictionaries or lists respectively. However there is no real equivalent in Octave. The closest I got to this functionality in Octave, was the ‘cell array’. But the cell array can be accessed only by the index, and not with the key as in a Python dictionary or R list. This makes things just a bit more difficult in Octave.
3. Python and Octave include implicit broadcasting. In R, broadcasting is not implicit, but R has a nifty function, the sweep(), with which we can broadcast either by columns or by rows
4. The closest equivalent of Python’s dictionary, or R’s list, in Octave is the cell array. However I had to manage separate cell arrays for weights and biases and during gradient descent and separate gradients dW and dB
5. In Python the rank-1 numpy arrays can be annoying at times. This issue is not present in R and Octave.

Though the number of lines of code for Deep Learning functions in Python, R and Octave are about ~350 apiece, they have been some of the most difficult code I have implemented. The current vectorized implementation supports the relu, sigmoid and tanh activation functions as of now. I will be adding other activation functions like the ‘leaky relu’, ‘softmax’ and others, to the implementation in the weeks to come.

While testing with different hyper-parameters namely i) the number of hidden layers, ii) the number of activation units in each layer, iii) the activation function and iv) the number iterations, I found the L-layer Deep Learning Network to be very sensitive to these hyper-parameters. It is not easy to tune the parameters. Adding more hidden layers, or more units per layer, does not help and mostly results in gradient descent getting stuck in some local minima. It does take a fair amount of trial and error and very close observation on how the DL network performs for logical changes. We then can zero in on the most the optimal solution. Feel free to download/fork my code from Github DeepLearning-Part 3 and play around with the hyper-parameters for your own problems.

#### Derivation of a Multi Layer Deep Learning Network

Note: A detailed discussion of the derivation below is available in my video presentation Neural Network 4
Lets take a simple 3 layer Neural network with 3 hidden layers and an output layer

In the forward propagation cycle the equations are

$Z_{1} = W_{1}A_{0} +b_{1}$  and  $A_{1} = g(Z_{1})$
$Z_{2} = W_{2}A_{1} +b_{2}$  and  $A_{2} = g(Z_{2})$
$Z_{3} = W_{3}A_{2} +b_{3}$  and $A_{3} = g(Z_{3})$

The loss function is given by
$L = -(ylogA3 + (1-y)log(1-A3))$
and $dL/dA3 = -(Y/A_{3} + (1-Y)/(1-A_{3}))$

For a binary classification the output activation function is the sigmoid function given by
$A_{3} = 1/(1+ e^{-Z3})$. It can be shown that
$dA_{3}/dZ_{3} = A_{3}(1-A_3)$ see equation 2 in Part 1

$\partial L/\partial Z_{3} = \partial L/\partial A_{3}* \partial A_{3}/\partial Z_{3} = A3-Y$ see equation (f) in  Part 1
and since
$\partial L/\partial A_{2} = \partial L/\partial Z_{3} * \partial Z_{3}/\partial A_{2} = (A_{3} -Y) * W_{3}$ because $\partial Z_{3}/\partial A_{2} = W_{3}$ -(1a)
and $\partial L/\partial Z_{2} =\partial L/\partial A_{2} * \partial A_{2}/\partial Z_{2} = (A_{3} -Y) * W_{3} *g'(Z_{2})$ -(1b)
$\partial L/\partial W_{2} = \partial L/\partial Z_{2} * A_{1}$ -(1c)
since $\partial Z_{2}/\partial W_{2} = A_{1}$
and
$\partial L/\partial b_{2} = \partial L/\partial Z_{2}$ -(1d)
because
$\partial Z_{2}/\partial b_{2} =1$

Also

$\partial L/\partial A_{1} =\partial L/\partial Z_{2} * \partial Z_{2}/\partial A_{1} = \partial L/\partial Z_{2} * W_{2}$     – (2a)
$\partial L/\partial Z_{1} =\partial L/\partial A_{1} * \partial A_{1}/\partial Z_{1} = \partial L/\partial A_{1} * W_{2} *g'(Z_{1})$          – (2b)
$\partial L/\partial W_{1} = \partial L/\partial Z_{1} * A_{0}$ – (2c)
$\partial L/\partial b_{1} = \partial L/\partial Z_{1}$ – (2d)

Inspecting the above equations (1a – 1d & 2a-2d), our ‘Uber deep, bottomless’ brain  can easily discern the pattern in these equations. The equation for any layer ‘l’ is of the form
$Z_{l} = W_{l}A_{l-1} +b_{l}$     and  $A_{l} = g(Z_{l})$
The equation for the backward propagation have the general form
$\partial L/\partial A_{l} = \partial L/\partial Z_{l+1} * W^{l+1}$
$\partial L/\partial Z_{l}=\partial L/\partial A_{l} *g'(Z_{l})$
$\partial L/\partial W_{l} =\partial L/\partial Z_{l} *A^{l-1}$
$\partial L/\partial b_{l} =\partial L/\partial Z_{l}$

Some other important results The derivatives of the activation functions in the implemented Deep Learning network
g(z) = sigmoid(z) = $1/(1+e^{-z})$ = a g’(z) = a(1-a) – See Part 1
g(z) = tanh(z) = a g’(z) = $1 - a^{2}$
g(z) = relu(z) = z  when z>0 and 0 when z 0 and 0 when z <= 0
While it appears that there is a discontinuity for the derivative at 0 the small value at the discontinuity does not present a problem

The implementation of the multi layer vectorized Deep Learning Network for Python, R and Octave is included below. For all these implementations, initially I create the size and configuration of the the Deep Learning network with the layer dimennsions So for example layersDimension Vector ‘V’ of length L indicating ‘L’ layers where

V (in Python)= $[v_{0}, v_{1}, v_{2}$, … $v_{L-1}]$
V (in R)= $c(v_{1}, v_{2}, v_{3}$ , … $v_{L})$
V (in Octave)= [ $v_{1} v_{2} v_{3}$$v_{L}]$

In all of these implementations the first element is the number of input features to the Deep Learning network and the last element is always a ‘sigmoid’ activation function since all the problems deal with binary classification.

The number of elements between the first and the last element are the number of hidden layers and the magnitude of each $v_{i}$ is the number of activation units in each hidden layer, which is specified while actually executing the Deep Learning network using the function L_Layer_DeepModel(), in all the implementations Python, R and Octave

## 1a. Classification with Multi layer Deep Learning Network – Relu activation(Python)

In the code below a 4 layer Neural Network is trained to generate a non-linear boundary between the classes. In the code below the ‘Relu’ Activation function is used. The number of activation units in each layer is 9. The cost vs iterations is plotted in addition to the decision boundary. Further the accuracy, precision, recall and F1 score are also computed

import os
import numpy as np
import matplotlib.pyplot as plt
import matplotlib.colors
import sklearn.linear_model

from sklearn.model_selection import train_test_split
from sklearn.datasets import make_classification, make_blobs
from matplotlib.colors import ListedColormap
import sklearn
import sklearn.datasets

#from DLfunctions import plot_decision_boundary
execfile("./DLfunctions34.py") #
os.chdir("C:\\software\\DeepLearning-Posts\\part3")

# Create clusters of 2 classes
X1, Y1 = make_blobs(n_samples = 400, n_features = 2, centers = 9,
cluster_std = 1.3, random_state = 4)
#Create 2 classes
Y1=Y1.reshape(400,1)
Y1 = Y1 % 2
X2=X1.T
Y2=Y1.T
# Set the dimensions of DL Network
#  Below we have
#  2 - 2 input features
#  9,9 - 2 hidden layers with 9 activation units per layer and
#  1 - 1 sigmoid activation unit in the output layer as this is a binary classification
# The activation in the hidden layer is the 'relu' specified in L_Layer_DeepModel

layersDimensions = [2, 9, 9,1] #  4-layer model
parameters = L_Layer_DeepModel(X2, Y2, layersDimensions,hiddenActivationFunc='relu', learning_rate = 0.3,num_iterations = 2500, fig="fig1.png")
#Plot the decision boundary
plot_decision_boundary(lambda x: predict(parameters, x.T), X2,Y2,str(0.3),"fig2.png")

# Compute the confusion matrix
yhat = predict(parameters,X2)
from sklearn.metrics import confusion_matrix
a=confusion_matrix(Y2.T,yhat.T)
from sklearn.metrics import accuracy_score, precision_score, recall_score, f1_score
print('Accuracy: {:.2f}'.format(accuracy_score(Y2.T, yhat.T)))
print('Precision: {:.2f}'.format(precision_score(Y2.T, yhat.T)))
print('Recall: {:.2f}'.format(recall_score(Y2.T, yhat.T)))
print('F1: {:.2f}'.format(f1_score(Y2.T, yhat.T)))
## Accuracy: 0.90
## Precision: 0.91
## Recall: 0.87
## F1: 0.89

For more details on metrics like Accuracy, Recall, Precision etc. used in classification take a look at my post Practical Machine Learning with R and Python – Part 2. More details about these and other metrics besides implementation of the most common machine learning algorithms are available in my book My book ‘Practical Machine Learning with R and Python’ on Amazon

## 1b. Classification with Multi layer Deep Learning Network – Relu activation(R)

In the code below, binary classification is performed on the same data set as above using the Relu activation function. The DL network is same as above

library(ggplot2)
# Read the data
z <- as.matrix(read.csv("data.csv",header=FALSE))
x <- z[,1:2]
y <- z[,3]
X1 <- t(x)
Y1 <- t(y)

# Set the dimensions of the Deep Learning network
# No of input features =2, 2 hidden layers with 9 activation units and 1 output layer
layersDimensions = c(2, 9, 9,1)
# Execute the Deep Learning Neural Network
retvals = L_Layer_DeepModel(X1, Y1, layersDimensions,
hiddenActivationFunc='relu',
learningRate = 0.3,
numIterations = 5000,
print_cost = True)
library(ggplot2)
source("DLfunctions33.R")
# Get the computed costs
costs <- retvals[['costs']]
# Create a sequence of iterations
numIterations=5000
iterations <- seq(0,numIterations,by=1000)
df <-data.frame(iterations,costs)
# Plot the Costs vs number of iterations
ggplot(df,aes(x=iterations,y=costs)) + geom_point() +geom_line(color="blue") +
xlab('No of iterations') + ylab('Cost') + ggtitle("Cost vs No of iterations")

# Plot the decision boundary
plotDecisionBoundary(z,retvals,hiddenActivationFunc="relu",0.3)

library(caret)
# Predict the output for the data values
yhat <-predict(retvals$parameters,X1,hiddenActivationFunc="relu") yhat[yhat==FALSE]=0 yhat[yhat==TRUE]=1 # Compute the confusion matrix confusionMatrix(yhat,Y1) ## Confusion Matrix and Statistics ## ## Reference ## Prediction 0 1 ## 0 201 10 ## 1 21 168 ## ## Accuracy : 0.9225 ## 95% CI : (0.8918, 0.9467) ## No Information Rate : 0.555 ## P-Value [Acc > NIR] : < 2e-16 ## ## Kappa : 0.8441 ## Mcnemar's Test P-Value : 0.07249 ## ## Sensitivity : 0.9054 ## Specificity : 0.9438 ## Pos Pred Value : 0.9526 ## Neg Pred Value : 0.8889 ## Prevalence : 0.5550 ## Detection Rate : 0.5025 ## Detection Prevalence : 0.5275 ## Balanced Accuracy : 0.9246 ## ## 'Positive' Class : 0 ##  ## 1c. Classification with Multi layer Deep Learning Network – Relu activation(Octave) Included below is the code for performing classification. Incidentally Octave does not seem to have implemented the confusion matrix, but confusionmat is available in Matlab. # Read the data data=csvread("data.csv"); X=data(:,1:2); Y=data(:,3); # Set layer dimensions layersDimensions = [2 9 7 1] #tanh=-0.5(ok), #relu=0.1 best! # Execute Deep Network [weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions, hiddenActivationFunc='relu', learningRate = 0.1, numIterations = 10000); plotCostVsIterations(10000,costs); plotDecisionBoundary(data,weights, biases,hiddenActivationFunc="tanh")  ## 2a. Classification with Multi layer Deep Learning Network – Tanh activation(Python) Below the Tanh activation function is used to perform the same classification. I found the Tanh activation required a simpler Neural Network of 3 layers. # Tanh activation import os import numpy as np import matplotlib.pyplot as plt import matplotlib.colors import sklearn.linear_model from sklearn.model_selection import train_test_split from sklearn.datasets import make_classification, make_blobs from matplotlib.colors import ListedColormap import sklearn import sklearn.datasets #from DLfunctions import plot_decision_boundary os.chdir("C:\\software\\DeepLearning-Posts\\part3") execfile("./DLfunctions34.py") # Create the dataset X1, Y1 = make_blobs(n_samples = 400, n_features = 2, centers = 9, cluster_std = 1.3, random_state = 4) #Create 2 classes Y1=Y1.reshape(400,1) Y1 = Y1 % 2 X2=X1.T Y2=Y1.T # Set the dimensions of the Neural Network layersDimensions = [2, 4, 1] # 3-layer model # Compute the DL network parameters = L_Layer_DeepModel(X2, Y2, layersDimensions, hiddenActivationFunc='tanh', learning_rate = .5,num_iterations = 2500,fig="fig3.png") #Plot the decision boundary plot_decision_boundary(lambda x: predict(parameters, x.T), X2,Y2,str(0.5),"fig4.png")  ## 2b. Classification with Multi layer Deep Learning Network – Tanh activation(R) R performs better with a Tanh activation than the Relu as can be seen below  #Set the dimensions of the Neural Network layersDimensions = c(2, 9, 9,1) library(ggplot2) # Read the data z <- as.matrix(read.csv("data.csv",header=FALSE)) x <- z[,1:2] y <- z[,3] X1 <- t(x) Y1 <- t(y) # Execute the Deep Model retvals = L_Layer_DeepModel(X1, Y1, layersDimensions, hiddenActivationFunc='tanh', learningRate = 0.3, numIterations = 5000, print_cost = True) # Get the costs costs <- retvals[['costs']] iterations <- seq(0,numIterations,by=1000) df <-data.frame(iterations,costs) # Plot Cost vs number of iterations ggplot(df,aes(x=iterations,y=costs)) + geom_point() +geom_line(color="blue") + xlab('No of iterations') + ylab('Cost') + ggtitle("Cost vs No of iterations") #Plot the decision boundary plotDecisionBoundary(z,retvals,hiddenActivationFunc="tanh",0.3) ## 2c. Classification with Multi layer Deep Learning Network – Tanh activation(Octave) The code below uses the Tanh activation in the hidden layers for Octave # Read the data data=csvread("data.csv"); X=data(:,1:2); Y=data(:,3); # Set layer dimensions layersDimensions = [2 9 7 1] #tanh=-0.5(ok), #relu=0.1 best! # Execute Deep Network [weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions, hiddenActivationFunc='tanh', learningRate = 0.1, numIterations = 10000); plotCostVsIterations(10000,costs); plotDecisionBoundary(data,weights, biases,hiddenActivationFunc="tanh")  ## 3. Bernoulli’s Lemniscate To make things more interesting, I create a 2D figure of the Bernoulli’s lemniscate to perform non-linear classification. The Lemniscate is given by the equation $(x^{2} + y^{2})^{2}$ = $2a^{2}*(x^{2}-y^{2})$ ## 3a. Classifying a lemniscate with Deep Learning Network – Relu activation(Python) import os import numpy as np import matplotlib.pyplot as plt os.chdir("C:\\software\\DeepLearning-Posts\\part3") execfile("./DLfunctions33.py") x1=np.random.uniform(0,10,2000).reshape(2000,1) x2=np.random.uniform(0,10,2000).reshape(2000,1) X=np.append(x1,x2,axis=1) X.shape # Create a subset of values where squared is <0,4. Perform ravel() to flatten this vector # Create the equation # (x^{2} + y^{2})^2 - 2a^2*(x^{2}-y^{2}) <= 0 a=np.power(np.power(X[:,0]-5,2) + np.power(X[:,1]-5,2),2) b=np.power(X[:,0]-5,2) - np.power(X[:,1]-5,2) c= a - (b*np.power(4,2)) <=0 Y=c.reshape(2000,1) # Create a scatter plot of the lemniscate plt.scatter(X[:,0], X[:,1], c=Y, marker= 'o', s=15,cmap="viridis") Z=np.append(X,Y,axis=1) plt.savefig("fig50.png",bbox_inches='tight') plt.clf() # Set the data for classification X2=X.T Y2=Y.T # These settings work the best # Set the Deep Learning layer dimensions for a Relu activation layersDimensions = [2,7,4,1] #Execute the DL network parameters = L_Layer_DeepModel(X2, Y2, layersDimensions, hiddenActivationFunc='relu', learning_rate = 0.5,num_iterations = 10000, fig="fig5.png") #Plot the decision boundary plot_decision_boundary(lambda x: predict(parameters, x.T), X2, Y2,str(2.2),"fig6.png") # Compute the Confusion matrix yhat = predict(parameters,X2) from sklearn.metrics import confusion_matrix a=confusion_matrix(Y2.T,yhat.T) from sklearn.metrics import accuracy_score, precision_score, recall_score, f1_score print('Accuracy: {:.2f}'.format(accuracy_score(Y2.T, yhat.T))) print('Precision: {:.2f}'.format(precision_score(Y2.T, yhat.T))) print('Recall: {:.2f}'.format(recall_score(Y2.T, yhat.T))) print('F1: {:.2f}'.format(f1_score(Y2.T, yhat.T))) ## Accuracy: 0.93 ## Precision: 0.77 ## Recall: 0.76 ## F1: 0.76 We could get better performance by tuning further. Do play around if you fork the code. Note:: The lemniscate data is saved as a CSV and then read in R and also in Octave. I do this instead of recreating the lemniscate shape ## 3b. Classifying a lemniscate with Deep Learning Network – Relu activation(R code) The R decision boundary for the Bernoulli’s lemniscate is shown below Z <- as.matrix(read.csv("lemniscate.csv",header=FALSE)) Z1=data.frame(Z) # Create a scatter plot of the lemniscate ggplot(Z1,aes(x=V1,y=V2,col=V3)) +geom_point() #Set the data for the DL network X=Z[,1:2] Y=Z[,3] X1=t(X) Y1=t(Y) # Set the layer dimensions for the tanh activation function layersDimensions = c(2,5,4,1) # Execute the Deep Learning network with Tanh activation retvals = L_Layer_DeepModel(X1, Y1, layersDimensions, hiddenActivationFunc='tanh', learningRate = 0.3, numIterations = 20000, print_cost = True) # Plot cost vs iteration costs <- retvals[['costs']] numIterations = 20000 iterations <- seq(0,numIterations,by=1000) df <-data.frame(iterations,costs) ggplot(df,aes(x=iterations,y=costs)) + geom_point() +geom_line(color="blue") + xlab('No of iterations') + ylab('Cost') + ggtitle("Cost vs No of iterations") #Plot the decision boundary plotDecisionBoundary(Z,retvals,hiddenActivationFunc="tanh",0.3) ## 3c. Classifying a lemniscate with Deep Learning Network – Relu activation(Octave code) Octave is used to generate the non-linear lemniscate boundary.  # Read the data data=csvread("lemniscate.csv"); X=data(:,1:2); Y=data(:,3); # Set the dimensions of the layers layersDimensions = [2 9 7 1] # Compute the DL network [weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions, hiddenActivationFunc='relu', learningRate = 0.20, numIterations = 10000); plotCostVsIterations(10000,costs); plotDecisionBoundary(data,weights, biases,hiddenActivationFunc="relu")  ## 4a. Binary Classification using MNIST – Python code Finally I perform a simple classification using the MNIST handwritten digits, which according to Prof Geoffrey Hinton is “the Drosophila of Deep Learning”. The Python code for reading the MNIST data is taken from Alex Kesling’s github link MNIST. In the Python code below, I perform a simple binary classification between the handwritten digit ‘5’ and ‘not 5’ which is all other digits. I will perform the proper classification of all digits using the Softmax classifier some time later. import os import numpy as np import matplotlib.pyplot as plt os.chdir("C:\\software\\DeepLearning-Posts\\part3") execfile("./DLfunctions34.py") execfile("./load_mnist.py") training=list(read(dataset='training',path="./mnist")) test=list(read(dataset='testing',path="./mnist")) lbls=[] pxls=[] print(len(training)) # Select the first 10000 training data and the labels for i in range(10000): l,p=training[i] lbls.append(l) pxls.append(p) labels= np.array(lbls) pixels=np.array(pxls) # Sey y=1 when labels == 5 and 0 otherwise y=(labels==5).reshape(-1,1) X=pixels.reshape(pixels.shape[0],-1) # Create the necessary feature and target variable X1=X.T Y1=y.T # Create the layer dimensions. The number of features are 28 x 28 = 784 since the 28 x 28 # pixels is flattened to single vector of length 784. layersDimensions=[784, 15,9,7,1] # Works very well parameters = L_Layer_DeepModel(X1, Y1, layersDimensions, hiddenActivationFunc='relu', learning_rate = 0.1,num_iterations = 1000, fig="fig7.png") # Test data lbls1=[] pxls1=[] for i in range(800): l,p=test[i] lbls1.append(l) pxls1.append(p) testLabels=np.array(lbls1) testData=np.array(pxls1) ytest=(testLabels==5).reshape(-1,1) Xtest=testData.reshape(testData.shape[0],-1) Xtest1=Xtest.T Ytest1=ytest.T yhat = predict(parameters,Xtest1) from sklearn.metrics import confusion_matrix a=confusion_matrix(Ytest1.T,yhat.T) from sklearn.metrics import accuracy_score, precision_score, recall_score, f1_score print('Accuracy: {:.2f}'.format(accuracy_score(Ytest1.T, yhat.T))) print('Precision: {:.2f}'.format(precision_score(Ytest1.T, yhat.T))) print('Recall: {:.2f}'.format(recall_score(Ytest1.T, yhat.T))) print('F1: {:.2f}'.format(f1_score(Ytest1.T, yhat.T))) probs=predict_proba(parameters,Xtest1) from sklearn.metrics import precision_recall_curve precision, recall, thresholds = precision_recall_curve(Ytest1.T, probs.T) closest_zero = np.argmin(np.abs(thresholds)) closest_zero_p = precision[closest_zero] closest_zero_r = recall[closest_zero] plt.xlim([0.0, 1.01]) plt.ylim([0.0, 1.01]) plt.plot(precision, recall, label='Precision-Recall Curve') plt.plot(closest_zero_p, closest_zero_r, 'o', markersize = 12, fillstyle = 'none', c='r', mew=3) plt.xlabel('Precision', fontsize=16) plt.ylabel('Recall', fontsize=16) plt.savefig("fig8.png",bbox_inches='tight')   ## Accuracy: 0.99 ## Precision: 0.96 ## Recall: 0.89 ## F1: 0.92 In addition to plotting the Cost vs Iterations, I also plot the Precision-Recall curve to show how the Precision and Recall, which are complementary to each other vary with respect to the other. To know more about Precision-Recall, please check my post Practical Machine Learning with R and Python – Part 4. Check out my compact and minimal book “Practical Machine Learning with R and Python:Second edition- Machine Learning in stereo” available in Amazon in paperback($10.99) and kindle($7.99) versions. My book includes implementations of key ML algorithms and associated measures and metrics. The book is ideal for anybody who is familiar with the concepts and would like a quick reference to the different ML algorithms that can be applied to problems and how to select the best model. Pick your copy today!! A physical copy of the book is much better than scrolling down a webpage. Personally, I tend to use my own book quite frequently to refer to R, Python constructs, subsetting, machine Learning function calls and the necessary parameters etc. It is useless to commit any of this to memory, and a physical copy of a book is much easier to thumb through for the relevant code snippet. Pick up your copy today! ## 4b. Binary Classification using MNIST – R code In the R code below the same binary classification of the digit ‘5’ and the ‘not 5’ is performed. The code to read and display the MNIST data is taken from Brendan O’ Connor’s github link at MNIST source("mnist.R") load_mnist() #show_digit(train$x[2,]
layersDimensions=c(784, 7,7,3,1) # Works at 1500
x <- t(train$x) # Choose only 5000 training data x2 <- x[,1:5000] y <-train$y
# Set labels for all digits that are 'not 5' to 0
y[y!=5] <- 0
# Set labels of digit 5 as 1
y[y==5] <- 1
# Set the data
y1 <- as.matrix(y)
y2 <- t(y1)
# Choose the 1st 5000 data
y3 <- y2[,1:5000]

#Execute the Deep Learning Model
retvals = L_Layer_DeepModel(x2, y3, layersDimensions,
hiddenActivationFunc='tanh',
learningRate = 0.3,
numIterations = 3000, print_cost = True)
# Plot cost vs iteration
costs <- retvals[['costs']]
numIterations = 3000
iterations <- seq(0,numIterations,by=1000)
df <-data.frame(iterations,costs)
ggplot(df,aes(x=iterations,y=costs)) + geom_point() +geom_line(color="blue") +
xlab('No of iterations') + ylab('Cost') + ggtitle("Cost vs No of iterations")

# Compute probability scores
scores <- computeScores(retvals$parameters, x2,hiddenActivationFunc='relu') a=y3==1 b=y3==0 # Compute probabilities of class 0 and class 1 class1=scores[a] class0=scores[b] # Plot ROC curve pr <-pr.curve(scores.class0=class1, scores.class1=class0, curve=T) plot(pr) The AUC curve hugs the top left corner and hence the performance of the classifier is quite good. ## 4c. Binary Classification using MNIST – Octave code This code to load MNIST data was taken from Daniel E blog. Precision recall curves are available in Matlab but are yet to be implemented in Octave’s statistics package.  load('./mnist/mnist.txt.gz'); % load the dataset # Subset the 'not 5' digits a=(trainY != 5); # Subset '5' b=(trainY == 5); #make a copy of trainY #Set 'not 5' as 0 and '5' as 1 y=trainY; y(a)=0; y(b)=1; X=trainX(1:5000,:); Y=y(1:5000); # Set the dimensions of layer layersDimensions=[784, 7,7,3,1]; # Compute the DL network [weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions, hiddenActivationFunc='relu', learningRate = 0.1, numIterations = 5000);  # Conclusion It was quite a challenge coding a Deep Learning Network in Python, R and Octave. The Deep Learning network implementation, in this post,is the base Deep Learning network, without any of the regularization methods included. Here are some key learning that I got while playing with different multi-layer networks on different problems a. Deep Learning Networks come with many levers, the hyper-parameters, – learning rate – activation unit – number of hidden layers – number of units per hidden layer – number of iterations while performing gradient descent b. Deep Networks are very sensitive. A change in any of the hyper-parameter makes it perform very differently c. Initially I thought adding more hidden layers, or more units per hidden layer will make the DL network better at learning. On the contrary, there is a performance degradation after the optimal DL configuration d. At a sub-optimal number of hidden layers or number of hidden units, gradient descent seems to get stuck at a local minima e. There were occasions when the cost came down, only to increase slowly as the number of iterations were increased. Probably early stopping would have helped. f. I also did come across situations of ‘exploding/vanishing gradient’, cost went to Inf/-Inf. Here I would think inclusion of ‘momentum method’ would have helped I intend to add the additional hyper-parameters of L1, L2 regularization, momentum method, early stopping etc. into the code in my future posts. Feel free to fork/clone the code from Github Deep Learning – Part 3, and take the DL network apart and play around with it. I will be continuing this series with more hyper-parameters to handle vanishing and exploding gradients, early stopping and regularization in the weeks to come. I also intend to add some more activation functions to this basic Multi-Layer Network. Hang around, there are more exciting things to come. Watch this space! To see all posts see Index of posts # Deep Learning from first principles in Python, R and Octave – Part 2 “What does the world outside your head really ‘look’ like? Not only is there no color, there’s also no sound: the compression and expansion of air is picked up by the ears, and turned into electrical signals. The brain then presents these signals to us as mellifluous tones and swishes and clatters and jangles. Reality is also odorless: there’s no such thing as smell outside our brains. Molecules floating through the air bind to receptors in our nose and are interpreted as different smells by our brain. The real world is not full of rich sensory events; instead, our brains light up the world with their own sensuality.” The Brain: The Story of You” by David Eagleman The world is Maya, illusory. The ultimate reality, the Brahman, is all-pervading and all-permeating, which is colourless, odourless, tasteless, nameless and formless Bhagavad Gita ## 1. Introduction This post is a follow-up post to my earlier post Deep Learning from first principles in Python, R and Octave-Part 1. In the first part, I implemented Logistic Regression, in vectorized Python,R and Octave, with a wannabe Neural Network (a Neural Network with no hidden layers). In this second part, I implement a regular, but somewhat primitive Neural Network (a Neural Network with just 1 hidden layer). The 2nd part implements classification of manually created datasets, where the different clusters of the 2 classes are not linearly separable. Neural Network perform really well in learning all sorts of non-linear boundaries between classes. Initially logistic regression is used perform the classification and the decision boundary is plotted. Vanilla logistic regression performs quite poorly. Using SVMs with a radial basis kernel would have performed much better in creating non-linear boundaries. To see R and Python implementations of SVMs take a look at my post Practical Machine Learning with R and Python – Part 4. Checkout my book ‘Deep Learning from first principles: Second Edition – In vectorized Python, R and Octave’. My book starts with the implementation of a simple 2-layer Neural Network and works its way to a generic L-Layer Deep Learning Network, with all the bells and whistles. The derivations have been discussed in detail. The code has been extensively commented and included in its entirety in the Appendix sections. My book is available on Amazon as paperback ($18.99) and in kindle version($9.99/Rs449). You may also like my companion book “Practical Machine Learning with R and Python:Second Edition- Machine Learning in stereo” available in Amazon in paperback($10.99) and Kindle($7.99/Rs449) versions. This book is ideal for a quick reference of the various ML functions and associated measurements in both R and Python which are essential to delve deep into Deep Learning. Take a look at my video presentation which discusses the below derivation step-by- step Elements of Neural Networks and Deep Learning – Part 3 You can clone and fork this R Markdown file along with the vectorized implementations of the 3 layer Neural Network for Python, R and Octave from Github DeepLearning-Part2 ### 2. The 3 layer Neural Network A simple representation of a 3 layer Neural Network (NN) with 1 hidden layer is shown below. In the above Neural Network, there are 2 input features at the input layer, 3 hidden units at the hidden layer and 1 output layer as it deals with binary classification. The activation unit at the hidden layer can be a tanh, sigmoid, relu etc. At the output layer the activation is a sigmoid to handle binary classification # Superscript indicates layer 1 $z_{11} = w_{11}^{1}x_{1} + w_{21}^{1}x_{2} + b_{1}$ $z_{12} = w_{12}^{1}x_{1} + w_{22}^{1}x_{2} + b_{1}$ $z_{13} = w_{13}^{1}x_{1} + w_{23}^{1}x_{2} + b_{1}$ Also $a_{11} = tanh(z_{11})$ $a_{12} = tanh(z_{12})$ $a_{13} = tanh(z_{13})$ # Superscript indicates layer 2 $z_{21} = w_{11}^{2}a_{11} + w_{21}^{2}a_{12} + w_{31}^{2}a_{13} + b_{2}$ $a_{21} = sigmoid(z21)$ Hence $Z1= \begin{pmatrix} z11\\ z12\\ z13 \end{pmatrix} =\begin{pmatrix} w_{11}^{1} & w_{21}^{1} \\ w_{12}^{1} & w_{22}^{1} \\ w_{13}^{1} & w_{23}^{1} \end{pmatrix} * \begin{pmatrix} x1\\ x2 \end{pmatrix} + b_{1}$ And $A1= \begin{pmatrix} a11\\ a12\\ a13 \end{pmatrix} = \begin{pmatrix} tanh(z11)\\ tanh(z12)\\ tanh(z13) \end{pmatrix}$ Similarly $Z2= z_{21} = \begin{pmatrix} w_{11}^{2} & w_{21}^{2} & w_{31}^{2} \end{pmatrix} *\begin{pmatrix} z_{11}\\ z_{12}\\ z_{13} \end{pmatrix} +b_{2}$ and $A2 = a_{21} = sigmoid(z_{21})$ These equations can be written as $Z1 = W1 * X + b1$ $A1 = tanh(Z1)$ $Z2 = W2 * A1 + b2$ $A2 = sigmoid(Z2)$ I) Some important results (a memory refresher!) $d/dx(e^{x}) = e^{x}$ and $d/dx(e^{-x}) = -e^{-x}$ -(a) and $sinhx = (e^{x} - e^{-x})/2$ and $coshx = (e^{x} + e^{-x})/2$ Using (a) we can shown that $d/dx(sinhx) = coshx$ and $d/dx(coshx) = sinhx$ (b) Now $d/dx(f(x)/g(x)) = (g(x)*d/dx(f(x)) - f(x)*d/dx(g(x)))/g(x)^{2}$ -(c) Since $tanhx =z= sinhx/coshx$ and using (b) we get $tanhx = (coshx*d/dx(sinhx) - sinhx*d/dx(coshx))/(cosh^{2})$ Using the values of the derivatives of sinhx and coshx from (b) above we get $d/dx(tanhx) = (coshx^{2} - sinhx{2})/coshx{2} = 1 - tanhx^{2}$ Since $tanhx =z$ $d/dx(tanhx) = 1 - tanhx^{2}= 1 - z^{2}$ -(d) II) Derivatives $L=-(Ylog(A2) + (1-Y)log(1-A2))$ $dL/dA2 = -(Y/A2 + (1-Y)/(1-A2))$ Since $A2 = sigmoid(Z2)$ therefore $dA2/dZ2 = A2(1-A2)$ see Part1 $Z2 = W2A1 +b2$ $dZ2/dW2 = A1$ $dZ2/db2 = 1$ $A1 = tanh(Z1)$ and $dA1/dZ1 = 1 - A1^{2}$ $Z1 = W1X + b1$ $dZ1/dW1 = X$ $dZ1/db1 = 1$ III) Back propagation Using the derivatives from II) we can derive the following results using Chain Rule $\partial L/\partial Z2 = \partial L/\partial A2 * \partial A2/\partial Z2$ $= -(Y/A2 + (1-Y)/(1-A2)) * A2(1-A2) = A2 - Y$ $\partial L/\partial W2 = \partial L/\partial A2 * \partial A2/\partial Z2 * \partial Z2/\partial W2$ $= (A2-Y) *A1$ -(A) $\partial L/\partial b2 = \partial L/\partial A2 * \partial A2/\partial Z2 * \partial Z2/\partial b2 = (A2-Y)$ -(B) $\partial L/\partial Z1 = \partial L/\partial A2 * \partial A2/\partial Z2 * \partial Z2/\partial A1 *\partial A1/\partial Z1 = (A2-Y) * W2 * (1-A1^{2})$ $\partial L/\partial W1 = \partial L/\partial A2 * \partial A2/\partial Z2 * \partial Z2/\partial A1 *\partial A1/\partial Z1 *\partial Z1/\partial W1$ $=(A2-Y) * W2 * (1-A1^{2}) * X$ -(C) $\partial L/\partial b1 = \partial L/\partial A2 * \partial A2/\partial Z2 * \partial Z2/\partial A1 *dA1/dZ1 *dZ1/db1$ $= (A2-Y) * W2 * (1-A1^{2})$ -(D) IV) Gradient Descent The key computations in the backward cycle are $W1 = W1-learningRate * \partial L/\partial W1$ – From (C) $b1 = b1-learningRate * \partial L/\partial b1$ – From (D) $W2 = W2-learningRate * \partial L/\partial W2$ – From (A) $b2 = b2-learningRate * \partial L/\partial b2$ – From (B) The weights and biases (W1,b1,W2,b2) are updated for each iteration thus minimizing the loss/cost. These derivations can be represented pictorially using the computation graph (from the book Deep Learning by Ian Goodfellow, Joshua Bengio and Aaron Courville) ### 3. Manually create a data set that is not lineary separable Initially I create a dataset with 2 classes which has around 9 clusters that cannot be separated by linear boundaries. Note: This data set is saved as data.csv and is used for the R and Octave Neural networks to see how they perform on the same dataset. import numpy as np import matplotlib.pyplot as plt import matplotlib.colors import sklearn.linear_model from sklearn.model_selection import train_test_split from sklearn.datasets import make_classification, make_blobs from matplotlib.colors import ListedColormap import sklearn import sklearn.datasets colors=['black','gold'] cmap = matplotlib.colors.ListedColormap(colors) X, y = make_blobs(n_samples = 400, n_features = 2, centers = 7, cluster_std = 1.3, random_state = 4) #Create 2 classes y=y.reshape(400,1) y = y % 2 #Plot the figure plt.figure() plt.title('Non-linearly separable classes') plt.scatter(X[:,0], X[:,1], c=y, marker= 'o', s=50,cmap=cmap) plt.savefig('fig1.png', bbox_inches='tight') ### 4. Logistic Regression On the above created dataset, classification with logistic regression is performed, and the decision boundary is plotted. It can be seen that logistic regression performs quite poorly import numpy as np import matplotlib.pyplot as plt import matplotlib.colors import sklearn.linear_model from sklearn.model_selection import train_test_split from sklearn.datasets import make_classification, make_blobs from matplotlib.colors import ListedColormap import sklearn import sklearn.datasets #from DLfunctions import plot_decision_boundary execfile("./DLfunctions.py") # Since import does not work in Rmd!!! colors=['black','gold'] cmap = matplotlib.colors.ListedColormap(colors) X, y = make_blobs(n_samples = 400, n_features = 2, centers = 7, cluster_std = 1.3, random_state = 4) #Create 2 classes y=y.reshape(400,1) y = y % 2 # Train the logistic regression classifier clf = sklearn.linear_model.LogisticRegressionCV(); clf.fit(X, y); # Plot the decision boundary for logistic regression plot_decision_boundary_n(lambda x: clf.predict(x), X.T, y.T,"fig2.png")  ### 5. The 3 layer Neural Network in Python (vectorized) The vectorized implementation is included below. Note that in the case of Python a learning rate of 0.5 and 3 hidden units performs very well. ## Random data set with 9 clusters import numpy as np import matplotlib import matplotlib.pyplot as plt import sklearn.linear_model import pandas as pd from sklearn.datasets import make_classification, make_blobs execfile("./DLfunctions.py") # Since import does not work in Rmd!!! X1, Y1 = make_blobs(n_samples = 400, n_features = 2, centers = 9, cluster_std = 1.3, random_state = 4) #Create 2 classes Y1=Y1.reshape(400,1) Y1 = Y1 % 2 X2=X1.T Y2=Y1.T #Perform gradient descent parameters,costs = computeNN(X2, Y2, numHidden = 4, learningRate=0.5, numIterations = 10000) plot_decision_boundary(lambda x: predict(parameters, x.T), X2, Y2,str(4),str(0.5),"fig3.png") ## Cost after iteration 0: 0.692669 ## Cost after iteration 1000: 0.246650 ## Cost after iteration 2000: 0.227801 ## Cost after iteration 3000: 0.226809 ## Cost after iteration 4000: 0.226518 ## Cost after iteration 5000: 0.226331 ## Cost after iteration 6000: 0.226194 ## Cost after iteration 7000: 0.226085 ## Cost after iteration 8000: 0.225994 ## Cost after iteration 9000: 0.225915 ### 6. The 3 layer Neural Network in R (vectorized) For this the dataset created by Python is saved to see how R performs on the same dataset. The vectorized implementation of a Neural Network was just a little more interesting as R does not have a similar package like ‘numpy’. While numpy handles broadcasting implicitly, in R I had to use the ‘sweep’ command to broadcast. The implementaion is included below. Note that since the initialization with random weights is slightly different, R performs best with a learning rate of 0.1 and with 6 hidden units source("DLfunctions2_1.R") z <- as.matrix(read.csv("data.csv",header=FALSE)) # x <- z[,1:2] y <- z[,3] x1 <- t(x) y1 <- t(y) #Perform gradient descent nn <-computeNN(x1, y1, 6, learningRate=0.1,numIterations=10000) # Good ## [1] 0.7075341 ## [1] 0.2606695 ## [1] 0.2198039 ## [1] 0.2091238 ## [1] 0.211146 ## [1] 0.2108461 ## [1] 0.2105351 ## [1] 0.210211 ## [1] 0.2099104 ## [1] 0.2096437 ## [1] 0.209409 plotDecisionBoundary(z,nn,6,0.1) ### 7. The 3 layer Neural Network in Octave (vectorized) This uses the same dataset that was generated using Python code. source("DL-function2.m") data=csvread("data.csv"); X=data(:,1:2); Y=data(:,3); # Make sure that the model parameters are correct. Take the transpose of X & Y #Perform gradient descent [W1,b1,W2,b2,costs]= computeNN(X', Y',4, learningRate=0.5, numIterations = 10000); ### 8a. Performance for different learning rates (Python) import numpy as np import matplotlib import matplotlib.pyplot as plt import sklearn.linear_model import pandas as pd from sklearn.datasets import make_classification, make_blobs execfile("./DLfunctions.py") # Since import does not work in Rmd!!! # Create data X1, Y1 = make_blobs(n_samples = 400, n_features = 2, centers = 9, cluster_std = 1.3, random_state = 4) #Create 2 classes Y1=Y1.reshape(400,1) Y1 = Y1 % 2 X2=X1.T Y2=Y1.T # Create a list of learning rates learningRate=[0.5,1.2,3.0] df=pd.DataFrame() #Compute costs for each learning rate for lr in learningRate: parameters,costs = computeNN(X2, Y2, numHidden = 4, learningRate=lr, numIterations = 10000) print(costs) df1=pd.DataFrame(costs) df=pd.concat([df,df1],axis=1) #Set the iterations iterations=[0,1000,2000,3000,4000,5000,6000,7000,8000,9000] #Create data frame #Set index df1=df.set_index([iterations]) df1.columns=[0.5,1.2,3.0] fig=df1.plot() fig=plt.title("Cost vs No of Iterations for different learning rates") plt.savefig('fig4.png', bbox_inches='tight') ### 8b. Performance for different hidden units (Python) import numpy as np import matplotlib import matplotlib.pyplot as plt import sklearn.linear_model import pandas as pd from sklearn.datasets import make_classification, make_blobs execfile("./DLfunctions.py") # Since import does not work in Rmd!!! #Create data set X1, Y1 = make_blobs(n_samples = 400, n_features = 2, centers = 9, cluster_std = 1.3, random_state = 4) #Create 2 classes Y1=Y1.reshape(400,1) Y1 = Y1 % 2 X2=X1.T Y2=Y1.T # Make a list of hidden unis numHidden=[3,5,7] df=pd.DataFrame() #Compute costs for different hidden units for numHid in numHidden: parameters,costs = computeNN(X2, Y2, numHidden = numHid, learningRate=1.2, numIterations = 10000) print(costs) df1=pd.DataFrame(costs) df=pd.concat([df,df1],axis=1) #Set the iterations iterations=[0,1000,2000,3000,4000,5000,6000,7000,8000,9000] #Set index df1=df.set_index([iterations]) df1.columns=[3,5,7] #Plot fig=df1.plot() fig=plt.title("Cost vs No of Iterations for different no of hidden units") plt.savefig('fig5.png', bbox_inches='tight') ### 9a. Performance for different learning rates (R) source("DLfunctions2_1.R") # Read data z <- as.matrix(read.csv("data.csv",header=FALSE)) # x <- z[,1:2] y <- z[,3] x1 <- t(x) y1 <- t(y) #Loop through learning rates and compute costs learningRate <-c(0.1,1.2,3.0) df <- NULL for(i in seq_along(learningRate)){ nn <- computeNN(x1, y1, 6, learningRate=learningRate[i],numIterations=10000) cost <- nn$costs
df <- cbind(df,cost)

}

#Create dataframe
df <- data.frame(df)
iterations=seq(0,10000,by=1000)
df <- cbind(iterations,df)
names(df) <- c("iterations","0.5","1.2","3.0")
library(reshape2)
df1 <- melt(df,id="iterations")  # Melt the data
#Plot
ggplot(df1) + geom_line(aes(x=iterations,y=value,colour=variable),size=1)  +
xlab("Iterations") +
ylab('Cost') + ggtitle("Cost vs No iterations for  different learning rates")

### 9b. Performance  for different hidden units (R)

source("DLfunctions2_1.R")
# Loop through Num hidden units
numHidden <-c(4,6,9)
df <- NULL
for(i in seq_along(numHidden)){
nn <-  computeNN(x1, y1, numHidden[i], learningRate=0.1,numIterations=10000)
cost <- nn\$costs
df <- cbind(df,cost)

}
df <- data.frame(df)
iterations=seq(0,10000,by=1000)
df <- cbind(iterations,df)
names(df) <- c("iterations","4","6","9")
library(reshape2)
# Melt
df1 <- melt(df,id="iterations")
# Plot
ggplot(df1) + geom_line(aes(x=iterations,y=value,colour=variable),size=1)  +
xlab("Iterations") +
ylab('Cost') + ggtitle("Cost vs No iterations for  different number of hidden units")

## 10a. Performance of the Neural Network for different learning rates (Octave)

source("DL-function2.m") plotLRCostVsIterations() print -djph figa.jpg

## 10b. Performance of the Neural Network for different number of hidden units (Octave)

source("DL-function2.m") plotHiddenCostVsIterations() print -djph figa.jpg

## 11. Turning the heat on the Neural Network

In this 2nd part I create a a central region of positives and and the outside region as negatives. The points are generated using the equation of a circle (x – a)^{2} + (y -b) ^{2} = R^{2} . How does the 3 layer Neural Network perform on this?  Here’s a look! Note: The same dataset is also used for R and Octave Neural Network constructions

## 12. Manually creating a circular central region

import numpy as np
import matplotlib.pyplot as plt
import matplotlib.colors
import sklearn.linear_model

from sklearn.model_selection import train_test_split
from sklearn.datasets import make_classification, make_blobs
from matplotlib.colors import ListedColormap
import sklearn
import sklearn.datasets

colors=['black','gold']
cmap = matplotlib.colors.ListedColormap(colors)
x1=np.random.uniform(0,10,800).reshape(800,1)
x2=np.random.uniform(0,10,800).reshape(800,1)
X=np.append(x1,x2,axis=1)
X.shape
# Create (x-a)^2 + (y-b)^2 = R^2
# Create a subset of values where squared is <0,4. Perform ravel() to flatten this vector
a=(np.power(X[:,0]-5,2) + np.power(X[:,1]-5,2) <= 6).ravel()
Y=a.reshape(800,1)

cmap = matplotlib.colors.ListedColormap(colors)

plt.figure()
plt.title('Non-linearly separable classes')
plt.scatter(X[:,0], X[:,1], c=Y,
marker= 'o', s=15,cmap=cmap)
plt.savefig('fig6.png', bbox_inches='tight')

### 13a. Decision boundary with hidden units=4 and learning rate = 2.2 (Python)

With the above hyper parameters the decision boundary is triangular

import numpy as np
import matplotlib.pyplot as plt
import matplotlib.colors
import sklearn.linear_model
execfile("./DLfunctions.py")
x1=np.random.uniform(0,10,800).reshape(800,1)
x2=np.random.uniform(0,10,800).reshape(800,1)
X=np.append(x1,x2,axis=1)
X.shape

# Create a subset of values where squared is <0,4. Perform ravel() to flatten this vector
a=(np.power(X[:,0]-5,2) + np.power(X[:,1]-5,2) <= 6).ravel()
Y=a.reshape(800,1)

X2=X.T
Y2=Y.T

parameters,costs = computeNN(X2, Y2, numHidden = 4, learningRate=2.2, numIterations = 10000)
plot_decision_boundary(lambda x: predict(parameters, x.T), X2, Y2,str(4),str(2.2),"fig7.png")

## Cost after iteration 0: 0.692836
## Cost after iteration 1000: 0.331052
## Cost after iteration 2000: 0.326428
## Cost after iteration 3000: 0.474887
## Cost after iteration 4000: 0.247989
## Cost after iteration 5000: 0.218009
## Cost after iteration 6000: 0.201034
## Cost after iteration 7000: 0.197030
## Cost after iteration 8000: 0.193507
## Cost after iteration 9000: 0.191949

### 13b. Decision boundary with hidden units=12 and learning rate = 2.2 (Python)

With the above hyper parameters the decision boundary is triangular

import numpy as np
import matplotlib.pyplot as plt
import matplotlib.colors
import sklearn.linear_model
execfile("./DLfunctions.py")
x1=np.random.uniform(0,10,800).reshape(800,1)
x2=np.random.uniform(0,10,800).reshape(800,1)
X=np.append(x1,x2,axis=1)
X.shape

# Create a subset of values where squared is <0,4. Perform ravel() to flatten this vector
a=(np.power(X[:,0]-5,2) + np.power(X[:,1]-5,2) <= 6).ravel()
Y=a.reshape(800,1)

X2=X.T
Y2=Y.T

parameters,costs = computeNN(X2, Y2, numHidden = 12, learningRate=2.2, numIterations = 10000)
plot_decision_boundary(lambda x: predict(parameters, x.T), X2, Y2,str(12),str(2.2),"fig8.png")

## Cost after iteration 0: 0.693291
## Cost after iteration 1000: 0.383318
## Cost after iteration 2000: 0.298807
## Cost after iteration 3000: 0.251735
## Cost after iteration 4000: 0.177843
## Cost after iteration 5000: 0.130414
## Cost after iteration 6000: 0.152400
## Cost after iteration 7000: 0.065359
## Cost after iteration 8000: 0.050921
## Cost after iteration 9000: 0.039719

### 14a. Decision boundary with hidden units=9 and learning rate = 0.5 (R)

When the number of hidden units is 6 and the learning rate is 0,1, is also a triangular shape in R

source("DLfunctions2_1.R")
z <- as.matrix(read.csv("data1.csv",header=FALSE)) # N
x <- z[,1:2]
y <- z[,3]
x1 <- t(x)
y1 <- t(y)
nn <-computeNN(x1, y1, 9, learningRate=0.5,numIterations=10000) # Triangular
## [1] 0.8398838
## [1] 0.3303621
## [1] 0.3127731
## [1] 0.3012791
## [1] 0.3305543
## [1] 0.3303964
## [1] 0.2334615
## [1] 0.1920771
## [1] 0.2341225
## [1] 0.2188118
## [1] 0.2082687
plotDecisionBoundary(z,nn,6,0.1)

### 14b. Decision boundary with hidden units=8 and learning rate = 0.1 (R)

source("DLfunctions2_1.R")
z <- as.matrix(read.csv("data1.csv",header=FALSE)) # N
x <- z[,1:2]
y <- z[,3]
x1 <- t(x)
y1 <- t(y)
nn <-computeNN(x1, y1, 8, learningRate=0.1,numIterations=10000) # Hemisphere
## [1] 0.7273279
## [1] 0.3169335
## [1] 0.2378464
## [1] 0.1688635
## [1] 0.1368466
## [1] 0.120664
## [1] 0.111211
## [1] 0.1043362
## [1] 0.09800573
## [1] 0.09126161
## [1] 0.0840379
plotDecisionBoundary(z,nn,8,0.1)

### 15a. Decision boundary with hidden units=12 and learning rate = 1.5 (Octave)

source("DL-function2.m") data=csvread("data1.csv"); X=data(:,1:2); Y=data(:,3); # Make sure that the model parameters are correct. Take the transpose of X & Y [W1,b1,W2,b2,costs]= computeNN(X', Y',12, learningRate=1.5, numIterations = 10000); plotDecisionBoundary(data, W1,b1,W2,b2) print -djpg fige.jpg

Conclusion: This post implemented a 3 layer Neural Network to create non-linear boundaries while performing classification. Clearly the Neural Network performs very well when the number of hidden units and learning rate are varied.

To be continued…
Watch this space!!

To see all posts check Index of posts

# Computer Vision: Ramblings on derivatives, histograms and contours

Images can be visualized to be functions of the form f(x,y) where f(x,y) represents the intensity at the pixel position ,y. However images can be grayscale, color or four channels and each channel may consist of integers or floating point numbers. However the changes in the values can be viewed as a continuous function. Here is a nice representation of an image as a continuous function (courtesy: Prof Darrell’s lecture at Berkeley on Filters)

Given that the image can be viewed as a continuous function in 2 or 3 axes we have derivatives that can be taken of the images. The derivates determine the maximum and minimum of this changing function. The key derivatives in image processing are the Sobel, the Scharr and the Laplacian filters. These provide the 1st order or 2nd order derivative and hence can be used for determining edges of an image.

I was keen on playing around with derivatives and also understanding how the histograms look like.

Here is the original image and its histogram. Clearly there is a nice spread of the values.

Sobel filter and its histogram

The output of the Sobel filter on the original image is shown. The edges with Sobel’s derivative somehow are not too pronounced. The Sobel derivate can be used for obtaining the gradient of the image. The corresponding histogram of the Sobel’s gradient is shown.

The code snippet ( The complete code is given below)

    IplImage* out_sobel = cvCreateImage( cvSize(img->width, img->height), IPL_DEPTH_16S, 1);
cvSobel(in_gray, out_sobel, 1,1,7);
cvShowImage("Sobel", out_sobel);

//create an image to hold the histogram
IplImage* histImage_Sobel = cvCreateImage(cvSize(300,400), 8, 1);

//create a histogram to store the information from the image
CvHistogram* histSobel = cvCreateHist(1, &hist_size, CV_HIST_ARRAY, ranges, 1);

//calculate the histogram and apply to hist
cvCalcHist( &histImage_Sobel, histSobel, 0, NULL );

//grab the min and max values and their indeces
cvGetMinMaxHistValue( histSobel, &min_value, &max_value, &min_idx, &max_idx);

//scale the bin values so that they will fit in the image representation
cvScale( histSobel->bins, histSobel->bins, ((double)histImage_Sobel->height)/max_value, 0 );

//set all histogram values to 255
cvSet( histImage_Sobel, cvScalarAll(255), 0 );

//create a factor for scaling along the width
bin_w = cvRound((double)histImage_Sobel->width/hist_size);

for( i = 0; i < hist_size; i++ ) {
//draw the histogram data onto the histogram image
cvRectangle( histImage_Sobel, cvPoint(i*bin_w, histImage_Sobel->height),
cvPoint((i+1)*bin_w,
histImage_Sobel->height - cvRound(cvGetReal1D(histSobel->bins,i))),
cvScalarAll(0), -1, 8, 0 );
//get the value at the current histogram bucket
float* bins = cvGetHistValue_1D(histSobel,i);
//increment the mean value
mean += bins[0];
}

cvShowImage("Hist Sobel",histImage_Sobel);
...
...
(Please see Gavin S. Page's tutorial(vast.uccs.edu/~tboult/CS330/NOTES/OpenCVTutorial_II.ppt) on histograms)

Laplacian and its histogram

The Laplacian provides the 2nd order derivative and hence can be used to determine local maxima and local minima. The Laplacian provides for much more pronounced edges and can be used to extract features of an object of interest. Its corresponding histogram is also included.

Canny filter and Contours

The third filter is cvCanny which is most suitable for obtaining clear edges in an image. The canny is usually used along with cvFindContours to determine the general shape of an object. I used the canny filter which I passed to a contour detecting function. However the contour detecting function identified more than 228 contours most of which were useless except for 1 which had included the complete contour of the hand as shown.

However when I increased the max_depth to 1 I found that it was immediately able to get the complete contour of the hand besides a lot of extraneous contours.

I guess the challenge with the contour function is being able to programmatically reject all those contours which of lesser importance (possibly a future post).

Code for Sobel, Laplacian and Histograms

#include "cv.h"
#include "highgui.h"
#include "stdio.h"

int main(int argc, char** argv)
{
IplImage* img = cvLoadImage("gazelle.jpg",1);
IplImage* dst;
IplImage* in_gray;
int hist_size=30;
float gray_ranges[] = { 0, 255 };
float* ranges[]     = { gray_ranges};
int min_idx,max_idx;
float min_value,max_value;
int bin_w;
int i;
float mean,variance;

cvNamedWindow("Original",CV_WINDOW_AUTOSIZE);
cvNamedWindow("histogram",CV_WINDOW_AUTOSIZE);
cvNamedWindow("Sobel",CV_WINDOW_AUTOSIZE);
cvNamedWindow("Hist Sobel",CV_WINDOW_AUTOSIZE);

cvNamedWindow("Laplacian",CV_WINDOW_AUTOSIZE);
cvNamedWindow("Hist Laplace",CV_WINDOW_AUTOSIZE);

in_gray = cvCreateImage(cvSize(img->width, img->height), IPL_DEPTH_8U, 1);
cvCvtColor(img, in_gray, CV_BGR2GRAY);
cvShowImage("Original", in_gray);

//create a rectangular area to evaluate
CvRect rect = cvRect(0, 0, 300, 400 );
//apply the rectangle to the image and establish a region of interest
cvSetImageROI(in_gray, rect);

//create an image to hold the histogram
IplImage* histImage = cvCreateImage(cvSize(300,400), 8, 1);

//create a histogram to store the information from the image
CvHistogram* hist = cvCreateHist(1, &hist_size, CV_HIST_ARRAY, ranges, 1);

//calculate the histogram and apply to hist
cvCalcHist( &in_gray, hist, 0, NULL );

//grab the min and max values and their indeces
cvGetMinMaxHistValue( hist, &min_value, &max_value, &min_idx, &max_idx);

//scale the bin values so that they will fit in the image representation
cvScale( hist->bins, hist->bins, ((double)histImage->height)/max_value, 0 );

//set all histogram values to 255
cvSet( histImage, cvScalarAll(255), 0 );

//create a factor for scaling along the width
bin_w = cvRound((double)histImage->width/hist_size);

for( i = 0; i < hist_size; i++ ) {
//draw the histogram data onto the histogram image
cvRectangle( histImage, cvPoint(i*bin_w, histImage->height),
cvPoint((i+1)*bin_w,
histImage->height - cvRound(cvGetReal1D(hist->bins,i))),
cvScalarAll(0), -1, 8, 0 );
//get the value at the current histogram bucket
float* bins = cvGetHistValue_1D(hist,i);
//increment the mean value
mean += bins[0];
}

//finish mean calculation
mean /= hist_size;

//go back through now that mean has been calculated in order to calculate variance
for( i = 0; i < hist_size; i++ ) {
float* bins = cvGetHistValue_1D(hist,i);
variance += pow((bins[0] - mean),2);
}
//finish variance calculation
variance /= hist_size;

cvShowImage("histogram",histImage);

IplImage* out_sobel = cvCreateImage( cvSize(img->width, img->height), IPL_DEPTH_16S, 1);
cvSobel(in_gray, out_sobel, 1,1,7);
cvShowImage("Sobel", out_sobel);

//create an image to hold the histogram
IplImage* histImage_Sobel = cvCreateImage(cvSize(300,400), 8, 1);

//create a histogram to store the information from the image
CvHistogram* histSobel = cvCreateHist(1, &hist_size, CV_HIST_ARRAY, ranges, 1);

//calculate the histogram and apply to hist
cvCalcHist( &histImage_Sobel, histSobel, 0, NULL );

//grab the min and max values and their indeces
cvGetMinMaxHistValue( histSobel, &min_value, &max_value, &min_idx, &max_idx);

//scale the bin values so that they will fit in the image representation
cvScale( histSobel->bins, histSobel->bins, ((double)histImage_Sobel->height)/max_value, 0 );

//set all histogram values to 255
cvSet( histImage_Sobel, cvScalarAll(255), 0 );

//create a factor for scaling along the width
bin_w = cvRound((double)histImage_Sobel->width/hist_size);

for( i = 0; i < hist_size; i++ ) {
//draw the histogram data onto the histogram image
cvRectangle( histImage_Sobel, cvPoint(i*bin_w, histImage_Sobel->height),
cvPoint((i+1)*bin_w,
histImage_Sobel->height - cvRound(cvGetReal1D(histSobel->bins,i))),
cvScalarAll(0), -1, 8, 0 );
//get the value at the current histogram bucket
float* bins = cvGetHistValue_1D(histSobel,i);
//increment the mean value
mean += bins[0];
}

cvShowImage("Hist Sobel",histImage_Sobel);

// Create Laplacian and the histogram for it
IplImage *output=cvCreateImage( cvSize(img->width, img->height), IPL_DEPTH_16S, 1);
cvLaplace(in_gray, output, 7);
cvShowImage("Laplacian", output);

//create an image to hold the histogram
IplImage* histImage_Laplace = cvCreateImage(cvSize(300,400), 8, 1);

//create a histogram to store the information from the image
CvHistogram* histLaplace = cvCreateHist(1, &hist_size, CV_HIST_ARRAY, ranges, 1);

//calculate the histogram and apply to hist
cvCalcHist( &histImage_Laplace, histLaplace, 0, NULL );

//grab the min and max values and their indeces
cvGetMinMaxHistValue( histLaplace, &min_value, &max_value, &min_idx, &max_idx);

//scale the bin values so that they will fit in the image representation
cvScale( histLaplace->bins, histLaplace->bins, ((double)histImage_Laplace->height)/max_value, 0 );

//set all histogram values to 255
cvSet( histImage_Laplace, cvScalarAll(255), 0 );

//create a factor for scaling along the width
bin_w = cvRound((double)histImage_Laplace->width/hist_size);

for( i = 0; i < hist_size; i++ ) {
//draw the histogram data onto the histogram image
cvRectangle( histImage_Laplace, cvPoint(i*bin_w, histImage_Laplace->height),
cvPoint((i+1)*bin_w,
histImage_Laplace->height - cvRound(cvGetReal1D(histLaplace->bins,i))),
cvScalarAll(0), -1, 8, 0 );
//get the value at the current histogram bucket
float* bins = cvGetHistValue_1D(histLaplace,i);
//increment the mean value
mean += bins[0];
}

cvShowImage("Hist Laplace",histImage_Laplace);

cvWaitKey(0);

printf("Mean= %f\n",mean);
printf("variance=%f\n",variance);

//clean up images
cvReleaseImage(&histImage_Laplace);
cvReleaseImage(&histImage_Sobel);
cvReleaseImage(&histImage);
cvReleaseImage(&in_gray);
cvReleaseImage(&img);

//remove windows
cvDestroyWindow("Original");

cvDestroyWindow("histogram");
}

Code for Canny & Contours
#include "cv.h"
#include "highgui.h"

#define CVX_RED		CV_RGB(0xff,0x00,0x00)
#define CVX_GREEN	CV_RGB(0x00,0xff,0x00)
#define CVX_BLUE	CV_RGB(0x00,0x00,0xff)

int main(int argc, char* argv[])
{
CvSeq* c;
int i;
cvNamedWindow("Original", 1 );
cvNamedWindow("Canny_Edge", 1 );
cvNamedWindow("Contours", 1 );
IplImage* img_8uc1 = cvLoadImage( argv[1], CV_LOAD_IMAGE_GRAYSCALE );
IplImage* img_edge = cvCreateImage( cvGetSize(img_8uc1), 8, 1 );
IplImage* img_8uc3 = cvCreateImage( cvGetSize(img_8uc1), 8, 3 );
cvThreshold( img_8uc1, img_edge, 128, 255, CV_THRESH_BINARY );
CvMemStorage* storage =cvCreateMemStorage(0);

CvSeq* first_contour = NULL;

int Nc;
int n=0;

cvShowImage("Original", img_8uc1);

IplImage *out_canny=cvCreateImage( cvSize(img_8uc1->width, img_8uc1->height), IPL_DEPTH_8U, 1);
cvCanny(img_8uc1, out_canny, 50.0 ,100.0, 3);
cvShowImage("Canny_Edge", out_canny);

/*	Nc = cvFindContours(
img_edge,
storage,
&first_contour,
sizeof(CvContour),
CV_RETR_LIST,
CV_CHAIN_APPROX_SIMPLE,
cvPoint(0,0)// Try all four values and see what happens
);*/

Nc = cvFindContours(
out_canny,
storage,
&first_contour,
sizeof(CvContour),
CV_RETR_TREE,
CV_CHAIN_APPROX_SIMPLE,
cvPoint(0,0)// Try all four values and see what happens
);

printf("Total contours detected: %d\n",Nc);

for(c=first_contour; c!=NULL; c=c->h_next )
{
cvCvtColor( img_8uc1, img_8uc3, CV_GRAY2BGR );
cvDrawContours(
img_8uc3,
c,
CVX_RED,
CVX_BLUE,
1,        // Try different values of max_level, and see what happens
2,
8,
cvPoint(0,0));
printf("Contour #%d\n",n);

cvShowImage("Contours", img_8uc3 );
printf(" %d elements: \n",c->total);

for(i=0; i<c->total; ++i ) {
CvPoint* p = CV_GET_SEQ_ELEM( CvPoint, c, i );
printf("(%d,%d)\n",p->x,p->y);

}
cvWaitKey(0);
n++;
}
printf("Finished all contours\n");
cvCvtColor( img_8uc1, img_8uc3, CV_GRAY2BGR );
cvShowImage( argv[0], img_8uc3 );
cvWaitKey(0);
cvDestroyWindow( argv[0] );
cvReleaseImage( &img_8uc1 );
cvReleaseImage( &img_8uc3 );
cvReleaseImage( &img_edge );
return 0;
}



Find me on Google+
