Introduction

“If cricketr is to cricpy, then yorkr is to _____?”. Yes, you guessed it right, it is yorkpy. In this post, I introduce my 2nd python package, yorkpy, which is a python clone of my R package yorkr. This package is based on data from Cricsheet. yorkpy currently handles IPL T20 matches.

When I created cricpy, the python avatar, of my R package cricketr, see Introducing cricpy:A python package to analyze performances of cricketers, I had decided that I should avoid doing a python avatar of my R package yorkr (see Introducing cricket package yorkr: Part 1- Beaten by sheer pace!) , as it was more involved, and required the parsing of match data available as yaml files.

Just out of curiosity, I tried the python package ‘yaml’ to read the match data, and lo and behold, I was sucked into the developing the package and so, yorkpy was born. Of course, it goes without saying that, usually when I am in the thick of developing something, I occasionally wonder, why I am doing it, for whom and for what purpose? Maybe it is the joy of ideation, the problem-solving,  the programmer’s high, for sharing my ideas etc. Anyway, whatever be the reason, I hope you enjoy this post and also find yorkpy useful.

You can clone/download the code at Github yorkpy
This post has been published to RPubs at yorkpy-Part1
You can download this post as PDF at IPLT20-yorkpy-part1

The IPL T20 functions in yorkpy are

2. Install the package using ‘pip install’

import pandas as pd
import yorkpy.analytics as yka
#pip install yorkpy

3. Load a yaml file from Cricsheet

There are 2 functions that can be to convert the IPL Twenty20 yaml files to pandas dataframeare

  1. convertYaml2PandasDataframeT20
  2. convertAllYaml2PandasDataframesT20

Note 1: While I have already converted the IPL T20 files, you will need to use these functions for future IPL matches

4. Convert and save IPL T20 yaml file to pandas dataframe

This function will convert a IPL T20 IPL yaml file, in the format as specified in Cricsheet to pandas dataframe. This will be saved as as CSV file in the target directory. The name of the file wil have the following format team1-team2-date.csv. The IPL T20 zip file can be downloaded from Indian Premier League matches.  An example of how a yaml file can be converted to a dataframe and saved is shown below.

import pandas as pd
import yorkpy.analytics as yka
#convertYaml2PandasDataframe(".\\1082593.yaml","..\ipl", ..\\data")

5. Convert and save all IPL T20 yaml files to dataframes

This function will convert all IPL T20 yaml files from a source directory to dataframes, and save it in the target directory, with the names as mentioned above. Since I have already done this, I will not be executing this again. You can download the zip of all the converted RData files from Github at yorkpyData

import pandas as pd
import yorkpy.analytics as yka
#convertAllYaml2PandasDataframes("..\\ipl", "..\\data")

You can download the the zip of the files and use it directly in the functions as follows.For the analysis below I chosen a set of random IPL matches

The randomly selected IPL T20 matches are

  • Chennai Super Kings vs Kings Xi Punjab, 2014-05-30
  • Deccan Chargers vs Delhi Daredevils, 2012-05-10
  • Gujarat Lions vs Mumbai Indians, 2017-04-29
  • Kolkata Knight Riders vs Rajasthan Royals, 2010-04-17
  • Rising Pune Supergiants vs Royal Challengers Bangalore, 2017-04-29

6. Team batting scorecard

The function below computes the batting score card of a team in an IPL match. The scorecard gives the balls faced, the runs scored, 4s, 6s and strike rate. The example below is based on the CSK KXIP match on 30 May 2014.

You can check against the actual scores in this match Chennai Super Kings-Kings XI Punjab-2014-05-30

import pandas as pd
import yorkpy.analytics as yka
csk_kxip=pd.read_csv(".\\Chennai Super Kings-Kings XI Punjab-2014-05-30.csv")
scorecard,extras=yka.teamBattingScorecardMatch(csk_kxip,"Chennai Super Kings")
print(scorecard)
##         batsman  runs  balls  4s  6s          SR
## 0      DR Smith     7     12   0   0   58.333333
## 1  F du Plessis     0      1   0   0    0.000000
## 2      SK Raina    87     26  12   0  334.615385
## 3   BB McCullum    11     16   0   0   68.750000
## 4     RA Jadeja    27     22   2   0  122.727273
## 5     DJ Hussey     1      3   0   0   33.333333
## 6      MS Dhoni    42     34   3   0  123.529412
## 7      R Ashwin    10     11   0   0   90.909091
## 8     MM Sharma     1      3   0   0   33.333333
print(extras)
##    total  wides  noballs  legbyes  byes  penalty  extras
## 0    428     14        3        5     5        0      27
print("\n\n")
scorecard1,extras1=yka.teamBattingScorecardMatch(csk_kxip,"Kings XI Punjab")
print(scorecard1)
##       batsman  runs  balls  4s  6s          SR
## 0    V Sehwag   122     62  12   0  196.774194
## 1     M Vohra    34     33   1   0  103.030303
## 2  GJ Maxwell    13      8   1   0  162.500000
## 3   DA Miller    38     19   5   0  200.000000
## 4   GJ Bailey     1      2   0   0   50.000000
## 5     WP Saha     6      4   0   0  150.000000
## 6  MG Johnson     1      1   0   0  100.000000
print(extras1)
##    total  wides  noballs  legbyes  byes  penalty  extras
## 0    428     14        3        5     5        0      27

Let’s take another random match between Gujarat Lions and Mumbai Indian on 29 Apr 2017 Gujarat Lions-Mumbai Indians-2017-04-29

import pandas as pd
gl_mi=pd.read_csv(".\\Gujarat Lions-Mumbai Indians-2017-04-29.csv")
import yorkpy.analytics as yka
scorecard,extras=yka.teamBattingScorecardMatch(gl_mi,"Gujarat Lions")
print(scorecard)
##          batsman  runs  balls  4s  6s          SR
## 0   Ishan Kishan    48     38   6   0  126.315789
## 1    BB McCullum     6      4   1   0  150.000000
## 2       SK Raina     1      3   0   0   33.333333
## 3       AJ Finch     0      3   0   0    0.000000
## 4     KD Karthik     2      9   0   0   22.222222
## 5      RA Jadeja    28     22   2   0  127.272727
## 6    JP Faulkner    21     29   2   0   72.413793
## 7      IK Pathan     2      3   0   0   66.666667
## 8         AJ Tye    25     12   2   0  208.333333
## 9   Basil Thampi     2      4   0   0   50.000000
## 10    Ankit Soni     7      2   0   0  350.000000
print(extras)
##    total  wides  noballs  legbyes  byes  penalty  extras
## 0    306      8        3        1     0        0      12
print("\n\n")
scorecard1,extras1=yka.teamBattingScorecardMatch(gl_mi,"Mumbai Indians")
print(scorecard1)
##             batsman  runs  balls  4s  6s          SR
## 0          PA Patel    70     45   9   0  155.555556
## 1        JC Buttler     9      7   2   0  128.571429
## 2            N Rana    19     16   1   0  118.750000
## 3         RG Sharma     5     13   0   0   38.461538
## 4        KA Pollard    15     11   2   0  136.363636
## 5         KH Pandya    29     20   2   0  145.000000
## 6         HH Pandya     4      5   0   0   80.000000
## 7   Harbhajan Singh     0      1   0   0    0.000000
## 8    MJ McClenaghan     1      1   0   0  100.000000
## 9         JJ Bumrah     0      1   0   0    0.000000
## 10       SL Malinga     0      1   0   0    0.000000
print(extras1)
##    total  wides  noballs  legbyes  byes  penalty  extras
## 0    306      8        3        1     0        0      12

7. Plot the team batting partnerships

The functions below plot the team batting partnership in the match. It shows what the partnership were in the mtach

Note: Many of the plots include an additional parameters plot which is either True or False. The default value is plot=True. When plot=True the plot will be displayed. When plot=False the data frame will be returned to the user. The user can use this to create an interactive chart using one of the packages like rcharts, ggvis,googleVis or plotly.

import pandas as pd
import yorkpy.analytics as yka
dc_dd=pd.read_csv(".\\Deccan Chargers-Delhi Daredevils-2012-05-10.csv")
yka.teamBatsmenPartnershipMatch(dc_dd,'Deccan Chargers','Delhi Daredevils')

yka.teamBatsmenPartnershipMatch(dc_dd,'Delhi Daredevils','Deccan Chargers',plot=True)
# Print partnerships as a dataframe

rps_rcb=pd.read_csv(".\\Rising Pune Supergiant-Royal Challengers Bangalore-2017-04-29.csv")
m=yka.teamBatsmenPartnershipMatch(rps_rcb,'Royal Challengers Bangalore','Rising Pune Supergiant',plot=False)
print(m)
##            batsman     non_striker  runs
## 0   AB de Villiers         V Kohli     3
## 1         AF Milne         V Kohli     5
## 2        KM Jadhav         V Kohli     7
## 3           P Negi         V Kohli     3
## 4        S Aravind         V Kohli     0
## 5        S Aravind       YS Chahal     8
## 6         S Badree         V Kohli     2
## 7        STR Binny         V Kohli     1
## 8      Sachin Baby         V Kohli     2
## 9          TM Head         V Kohli     2
## 10         V Kohli  AB de Villiers    17
## 11         V Kohli        AF Milne     5
## 12         V Kohli       KM Jadhav     4
## 13         V Kohli          P Negi     9
## 14         V Kohli       S Aravind     2
## 15         V Kohli        S Badree     8
## 16         V Kohli     Sachin Baby     1
## 17         V Kohli         TM Head     9
## 18       YS Chahal       S Aravind     4

8. Batsmen vs Bowler

The function below computes and plots the performances of the batsmen vs the bowlers. As before the plot parameter can be set to True or False. By default it is plot=True

import pandas as pd
import yorkpy.analytics as yka
gl_mi=pd.read_csv(".\\Gujarat Lions-Mumbai Indians-2017-04-29.csv")
yka.teamBatsmenVsBowlersMatch(gl_mi,"Gujarat Lions","Mumbai Indians", plot=True)
# Print

csk_kxip=pd.read_csv(".\\Chennai Super Kings-Kings XI Punjab-2014-05-30.csv")
m=yka.teamBatsmenVsBowlersMatch(csk_kxip,'Chennai Super Kings','Kings XI Punjab',plot=False)
print(m)
##          batsman           bowler  runs
## 0    BB McCullum         AR Patel     4
## 1    BB McCullum       GJ Maxwell     1
## 2    BB McCullum  Karanveer Singh     6
## 3      DJ Hussey          P Awana     1
## 4       DR Smith       MG Johnson     7
## 5       DR Smith          P Awana     0
## 6       DR Smith   Sandeep Sharma     0
## 7   F du Plessis       MG Johnson     0
## 8      MM Sharma         AR Patel     0
## 9      MM Sharma       MG Johnson     0
## 10     MM Sharma          P Awana     1
## 11      MS Dhoni         AR Patel    12
## 12      MS Dhoni  Karanveer Singh     2
## 13      MS Dhoni       MG Johnson    11
## 14      MS Dhoni          P Awana    15
## 15      MS Dhoni   Sandeep Sharma     2
## 16      R Ashwin         AR Patel     1
## 17      R Ashwin  Karanveer Singh     4
## 18      R Ashwin       MG Johnson     1
## 19      R Ashwin          P Awana     1
## 20      R Ashwin   Sandeep Sharma     3
## 21     RA Jadeja         AR Patel     5
## 22     RA Jadeja       GJ Maxwell     3
## 23     RA Jadeja  Karanveer Singh    19
## 24     RA Jadeja          P Awana     0
## 25      SK Raina       MG Johnson    21
## 26      SK Raina          P Awana    40
## 27      SK Raina   Sandeep Sharma    26

9. Bowling Scorecard

This function provides the bowling performance, the number of overs bowled, maidens, runs conceded. wickets taken and economy rate for the IPL match

import pandas as pd
import yorkpy.analytics as yka
dc_dd=pd.read_csv(".\\Deccan Chargers-Delhi Daredevils-2012-05-10.csv")
a=yka.teamBowlingScorecardMatch(dc_dd,'Deccan Chargers')
print(a)
##        bowler  overs  runs  maidens  wicket  econrate
## 0  AD Russell      4    39        0       0      9.75
## 1   IK Pathan      4    46        0       1     11.50
## 2    M Morkel      4    32        0       1      8.00
## 3    S Nadeem      4    39        0       0      9.75
## 4    VR Aaron      4    30        0       2      7.50
rps_rcb=pd.read_csv(".\\Rising Pune Supergiant-Royal Challengers Bangalore-2017-04-29.csv")
b=yka.teamBowlingScorecardMatch(rps_rcb,'Royal Challengers Bangalore')
print(b)
##               bowler  overs  runs  maidens  wicket  econrate
## 0          DL Chahar      2    18        0       0      9.00
## 1       DT Christian      4    25        0       1      6.25
## 2        Imran Tahir      4    18        0       3      4.50
## 3         JD Unadkat      4    19        0       1      4.75
## 4        LH Ferguson      4     7        1       3      1.75
## 5  Washington Sundar      2     7        0       1      3.50

10. Wicket Kind

The plots below provide the kind of wicket taken by the bowler (caught, bowled, lbw etc.) for the IPL match

import pandas as pd
import yorkpy.analytics as yka
kkr_rr=pd.read_csv(".\\Kolkata Knight Riders-Rajasthan Royals-2010-04-17.csv")
yka.teamBowlingWicketKindMatch(kkr_rr,'Kolkata Knight Riders','Rajasthan Royals')

csk_kxip=pd.read_csv(".\\Chennai Super Kings-Kings XI Punjab-2014-05-30.csv")
m = yka.teamBowlingWicketKindMatch(csk_kxip,'Chennai Super Kings','Kings-Kings XI Punjab',plot=False)
print(m)
##             bowler     kind  player_out
## 0         AR Patel  run out           1
## 1         AR Patel  stumped           1
## 2  Karanveer Singh  run out           1
## 3       MG Johnson   caught           1
## 4          P Awana   caught           2
## 5   Sandeep Sharma   bowled           1

11. Wicket vs Runs conceded

The plots below provide the wickets taken and the runs conceded by the bowler in the IPL T20 match

import pandas as pd
import yorkpy.analytics as yka
dc_dd=pd.read_csv(".\\Deccan Chargers-Delhi Daredevils-2012-05-10.csv")
yka.teamBowlingWicketMatch(dc_dd,"Deccan Chargers", "Delhi Daredevils",plot=True)

print("\n\n")
rps_rcb=pd.read_csv(".\\Rising Pune Supergiant-Royal Challengers Bangalore-2017-04-29.csv")
a=yka.teamBowlingWicketMatch(rps_rcb,"Royal Challengers Bangalore", "Rising Pune Supergiant",plot=False)
print(a)
##               bowler      player_out  kind
## 0       DT Christian         V Kohli     1
## 1        Imran Tahir        AF Milne     1
## 2        Imran Tahir          P Negi     1
## 3        Imran Tahir        S Badree     1
## 4         JD Unadkat         TM Head     1
## 5        LH Ferguson  AB de Villiers     1
## 6        LH Ferguson       KM Jadhav     1
## 7        LH Ferguson       STR Binny     1
## 8  Washington Sundar     Sachin Baby     1

12. Bowler Vs Batsmen

The functions compute and display how the different bowlers of the IPL team performed against the batting opposition.

import pandas as pd
import yorkpy.analytics as yka
csk_kxip=pd.read_csv(".\\Chennai Super Kings-Kings XI Punjab-2014-05-30.csv")
yka.teamBowlersVsBatsmenMatch(csk_kxip,"Chennai Super Kings","Kings XI Punjab")

print("\n\n")
kkr_rr=pd.read_csv(".\\Kolkata Knight Riders-Rajasthan Royals-2010-04-17.csv")
m =yka.teamBowlersVsBatsmenMatch(kkr_rr,"Rajasthan Royals","Kolkata Knight Riders",plot=False)
print(m)
##        batsman      bowler  runs
## 0     AC Voges    AB Dinda     1
## 1     AC Voges  JD Unadkat     1
## 2     AC Voges   LR Shukla     1
## 3     AC Voges    M Kartik     5
## 4     AJ Finch    AB Dinda     3
## 5     AJ Finch  JD Unadkat     3
## 6     AJ Finch   LR Shukla    13
## 7     AJ Finch    M Kartik     2
## 8     AJ Finch     SE Bond     0
## 9      AS Raut    AB Dinda     1
## 10     AS Raut  JD Unadkat     1
## 11    FY Fazal    AB Dinda     1
## 12    FY Fazal   LR Shukla     3
## 13    FY Fazal    M Kartik     3
## 14    FY Fazal     SE Bond     6
## 15     NV Ojha    AB Dinda    10
## 16     NV Ojha  JD Unadkat     5
## 17     NV Ojha   LR Shukla     0
## 18     NV Ojha    M Kartik     1
## 19     NV Ojha     SE Bond     2
## 20     P Dogra  JD Unadkat     2
## 21     P Dogra   LR Shukla     5
## 22     P Dogra    M Kartik     1
## 23     P Dogra     SE Bond     0
## 24  SK Trivedi    AB Dinda     4
## 25    SK Warne    AB Dinda     2
## 26    SK Warne    M Kartik     1
## 27    SK Warne     SE Bond     0
## 28   SR Watson    AB Dinda     2
## 29   SR Watson  JD Unadkat    13
## 30   SR Watson   LR Shukla     1
## 31   SR Watson    M Kartik    18
## 32   SR Watson     SE Bond    10
## 33   YK Pathan  JD Unadkat     1
## 34   YK Pathan   LR Shukla     7

13. Match worm chart

The plots below provide the match worm graph for the IPL Twenty 20 matches

import pandas as pd
import yorkpy.analytics as yka
dc_dd=pd.read_csv(".\\Deccan Chargers-Delhi Daredevils-2012-05-10.csv")
yka.matchWormChart(dc_dd,"Deccan Chargers", "Delhi Daredevils")

gl_mi=pd.read_csv(".\\Gujarat Lions-Mumbai Indians-2017-04-29.csv")
yka.matchWormChart(gl_mi,"Mumbai Indians","Gujarat Lions")

Feel free to clone/download the code from Github yorkpy

Conclusion

This post included all functions between 2 IPL teams from the package yorkpy for IPL Twenty20 matches. As mentioned above the yaml match files have been already converted to dataframes and are available for download from Github at yorkpyData

After having used Python and R for analytics, Machine Learning and Deep Learning, I have now realized that neither language is superior or inferior. Both have, some good packages and some that are not so well suited.

To be continued. Watch this space!

You may also like
1.My book ‘Deep Learning from first principles:Second Edition’ now on Amazon
2.My book ‘Practical Machine Learning in R and Python: Second edition’ on Amazon
2. Cricpy takes a swing at the ODIs
3. Introducing cricket package yorkr: Part 1- Beaten by sheer pace!
4. Big Data-1: Move into the big league:Graduate from Python to Pyspark
5. Simulating an Edge Shape in Android

To see all posts click Index of posts

My book ‘Deep Learning from first principles:Second Edition’ now on Amazon


The second edition of my book ‘Deep Learning from first principles:Second Edition- In vectorized Python, R and Octave’, is now available on Amazon, in both paperback ($18.99)  and kindle ($9.99/Rs449/-)  versions. Since this book is almost 70% code, all functions, and code snippets have been formatted to use the fixed-width font ‘Lucida Console’. In addition line numbers have been added to all code snippets. This makes the code more organized and much more readable. I have also fixed typos in the book

Untitled



The book includes the following chapters

Table of Contents
Preface 4
Introduction 6
1. Logistic Regression as a Neural Network 8
2. Implementing a simple Neural Network 23
3. Building a L- Layer Deep Learning Network 48
4. Deep Learning network with the Softmax 85
5. MNIST classification with Softmax 103
6. Initialization, regularization in Deep Learning 121
7. Gradient Descent Optimization techniques 167
8. Gradient Check in Deep Learning 197
1. Appendix A 214
2. Appendix 1 – Logistic Regression as a Neural Network 220
3. Appendix 2 - Implementing a simple Neural Network 227
4. Appendix 3 - Building a L- Layer Deep Learning Network 240
5. Appendix 4 - Deep Learning network with the Softmax 259
6. Appendix 5 - MNIST classification with Softmax 269
7. Appendix 6 - Initialization, regularization in Deep Learning 302
8. Appendix 7 - Gradient Descent Optimization techniques 344
9. Appendix 8 – Gradient Check 405
References 475

Also see
1. My book ‘Practical Machine Learning in R and Python: Second edition’ on Amazon
2. The 3rd paperback & kindle editions of my books on Cricket, now on Amazon
3. De-blurring revisited with Wiener filter using OpenCV
4. TWS-4: Gossip protocol: Epidemics and rumors to the rescue
5. A Cloud medley with IBM Bluemix, Cloudant DB and Node.js
6. Practical Machine Learning with R and Python – Part 6
7. GooglyPlus: yorkr analyzes IPL players, teams, matches with plots and tables
8. Fun simulation of a Chain in Android

To see posts click Index of Posts

Big Data-2: Move into the big league:Graduate from R to SparkR


This post is a continuation of my earlier post Big Data-1: Move into the big league:Graduate from Python to Pyspark. While the earlier post discussed parallel constructs in Python and Pyspark, this post elaborates similar and key constructs in R and SparkR. While this post just focuses on the programming part of R and SparkR it is essential to understand and fully grasp the concept of Spark, RDD and how data is distributed across the clusters. This post like the earlier post shows how if you already have a good handle of R, you can easily graduate to Big Data with SparkR

Note 1: This notebook has also been published at Databricks community site Big Data-2: Move into the big league:Graduate from R to SparkR

Note 2: You can download this RMarkdown file from Github at Big Data- Python to Pyspark and R to SparkR
1a. Read CSV- R

Note: To upload the CSV to databricks see the video Upload Flat File to Databricks Table

# Read CSV file
tendulkar= read.csv("/dbfs/FileStore/tables/tendulkar.csv",stringsAsFactors = FALSE,na.strings=c(NA,"-"))
#Check the dimensions of the dataframe
dim(tendulkar)
[1] 347  12
1b. Read CSV – SparkR
# Load the SparkR library
library(SparkR)
# Initiate a SparkR session
sparkR.session()
tendulkar1 <- read.df("/FileStore/tables/tendulkar.csv",
                header = "true",
                delimiter = ",",
                source = "csv",
                inferSchema = "true",
                na.strings = "")

# Check the dimensions of the dataframe
dim(tendulkar1)
[1] 347  12
2a. Data frame shape – R
# Get the shape of the dataframe in R
dim(tendulkar)
[1] 347  12
2b. Dataframe shape – SparkR

The same ‘dim’ command works in SparkR too!

dim(tendulkar1)
[1] 347  12
3a . Dataframe columns – R
# Get the names
names(tendulkar) # Also colnames(tendulkar)
 [1] "Runs"       "Mins"       "BF"         "X4s"        "X6s"
 [6] "SR"         "Pos"        "Dismissal"  "Inns"       "Opposition"
[11] "Ground"     "Start.Date"
3b. Dataframe columns – SparkR
names(tendulkar1)
 [1] "Runs"       "Mins"       "BF"         "4s"         "6s"
 [6] "SR"         "Pos"        "Dismissal"  "Inns"       "Opposition"
[11] "Ground"     "Start Date"
4a. Rename columns – R
names(tendulkar)=c('Runs','Minutes','BallsFaced','Fours','Sixes','StrikeRate','Position','Dismissal','Innings','Opposition','Ground','StartDate')
names(tendulkar)
 [1] "Runs"       "Minutes"    "BallsFaced" "Fours"      "Sixes"
 [6] "StrikeRate" "Position"   "Dismissal"  "Innings"    "Opposition"
[11] "Ground"     "StartDate"
4b. Rename columns – SparkR
names(tendulkar1)=c('Runs','Minutes','BallsFaced','Fours','Sixes','StrikeRate','Position','Dismissal','Innings','Opposition','Ground','StartDate')
names(tendulkar1)
 [1] "Runs"       "Minutes"    "BallsFaced" "Fours"      "Sixes"
 [6] "StrikeRate" "Position"   "Dismissal"  "Innings"    "Opposition"
[11] "Ground"     "StartDate"
5a. Summary – R
summary(tendulkar)
     Runs              Minutes        BallsFaced         Fours
 Length:347         Min.   :  1.0   Min.   :  0.00   Min.   : 0.000
 Class :character   1st Qu.: 33.0   1st Qu.: 22.00   1st Qu.: 1.000
 Mode  :character   Median : 82.0   Median : 58.50   Median : 4.000
                    Mean   :125.5   Mean   : 89.75   Mean   : 6.274
                    3rd Qu.:181.0   3rd Qu.:133.25   3rd Qu.: 9.000
                    Max.   :613.0   Max.   :436.00   Max.   :35.000
                    NA's   :18      NA's   :19       NA's   :19
     Sixes          StrikeRate        Position     Dismissal
 Min.   :0.0000   Min.   :  0.00   Min.   :2.00   Length:347
 1st Qu.:0.0000   1st Qu.: 38.09   1st Qu.:4.00   Class :character
 Median :0.0000   Median : 52.25   Median :4.00   Mode  :character
 Mean   :0.2097   Mean   : 51.79   Mean   :4.24
 3rd Qu.:0.0000   3rd Qu.: 65.09   3rd Qu.:4.00
 Max.   :4.0000   Max.   :166.66   Max.   :7.00
 NA's   :18       NA's   :20       NA's   :18
    Innings       Opposition           Ground           StartDate
 Min.   :1.000   Length:347         Length:347         Length:347
 1st Qu.:1.000   Class :character   Class :character   Class :character
 Median :2.000   Mode  :character   Mode  :character   Mode  :character
 Mean   :2.376
 3rd Qu.:3.000
 Max.   :4.000
 NA's   :1
5b. Summary – SparkR
summary(tendulkar1)
SparkDataFrame[summary:string, Runs:string, Minutes:string, BallsFaced:string, Fours:string, Sixes:string, StrikeRate:string, Position:string, Dismissal:string, Innings:string, Opposition:string, Ground:string, StartDate:string]
6a. Displaying details of dataframe with str() – R
str(tendulkar)
'data.frame':	347 obs. of  12 variables:
 $ Runs      : chr  "15" "DNB" "59" "8" ...
 $ Minutes   : int  28 NA 254 24 124 74 193 1 50 324 ...
 $ BallsFaced: int  24 NA 172 16 90 51 134 1 44 266 ...
 $ Fours     : int  2 NA 4 1 5 5 6 0 3 5 ...
 $ Sixes     : int  0 NA 0 0 0 0 0 0 0 0 ...
 $ StrikeRate: num  62.5 NA 34.3 50 45.5 ...
 $ Position  : int  6 NA 6 6 7 6 6 6 6 6 ...
 $ Dismissal : chr  "bowled" NA "lbw" "run out" ...
 $ Innings   : int  2 4 1 3 1 1 3 2 3 1 ...
 $ Opposition: chr  "v Pakistan" "v Pakistan" "v Pakistan" "v Pakistan" ...
 $ Ground    : chr  "Karachi" "Karachi" "Faisalabad" "Faisalabad" ...
 $ StartDate : chr  "15-Nov-89" "15-Nov-89" "23-Nov-89" "23-Nov-89" ...
6b. Displaying details of dataframe with str() – SparkR
str(tendulkar1)
'SparkDataFrame': 12 variables:
 $ Runs      : chr "15" "DNB" "59" "8" "41" "35"
 $ Minutes   : chr "28" "-" "254" "24" "124" "74"
 $ BallsFaced: chr "24" "-" "172" "16" "90" "51"
 $ Fours     : chr "2" "-" "4" "1" "5" "5"
 $ Sixes     : chr "0" "-" "0" "0" "0" "0"
 $ StrikeRate: chr "62.5" "-" "34.3" "50" "45.55" "68.62"
 $ Position  : chr "6" "-" "6" "6" "7" "6"
 $ Dismissal : chr "bowled" "-" "lbw" "run out" "bowled" "lbw"
 $ Innings   : chr "2" "4" "1" "3" "1" "1"
 $ Opposition: chr "v Pakistan" "v Pakistan" "v Pakistan" "v Pakistan" "v Pakistan" "v Pakistan"
 $ Ground    : chr "Karachi" "Karachi" "Faisalabad" "Faisalabad" "Lahore" "Sialkot"
 $ StartDate : chr "15-Nov-89" "15-Nov-89" "23-Nov-89" "23-Nov-89" "1-Dec-89" "9-Dec-89"
7a. Head & tail -R
print(head(tendulkar),3)
print(tail(tendulkar),3)
 Runs Minutes BallsFaced Fours Sixes StrikeRate Position Dismissal Innings
1   15      28         24     2     0      62.50        6    bowled       2
2  DNB      NA         NA    NA    NA         NA       NA             4
3   59     254        172     4     0      34.30        6       lbw       1
4    8      24         16     1     0      50.00        6   run out       3
5   41     124         90     5     0      45.55        7    bowled       1
6   35      74         51     5     0      68.62        6       lbw       1
  Opposition     Ground StartDate
1 v Pakistan    Karachi 15-Nov-89
2 v Pakistan    Karachi 15-Nov-89
3 v Pakistan Faisalabad 23-Nov-89
4 v Pakistan Faisalabad 23-Nov-89
5 v Pakistan     Lahore  1-Dec-89
6 v Pakistan    Sialkot  9-Dec-89
    Runs Minutes BallsFaced Fours Sixes StrikeRate Position Dismissal Innings
342   37     125         81     5     0      45.67        4    caught       2
343   21      71         23     2     0      91.30        4   run out       4
344   32      99         53     5     0      60.37        4       lbw       2
345    1       8          5     0     0      20.00        4       lbw       4
346   10      41         24     2     0      41.66        4       lbw       2
347   74     150        118    12     0      62.71        4    caught       2
       Opposition  Ground StartDate
342   v Australia  Mohali 14-Mar-13
343   v Australia  Mohali 14-Mar-13
344   v Australia   Delhi 22-Mar-13
345   v Australia   Delhi 22-Mar-13
346 v West Indies Kolkata  6-Nov-13
347 v West Indies  Mumbai 14-Nov-13
7b. Head – SparkR
head(tendulkar1,3)
  Runs Minutes BallsFaced Fours Sixes StrikeRate Position Dismissal Innings
1   15      28         24     2     0       62.5        6    bowled       2
2  DNB       -          -     -     -          -        -         -       4
3   59     254        172     4     0       34.3        6       lbw       1
  Opposition     Ground StartDate
1 v Pakistan    Karachi 15-Nov-89
2 v Pakistan    Karachi 15-Nov-89
3 v Pakistan Faisalabad 23-Nov-89
8a. Determining the column types with sapply -R
sapply(tendulkar,class)
       Runs     Minutes  BallsFaced       Fours       Sixes  StrikeRate
"character"   "integer"   "integer"   "integer"   "integer"   "numeric"
   Position   Dismissal     Innings  Opposition      Ground   StartDate
  "integer" "character"   "integer" "character" "character" "character"
8b. Determining the column types with printSchema – SparkR
printSchema(tendulkar1)
root
 |-- Runs: string (nullable = true)
 |-- Minutes: string (nullable = true)
 |-- BallsFaced: string (nullable = true)
 |-- Fours: string (nullable = true)
 |-- Sixes: string (nullable = true)
 |-- StrikeRate: string (nullable = true)
 |-- Position: string (nullable = true)
 |-- Dismissal: string (nullable = true)
 |-- Innings: string (nullable = true)
 |-- Opposition: string (nullable = true)
 |-- Ground: string (nullable = true)
 |-- StartDate: string (nullable = true)
9a. Selecting columns – R
library(dplyr)
df=select(tendulkar,Runs,BallsFaced,Minutes)
head(df,5)
  Runs BallsFaced Minutes
1   15         24      28
2  DNB         NA      NA
3   59        172     254
4    8         16      24
5   41         90     124
9b. Selecting columns – SparkR
library(SparkR)
Sys.setenv(SPARK_HOME="/usr/hdp/2.6.0.3-8/spark")
.libPaths(c(file.path(Sys.getenv("SPARK_HOME"), "R", "lib"), .libPaths()))
# Initiate a SparkR session
sparkR.session()
tendulkar1 <- read.df("/FileStore/tables/tendulkar.csv",
                header = "true",
                delimiter = ",",
                source = "csv",
                inferSchema = "true",
                na.strings = "")
df=SparkR::select(tendulkar1, "Runs", "BF","Mins")
head(SparkR::collect(df))
  Runs  BF Mins
1   15  24   28
2  DNB   -    -
3   59 172  254
4    8  16   24
5   41  90  124
6   35  51   74
10a. Filter rows by criteria – R
library(dplyr)
df=tendulkar %>% filter(Runs > 50)
head(df,5)
  Runs Minutes BallsFaced Fours Sixes StrikeRate Position Dismissal Innings
1  DNB      NA         NA    NA    NA         NA       NA             4
2   59     254        172     4     0      34.30        6       lbw       1
3    8      24         16     1     0      50.00        6   run out       3
4   57     193        134     6     0      42.53        6    caught       3
5   88     324        266     5     0      33.08        6    caught       1
     Opposition     Ground StartDate
1    v Pakistan    Karachi 15-Nov-89
2    v Pakistan Faisalabad 23-Nov-89
3    v Pakistan Faisalabad 23-Nov-89
4    v Pakistan    Sialkot  9-Dec-89
5 v New Zealand     Napier  9-Feb-90
10b. Filter rows by criteria – SparkR
df=SparkR::filter(tendulkar1, tendulkar1$Runs > 50)
head(SparkR::collect(df))
  Runs Mins  BF 4s 6s    SR Pos Dismissal Inns     Opposition       Ground
1   59  254 172  4  0  34.3   6       lbw    1     v Pakistan   Faisalabad
2   57  193 134  6  0 42.53   6    caught    3     v Pakistan      Sialkot
3   88  324 266  5  0 33.08   6    caught    1  v New Zealand       Napier
4   68  216 136  8  0    50   6    caught    2      v England   Manchester
5  114  228 161 16  0  70.8   4    caught    2    v Australia        Perth
6  111  373 270 19  0 41.11   4    caught    2 v South Africa Johannesburg
  Start Date
1  23-Nov-89
2   9-Dec-89
3   9-Feb-90
4   9-Aug-90
5   1-Feb-92
6  26-Nov-92
11a. Unique values -R
unique(tendulkar$Runs)
  [1] "15"   "DNB"  "59"   "8"    "41"   "35"   "57"   "0"    "24"   "88"
 [11] "5"    "10"   "27"   "68"   "119*" "21"   "11"   "16"   "7"    "40"
 [21] "148*" "6"    "17"   "114"  "111"  "1"    "73"   "50"   "9*"   "165"
 [31] "78"   "62"   "TDNB" "28"   "104*" "71"   "142"  "96"   "43"   "11*"
 [41] "34"   "85"   "179"  "54"   "4"    "0*"   "52*"  "2"    "122"  "31"
 [51] "177"  "74"   "42"   "18"   "61"   "36"   "169"  "9"    "15*"  "92"
 [61] "83"   "143"  "139"  "23"   "148"  "13"   "155*" "79"   "47"   "113"
 [71] "67"   "136"  "29"   "53"   "124*" "126*" "44*"  "217"  "116"  "52"
 [81] "45"   "97"   "20"   "39"   "201*" "76"   "65"   "126"  "36*"  "69"
 [91] "155"  "22*"  "103"  "26"   "90"   "176"  "117"  "86"   "12"   "193"
[101] "16*"  "51"   "32"   "55"   "37"   "44"   "241*" "60*"  "194*" "3"
[111] "32*"  "248*" "94"   "22"   "109"  "19"   "14"   "28*"  "63"   "64"
[121] "101"  "122*" "91"   "82"   "56*"  "154*" "153"  "49"   "10*"  "103*"
[131] "160"  "100*" "105*" "100"  "106"  "84"   "203"  "98"   "38"   "214"
[141] "53*"  "111*" "146"  "14*"  "56"   "80"   "25"   "81"   "13*"
11b. Unique values – SparkR
head(SparkR::distinct(tendulkar1[,"Runs"]),5)
  Runs
1 119*
2    7
3   51
4  169
5  32*
12a. Aggregate – Mean, min and max – R
library(dplyr)
library(magrittr)
a <- tendulkar$Runs != "DNB"
tendulkar <- tendulkar[a,]
dim(tendulkar)

# Remove rows with 'TDNB'
c <- tendulkar$Runs != "TDNB"
tendulkar <- tendulkar[c,]

# Remove rows with absent
d <- tendulkar$Runs != "absent"
tendulkar <- tendulkar[d,]
dim(tendulkar)

# Remove the "* indicating not out
tendulkar$Runs <- as.numeric(gsub("\\*","",tendulkar$Runs))
c <- complete.cases(tendulkar)

#Subset the rows which are complete
tendulkar <- tendulkar[c,]
print(dim(tendulkar))
df <-tendulkar %>%  group_by(Ground) %>% summarise(meanRuns= mean(Runs), minRuns=min(Runs), maxRuns=max(Runs))
#names(tendulkar)
head(df)
[1] 327  12
# A tibble: 6 x 4
  Ground       meanRuns minRuns maxRuns

1 Adelaide        32.6       0.    153.
2 Ahmedabad       40.1       4.    217.
3 Auckland         5.00      5.      5.
4 Bangalore       57.9       4.    214.
5 Birmingham      46.8       1.    122.
6 Bloemfontein    85.0      15.    155.
12b. Aggregate- Mean, Min, Max – SparkR
sparkR.session()

tendulkar1 <- read.df("/FileStore/tables/tendulkar.csv",
                header = "true",
                delimiter = ",",
                source = "csv",
                inferSchema = "true",
                na.strings = "")

print(dim(tendulkar1))
tendulkar1 <-SparkR::filter(tendulkar1,tendulkar1$Runs != "DNB")
print(dim(tendulkar1))
tendulkar1<-SparkR::filter(tendulkar1,tendulkar1$Runs != "TDNB")
print(dim(tendulkar1))
tendulkar1<-SparkR::filter(tendulkar1,tendulkar1$Runs != "absent")
print(dim(tendulkar1))

# Cast the string type Runs to double
withColumn(tendulkar1, "Runs", cast(tendulkar1$Runs, "double"))
head(SparkR::distinct(tendulkar1[,"Runs"]),20)
# Remove the "* indicating not out
tendulkar1$Runs=SparkR::regexp_replace(tendulkar1$Runs, "\\*", "")
head(SparkR::distinct(tendulkar1[,"Runs"]),20)
df=SparkR::summarize(SparkR::groupBy(tendulkar1, tendulkar1$Ground), mean = mean(tendulkar1$Runs), minRuns=min(tendulkar1$Runs),maxRuns=max(tendulkar1$Runs))
head(df,20)
[1] 347  12
[1] 330  12
[1] 329  12
[1] 329  12
          Ground       mean minRuns maxRuns
1      Bangalore  54.312500       0      96
2       Adelaide  32.600000       0      61
3  Colombo (PSS)  37.200000      14      71
4   Christchurch  12.000000       0      24
5       Auckland   5.000000       5       5
6        Chennai  60.625000       0      81
7      Centurion  73.500000     111      36
8       Brisbane   7.666667       0       7
9     Birmingham  46.750000       1      40
10     Ahmedabad  40.125000     100       8
11 Colombo (RPS) 143.000000     143     143
12    Chittagong  57.800000     101      36
13     Cape Town  69.857143      14       9
14    Bridgetown  26.000000       0      92
15      Bulawayo  55.000000      36      74
16         Delhi  39.947368       0      76
17    Chandigarh  11.000000      11      11
18  Bloemfontein  85.000000      15     155
19 Colombo (SSC)  77.555556     104       8
20       Cuttack   2.000000       2       2
13a Using SQL with SparkR
sparkR.session()
tendulkar1 <- read.df("/FileStore/tables/tendulkar.csv",
                header = "true",
                delimiter = ",",
                source = "csv",
                inferSchema = "true",
                na.strings = "")

# Register this SparkDataFrame as a temporary view.
createOrReplaceTempView(tendulkar1, "tendulkar2")

# SQL statements can be run by using the sql method
df=SparkR::sql("SELECT * FROM tendulkar2 WHERE Ground='Karachi'")

head(df)

  Runs Mins BF 4s 6s    SR Pos Dismissal Inns Opposition  Ground Start Date
1   15   28 24  2  0  62.5   6    bowled    2 v Pakistan Karachi  15-Nov-89
2  DNB    -  -  -  -     -   -         -    4 v Pakistan Karachi  15-Nov-89
3   23   49 29  5  0 79.31   4    bowled    2 v Pakistan Karachi  29-Jan-06
4   26   74 47  5  0 55.31   4    bowled    4 v Pakistan Karachi  29-Jan-06
Conclusion

This post discusses some of the key constructs in R and SparkR and how one can transition from R to SparkR fairly easily. I will be adding more constructs later. Do check back!

You may also like
1. Exploring Quantum Gate operations with QCSimulator
2. Deep Learning from first principles in Python, R and Octave – Part 4
3. A Bluemix recipe with MongoDB and Node.js
4. Practical Machine Learning with R and Python – Part 5
5. Introducing cricketr! : An R package to analyze performances of cricketers

To see all posts click Index of posts

My book ‘Practical Machine Learning in R and Python: Second edition’ on Amazon


Note: The 3rd edition of this book is now available My book ‘Practical Machine Learning in R and Python: Third edition’ on Amazon

The third edition of my book ‘Practical Machine Learning with R and Python – Machine Learning in stereo’ is now available in both paperback ($12.99) and kindle ($9.99/Rs449) versions.  This second edition includes more content,  extensive comments and formatting for better readability.

In this book I implement some of the most common, but important Machine Learning algorithms in R and equivalent Python code.
1. Practical machine with R and Python: Third Edition – Machine Learning in Stereo(Paperback-$12.99)
2. Practical machine with R and Third Edition – Machine Learning in Stereo(Kindle- $9.99/Rs449)

This book is ideal both for beginners and the experts in R and/or Python. Those starting their journey into datascience and ML will find the first 3 chapters useful, as they touch upon the most important programming constructs in R and Python and also deal with equivalent statements in R and Python. Those who are expert in either of the languages, R or Python, will find the equivalent code ideal for brushing up on the other language. And finally,those who are proficient in both languages, can use the R and Python implementations to internalize the ML algorithms better.

Here is a look at the topics covered

Table of Contents
Preface …………………………………………………………………………….4
Introduction ………………………………………………………………………6
1. Essential R ………………………………………………………………… 8
2. Essential Python for Datascience ……………………………………………57
3. R vs Python …………………………………………………………………81
4. Regression of a continuous variable ……………………………………….101
5. Classification and Cross Validation ………………………………………..121
6. Regression techniques and regularization ………………………………….146
7. SVMs, Decision Trees and Validation curves ………………………………191
8. Splines, GAMs, Random Forests and Boosting ……………………………222
9. PCA, K-Means and Hierarchical Clustering ………………………………258
References ……………………………………………………………………..269

Pick up your copy today!!
Hope you have a great time learning as I did while implementing these algorithms!

Deep Learning from first principles in Python, R and Octave – Part 6


“Today you are You, that is truer than true. There is no one alive who is Youer than You.”
Dr. Seuss

“Explanations exist; they have existed for all time; there is always a well-known solution to every human problem — neat, plausible, and wrong.”
H L Mencken

Introduction

In this 6th instalment of ‘Deep Learning from first principles in Python, R and Octave-Part6’, I look at a couple of different initialization techniques used in Deep Learning, L2 regularization and the ‘dropout’ method. Specifically, I implement “He initialization” & “Xavier Initialization”. My earlier posts in this series of Deep Learning included

1. Part 1 – In the 1st part, I implemented logistic regression as a simple 2 layer Neural Network
2. Part 2 – In part 2, implemented the most basic of Neural Networks, with just 1 hidden layer, and any number of activation units in that hidden layer. The implementation was in vectorized Python, R and Octave
3. Part 3 -In part 3, I derive the equations and also implement a L-Layer Deep Learning network with either the relu, tanh or sigmoid activation function in Python, R and Octave. The output activation unit was a sigmoid function for logistic classification
4. Part 4 – This part looks at multi-class classification, and I derive the Jacobian of a Softmax function and implement a simple problem to perform multi-class classification.
5. Part 5 – In the 5th part, I extend the L-Layer Deep Learning network implemented in Part 3, to include the Softmax classification. I also use this L-layer implementation to classify MNIST handwritten digits with Python, R and Octave.

The code in Python, R and Octave are identical, and just take into account some of the minor idiosyncrasies of the individual language. In this post, I implement different initialization techniques (random, He, Xavier), L2 regularization and finally dropout. Hence my generic L-Layer Deep Learning network includes these additional enhancements for enabling/disabling initialization methods, regularization or dropout in the algorithm. It already included sigmoid & softmax output activation for binary and multi-class classification, besides allowing relu, tanh and sigmoid activation for hidden units.

This R Markdown file and the code for Python, R and Octave can be cloned/downloaded from Github at DeepLearning-Part6

Checkout my book ‘Deep Learning from first principles: Second Edition – In vectorized Python, R and Octave’. My book starts with the implementation of a simple 2-layer Neural Network and works its way to a generic L-Layer Deep Learning Network, with all the bells and whistles. The derivations have been discussed in detail. The code has been extensively commented and included in its entirety in the Appendix sections. My book is available on Amazon as paperback ($18.99) and in kindle version($9.99/Rs449).

You may also like my companion book “Practical Machine Learning with R and Python:Second Edition- Machine Learning in stereo” available in Amazon in paperback($10.99) and Kindle($7.99/Rs449) versions. This book is ideal for a quick reference of the various ML functions and associated measurements in both R and Python which are essential to delve deep into Deep Learning.

1. Initialization techniques

The usual initialization technique is to generate Gaussian or uniform random numbers and multiply it by a small value like 0.01. Two techniques which are used to speed up convergence is the He initialization or Xavier. These initialization techniques enable gradient descent to converge faster.

1.1 a Default initialization – Python

This technique just initializes the weights to small random values based on Gaussian or uniform distribution

import numpy as np
import matplotlib
import matplotlib.pyplot as plt
import sklearn.linear_model
import pandas as pd
import sklearn
import sklearn.datasets
exec(open("DLfunctions61.py").read())
#Load the data
train_X, train_Y, test_X, test_Y = load_dataset()
# Set the layers dimensions
layersDimensions = [2,7,1]

# Train a deep learning network with random initialization
parameters = L_Layer_DeepModel(train_X, train_Y, layersDimensions, hiddenActivationFunc='relu', outputActivationFunc="sigmoid",learningRate = 0.6, num_iterations = 9000, initType="default", print_cost = True,figure="fig1.png")

# Clear the plot
plt.clf()
plt.close()

# Plot the decision boundary
plot_decision_boundary(lambda x: predict(parameters, x.T), train_X, train_Y,str(0.6),figure1="fig2.png")

1.1 b He initialization – Python

‘He’ initialization attributed to He et al, multiplies the random weights by
\sqrt{\frac{2}{dimension\ of\ previous\ layer}}

import numpy as np
import matplotlib
import matplotlib.pyplot as plt
import sklearn.linear_model
import pandas as pd
import sklearn
import sklearn.datasets
exec(open("DLfunctions61.py").read())

#Load the data
train_X, train_Y, test_X, test_Y = load_dataset()
# Set the layers dimensions
layersDimensions = [2,7,1]

# Train a deep learning network with He  initialization
parameters = L_Layer_DeepModel(train_X, train_Y, layersDimensions, hiddenActivationFunc='relu', outputActivationFunc="sigmoid", learningRate =0.6,    num_iterations = 10000,initType="He",print_cost = True,                           figure="fig3.png")

plt.clf()
plt.close()
# Plot the decision boundary
plot_decision_boundary(lambda x: predict(parameters, x.T), train_X, train_Y,str(0.6),figure1="fig4.png")


1.1 c Xavier initialization – Python

Xavier  initialization multiply the random weights by
\sqrt{\frac{1}{dimension\ of\ previous\ layer}}

import numpy as np
import matplotlib
import matplotlib.pyplot as plt
import sklearn.linear_model
import pandas as pd
import sklearn
import sklearn.datasets
exec(open("DLfunctions61.py").read())

#Load the data
train_X, train_Y, test_X, test_Y = load_dataset()
# Set the layers dimensions
layersDimensions = [2,7,1]

# Train a L layer Deep Learning network
parameters = L_Layer_DeepModel(train_X, train_Y, layersDimensions, hiddenActivationFunc='relu', outputActivationFunc="sigmoid",
                            learningRate = 0.6,num_iterations = 10000, initType="Xavier",print_cost = True,
                            figure="fig5.png")

# Plot the decision boundary
plot_decision_boundary(lambda x: predict(parameters, x.T), train_X, train_Y,str(0.6),figure1="fig6.png")


1.2a Default initialization – R

source("DLfunctions61.R")
#Load the data
z <- as.matrix(read.csv("circles.csv",header=FALSE))
x <- z[,1:2]
y <- z[,3]
X <- t(x)
Y <- t(y)
#Set the layer dimensions
layersDimensions = c(2,11,1)
# Train a deep learning network
retvals = L_Layer_DeepModel(X, Y, layersDimensions,
                            hiddenActivationFunc='relu',
                            outputActivationFunc="sigmoid",
                            learningRate = 0.5,
                            numIterations = 8000,
                            initType="default",
                            print_cost = True)
#Plot the cost vs iterations
iterations <- seq(0,8000,1000)
costs=retvals$costs
df=data.frame(iterations,costs)
ggplot(df,aes(x=iterations,y=costs)) + geom_point() + geom_line(color="blue") +
 ggtitle("Costs vs iterations") + xlab("No of iterations") + ylab("Cost")

# Plot the decision boundary
plotDecisionBoundary(z,retvals,hiddenActivationFunc="relu",lr=0.5)

1.2b He initialization – R

The code for ‘He’ initilaization in R is included below

# He Initialization model for L layers
# Input : List of units in each layer
# Returns: Initial weights and biases matrices for all layers
# He initilization multiplies the random numbers with sqrt(2/layerDimensions[previouslayer])
HeInitializeDeepModel <- function(layerDimensions){
    set.seed(2)

    # Initialize empty list
    layerParams <- list()

    # Note the Weight matrix at layer 'l' is a matrix of size (l,l-1)
    # The Bias is a vectors of size (l,1)

    # Loop through the layer dimension from 1.. L
    # Indices in R start from 1
    for(l in 2:length(layersDimensions)){
        # Initialize a matrix of small random numbers of size l x l-1
        # Create random numbers of size  l x l-1
        w=rnorm(layersDimensions[l]*layersDimensions[l-1])

        # Create a weight matrix of size l x l-1 with this initial weights and
        # Add to list W1,W2... WL
        # He initialization - Divide by sqrt(2/layerDimensions[previous layer])
        layerParams[[paste('W',l-1,sep="")]] = matrix(w,nrow=layersDimensions[l],
                                                      ncol=layersDimensions[l-1])*sqrt(2/layersDimensions[l-1])
        layerParams[[paste('b',l-1,sep="")]] = matrix(rep(0,layersDimensions[l]),
                                                      nrow=layersDimensions[l],ncol=1)
    }
    return(layerParams)
}

The code in R below uses He initialization to learn the data

source("DLfunctions61.R")
# Load the data
z <- as.matrix(read.csv("circles.csv",header=FALSE))
x <- z[,1:2]
y <- z[,3]
X <- t(x)
Y <- t(y)
# Set the layer dimensions
layersDimensions = c(2,11,1)
# Train a deep learning network
retvals = L_Layer_DeepModel(X, Y, layersDimensions,
                            hiddenActivationFunc='relu',
                            outputActivationFunc="sigmoid",
                            learningRate = 0.5,
                            numIterations = 9000,
                            initType="He",
                            print_cost = True)
#Plot the cost vs iterations
iterations <- seq(0,9000,1000)
costs=retvals$costs
df=data.frame(iterations,costs)
ggplot(df,aes(x=iterations,y=costs)) + geom_point() + geom_line(color="blue") +
    ggtitle("Costs vs iterations") + xlab("No of iterations") + ylab("Cost")

# Plot the decision boundary
plotDecisionBoundary(z,retvals,hiddenActivationFunc="relu",0.5,lr=0.5)

1.2c Xavier initialization – R

## Xav initialization
# Set the layer dimensions
layersDimensions = c(2,11,1)
# Train a deep learning network
retvals = L_Layer_DeepModel(X, Y, layersDimensions,
                            hiddenActivationFunc='relu',
                            outputActivationFunc="sigmoid",
                            learningRate = 0.5,
                            numIterations = 9000,
                            initType="Xav",
                            print_cost = True)
#Plot the cost vs iterations
iterations <- seq(0,9000,1000)
costs=retvals$costs
df=data.frame(iterations,costs)
ggplot(df,aes(x=iterations,y=costs)) + geom_point() + geom_line(color="blue") +
    ggtitle("Costs vs iterations") + xlab("No of iterations") + ylab("Cost")

# Plot the decision boundary
plotDecisionBoundary(z,retvals,hiddenActivationFunc="relu",0.5)

1.3a Default initialization – Octave

source("DL61functions.m")
# Read the data
data=csvread("circles.csv");

X=data(:,1:2);
Y=data(:,3);
# Set the layer dimensions
layersDimensions = [2 11  1]; #tanh=-0.5(ok), #relu=0.1 best!

# Train a deep learning network
[weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions,
                               hiddenActivationFunc='relu',
                               outputActivationFunc="sigmoid",
                               learningRate = 0.5,
                               lambd=0,
                               keep_prob=1,
                               numIterations = 10000,
                               initType="default");
# Plot cost vs iterations
plotCostVsIterations(10000,costs)
#Plot decision boundary
plotDecisionBoundary(data,weights, biases,keep_prob=1, hiddenActivationFunc="relu")



1.3b He initialization – Octave

source("DL61functions.m")
#Load data
data=csvread("circles.csv");
X=data(:,1:2);
Y=data(:,3);
# Set the layer dimensions
layersDimensions = [2 11  1]; #tanh=-0.5(ok), #relu=0.1 best!

# Train a deep learning network
[weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions,
                               hiddenActivationFunc='relu',
                               outputActivationFunc="sigmoid",
                               learningRate = 0.5,
                               lambd=0,
                               keep_prob=1,
                               numIterations = 8000,
                               initType="He");
plotCostVsIterations(8000,costs)
#Plot decision boundary
plotDecisionBoundary(data,weights, biases,keep_prob=1,hiddenActivationFunc="relu")

1.3c Xavier initialization – Octave

The code snippet for Xavier initialization in Octave is shown below

source("DL61functions.m")
# Xavier Initialization for L layers
# Input : List of units in each layer
# Returns: Initial weights and biases matrices for all layers
function [W b] = XavInitializeDeepModel(layerDimensions)
    rand ("seed", 3);
    # note the Weight matrix at layer 'l' is a matrix of size (l,l-1)
    # The Bias is a vectors of size (l,1)

    # Loop through the layer dimension from 1.. L
    # Create cell arrays for Weights and biases

    for l =2:size(layerDimensions)(2)
         W{l-1} = rand(layerDimensions(l),layerDimensions(l-1))* sqrt(1/layerDimensions(l-1)); #  Multiply by .01
         b{l-1} = zeros(layerDimensions(l),1);

    endfor
end

The Octave code below uses Xavier initialization

source("DL61functions.m")
#Load data
data=csvread("circles.csv");
X=data(:,1:2);
Y=data(:,3);
#Set layer dimensions
layersDimensions = [2 11 1]; #tanh=-0.5(ok), #relu=0.1 best!

# Train a deep learning network
[weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions,
hiddenActivationFunc='relu',
outputActivationFunc="sigmoid",
learningRate = 0.5,
lambd=0,
keep_prob=1,
numIterations = 8000,
initType="Xav");

plotCostVsIterations(8000,costs)
plotDecisionBoundary(data,weights, biases,keep_prob=1,hiddenActivationFunc="relu")





2.1a Regularization : Circles data – Python

The cross entropy cost for Logistic classification is given as J = \frac{1}{m}\sum_{i=1}^{m}y^{i}log((a^{L})^{(i)}) - (1-y^{i})log((a^{L})^{(i)}) The regularized L2 cost is given by J = \frac{1}{m}\sum_{i=1}^{m}y^{i}log((a^{L})^{(i)}) - (1-y^{i})log((a^{L})^{(i)}) + \frac{\lambda}{2m}\sum \sum \sum W_{kj}^{l}

import numpy as np
import matplotlib
import matplotlib.pyplot as plt
import sklearn.linear_model
import pandas as pd
import sklearn
import sklearn.datasets
exec(open("DLfunctions61.py").read())

#Load the data
train_X, train_Y, test_X, test_Y = load_dataset()
# Set the layers dimensions
layersDimensions = [2,7,1]

# Train a deep learning network
parameters = L_Layer_DeepModel(train_X, train_Y, layersDimensions, hiddenActivationFunc='relu',
                               outputActivationFunc="sigmoid",learningRate = 0.6, lambd=0.1, num_iterations = 9000,
                               initType="default", print_cost = True,figure="fig7.png")

# Clear the plot
plt.clf()
plt.close()

# Plot the decision boundary
plot_decision_boundary(lambda x: predict(parameters, x.T), train_X, train_Y,str(0.6),figure1="fig8.png")


plt.clf()
plt.close()
#Plot the decision boundary
plot_decision_boundary(lambda x: predict(parameters, x.T,keep_prob=0.9), train_X, train_Y,str(2.2),"fig8.png",)

2.1 b Regularization: Spiral data  – Python

import numpy as np
import matplotlib
import matplotlib.pyplot as plt
import sklearn.linear_model
import pandas as pd
import sklearn
import sklearn.datasets
exec(open("DLfunctions61.py").read())
N = 100 # number of points per class
D = 2 # dimensionality
K = 3 # number of classes
X = np.zeros((N*K,D)) # data matrix (each row = single example)
y = np.zeros(N*K, dtype='uint8') # class labels
for j in range(K):
  ix = range(N*j,N*(j+1))
  r = np.linspace(0.0,1,N) # radius
  t = np.linspace(j*4,(j+1)*4,N) + np.random.randn(N)*0.2 # theta
  X[ix] = np.c_[r*np.sin(t), r*np.cos(t)]
  y[ix] = j


# Plot the data
plt.scatter(X[:, 0], X[:, 1], c=y, s=40, cmap=plt.cm.Spectral)
plt.clf()
plt.close()
#Set layer dimensions
layersDimensions = [2,100,3]
y1=y.reshape(-1,1).T
# Train a deep learning network
parameters = L_Layer_DeepModel(X.T, y1, layersDimensions, hiddenActivationFunc='relu', outputActivationFunc="softmax",
                           learningRate = 1,lambd=1e-3, num_iterations = 5000, print_cost = True,figure="fig9.png")

plt.clf()
plt.close()
W1=parameters['W1']
b1=parameters['b1']
W2=parameters['W2']
b2=parameters['b2']
plot_decision_boundary1(X, y1,W1,b1,W2,b2,figure2="fig10.png")



2.2a Regularization: Circles data  – R

source("DLfunctions61.R")
#Load data
df=read.csv("circles.csv",header=FALSE)
z <- as.matrix(read.csv("circles.csv",header=FALSE))
x <- z[,1:2]
y <- z[,3]
X <- t(x)
Y <- t(y)
#Set layer dimensions
layersDimensions = c(2,11,1)
# Train a deep learning network
retvals = L_Layer_DeepModel(X, Y, layersDimensions,
                            hiddenActivationFunc='relu',
                            outputActivationFunc="sigmoid",
                            learningRate = 0.5,
                            lambd=0.1,
                            numIterations = 9000,
                            initType="default",
                            print_cost = True)
#Plot the cost vs iterations
iterations <- seq(0,9000,1000)
costs=retvals$costs
df=data.frame(iterations,costs)
ggplot(df,aes(x=iterations,y=costs)) + geom_point() + geom_line(color="blue") +
    ggtitle("Costs vs iterations") + xlab("No of iterations") + ylab("Cost")

# Plot the decision boundary
plotDecisionBoundary(z,retvals,hiddenActivationFunc="relu",0.5)

2.2b Regularization:Spiral data – R

# Read the spiral dataset
#Load the data
source("DLfunctions61.R")
Z <- as.matrix(read.csv("spiral.csv",header=FALSE))

# Setup the data
X <- Z[,1:2]
y <- Z[,3]
X <- t(X)
Y <- t(y)
layersDimensions = c(2, 100, 3)
# Train a deep learning network
retvals = L_Layer_DeepModel(X, Y, layersDimensions,
hiddenActivationFunc='relu',
outputActivationFunc="softmax",
learningRate = 0.5,
lambd=0.01,
numIterations = 9000,
print_cost = True)
print_cost = True)
parameters<-retvals$parameters
plotDecisionBoundary1(Z,parameters)


2.3a Regularization: Circles data – Octave

source("DL61functions.m")
#Load data
data=csvread("circles.csv");
X=data(:,1:2);
Y=data(:,3);
layersDimensions = [2 11  1]; #tanh=-0.5(ok), #relu=0.1 best!

# Train a deep learning network
[weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions,
                               hiddenActivationFunc='relu',
                               outputActivationFunc="sigmoid",
                               learningRate = 0.5,
                               lambd=0.2,
                               keep_prob=1,
                               numIterations = 8000,
                               initType="default");

plotCostVsIterations(8000,costs)
#Plot decision boundary
plotDecisionBoundary(data,weights, biases,keep_prob=1,hiddenActivationFunc="relu")

2.3b Regularization:Spiral data  2 – Octave

source("DL61functions.m")
data=csvread("spiral.csv");

# Setup the data
X=data(:,1:2);
Y=data(:,3);
layersDimensions = [2 100 3]
# Train a deep learning network
[weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions,
                               hiddenActivationFunc='relu',
                               outputActivationFunc="softmax",
                               learningRate = 0.6,
                               lambd=0.2,
                               keep_prob=1,
                               numIterations = 10000);

plotCostVsIterations(10000,costs)
#Plot decision boundary
plotDecisionBoundary1(data,weights, biases,keep_prob=1,hiddenActivationFunc="relu")

3.1 a Dropout: Circles data – Python

The ‘dropout’ regularization technique was used with great effectiveness, to prevent overfitting  by Alex Krizhevsky, Ilya Sutskever and Prof Geoffrey E. Hinton in the Imagenet classification with Deep Convolutional Neural Networks

The technique of dropout works by dropping a random set of activation units in each hidden layer, based on a ‘keep_prob’ criteria in the forward propagation cycle. Here is the code for Octave. A ‘dropoutMat’ is created for each layer which specifies which units to drop Note: The same ‘dropoutMat has to be used which computing the gradients in the backward propagation cycle. Hence the dropout matrices are stored in a cell array.

 for l =1:L-1
    ...
    D=rand(size(A)(1),size(A)(2));
    D = (D < keep_prob) ;
    # Zero out some hidden units
    A= A .* D;
    # Divide by keep_prob to keep the expected value of A the same
    A = A ./ keep_prob;
    # Store D in a dropoutMat cell array
    dropoutMat{l}=D;
    ...
 endfor

In the backward propagation cycle we have

    for l =(L-1):-1:1
          ...
          D = dropoutMat{l};
          # Zero out the dAl based on same dropout matrix
          dAl= dAl .* D;
          # Divide by keep_prob to maintain the expected value
          dAl = dAl ./ keep_prob;
          ...
    endfor
import numpy as np
import matplotlib
import matplotlib.pyplot as plt
import sklearn.linear_model
import pandas as pd
import sklearn
import sklearn.datasets
exec(open("DLfunctions61.py").read())
#Load the data
train_X, train_Y, test_X, test_Y = load_dataset()
# Set the layers dimensions
layersDimensions = [2,7,1]

# Train a deep learning network
parameters = L_Layer_DeepModel(train_X, train_Y, layersDimensions, hiddenActivationFunc='relu',
                               outputActivationFunc="sigmoid",learningRate = 0.6, keep_prob=0.7, num_iterations = 9000,
                               initType="default", print_cost = True,figure="fig11.png")

# Clear the plot
plt.clf()
plt.close()

# Plot the decision boundary
plot_decision_boundary(lambda x: predict(parameters, x.T,keep_prob=0.7), train_X, train_Y,str(0.6),figure1="fig12.png")

3.1b Dropout: Spiral data – Python

import numpy as np
import matplotlib
import matplotlib.pyplot as plt
import sklearn.linear_model
import pandas as pd
import sklearn
import sklearn.datasets
exec(open("DLfunctions61.py").read())
# Create an input data set - Taken from CS231n Convolutional Neural networks,
# http://cs231n.github.io/neural-networks-case-study/


N = 100 # number of points per class
D = 2 # dimensionality
K = 3 # number of classes
X = np.zeros((N*K,D)) # data matrix (each row = single example)
y = np.zeros(N*K, dtype='uint8') # class labels
for j in range(K):
  ix = range(N*j,N*(j+1))
  r = np.linspace(0.0,1,N) # radius
  t = np.linspace(j*4,(j+1)*4,N) + np.random.randn(N)*0.2 # theta
  X[ix] = np.c_[r*np.sin(t), r*np.cos(t)]
  y[ix] = j


# Plot the data
plt.scatter(X[:, 0], X[:, 1], c=y, s=40, cmap=plt.cm.Spectral)
plt.clf()
plt.close()
layersDimensions = [2,100,3]
y1=y.reshape(-1,1).T
# Train a deep learning network
parameters = L_Layer_DeepModel(X.T, y1, layersDimensions, hiddenActivationFunc='relu', outputActivationFunc="softmax",
                           learningRate = 1,keep_prob=0.9, num_iterations = 5000, print_cost = True,figure="fig13.png")

plt.clf()
plt.close()
W1=parameters['W1']
b1=parameters['b1']
W2=parameters['W2']
b2=parameters['b2']
#Plot decision boundary
plot_decision_boundary1(X, y1,W1,b1,W2,b2,figure2="fig14.png")

3.2a Dropout: Circles data – R

source("DLfunctions61.R")
#Load data
df=read.csv("circles.csv",header=FALSE)
z <- as.matrix(read.csv("circles.csv",header=FALSE))

x <- z[,1:2]
y <- z[,3]
X <- t(x)
Y <- t(y)
layersDimensions = c(2,11,1)
# Train a deep learning network
retvals = L_Layer_DeepModel(X, Y, layersDimensions,
                            hiddenActivationFunc='relu',
                            outputActivationFunc="sigmoid",
                            learningRate = 0.5,
                            keep_prob=0.8,
                            numIterations = 9000,
                            initType="default",
                            print_cost = True)
# Plot the decision boundary
plotDecisionBoundary(z,retvals,keep_prob=0.6, hiddenActivationFunc="relu",0.5)

3.2b Dropout: Spiral data – R

# Read the spiral dataset
source("DLfunctions61.R")
# Load data
Z <- as.matrix(read.csv("spiral.csv",header=FALSE))

# Setup the data
X <- Z[,1:2]
y <- Z[,3]
X <- t(X)
Y <- t(y)

# Train a deep learning network
retvals = L_Layer_DeepModel(X, Y, layersDimensions,
                            hiddenActivationFunc='relu',
                            outputActivationFunc="softmax",
                            learningRate = 0.1,
                            keep_prob=0.90,
                            numIterations = 9000,
                            print_cost = True)

parameters<-retvals$parameters
#Plot decision boundary
plotDecisionBoundary1(Z,parameters)

3.3a Dropout: Circles data – Octave

data=csvread("circles.csv");

X=data(:,1:2);
Y=data(:,3);
layersDimensions = [2 11  1]; #tanh=-0.5(ok), #relu=0.1 best!

# Train a deep learning network
[weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions,
                               hiddenActivationFunc='relu',
                               outputActivationFunc="sigmoid",
                               learningRate = 0.5,
                               lambd=0,
                               keep_prob=0.8,
                               numIterations = 10000,
                               initType="default");
plotCostVsIterations(10000,costs)
#Plot decision boundary
plotDecisionBoundary1(data,weights, biases,keep_prob=1, hiddenActivationFunc="relu")

3.3b Dropout  Spiral data – Octave

source("DL61functions.m")
data=csvread("spiral.csv");

# Setup the data
X=data(:,1:2);
Y=data(:,3);

layersDimensions = [numFeats numHidden  numOutput];
# Train a deep learning network
[weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions,
                               hiddenActivationFunc='relu',
                               outputActivationFunc="softmax",
                               learningRate = 0.1,
                               lambd=0,
                               keep_prob=0.8,
                               numIterations = 10000);

plotCostVsIterations(10000,costs)
#Plot decision boundary
plotDecisionBoundary1(data,weights, biases,keep_prob=1, hiddenActivationFunc="relu")

Note: The Python, R and Octave code can be cloned/downloaded from Github at DeepLearning-Part6
Conclusion
This post further enhances my earlier L-Layer generic implementation of a Deep Learning network to include options for initialization techniques, L2 regularization or dropout regularization

References
1. Deep Learning Specialization
2. Neural Networks for Machine Learning

Also see
1. Architecting a cloud based IP Multimedia System (IMS)
2. Using Linear Programming (LP) for optimizing bowling change or batting lineup in T20 cricket
3. My book ‘Practical Machine Learning with R and Python’ on Amazon
4. Simulating a Web Joint in Android
5. Inswinger: yorkr swings into International T20s
6. Introducing QCSimulator: A 5-qubit quantum computing simulator in R
7. Computer Vision: Ramblings on derivatives, histograms and contours
8. Bend it like Bluemix, MongoDB using Auto-scale – Part 1!
9. The 3rd paperback & kindle editions of my books on Cricket, now on Amazon

To see all posts click Index of posts

Deep Learning from first principles in Python, R and Octave – Part 4


In this 4th post of my series on Deep Learning from first principles in Python, R and Octave – Part 4, I explore the details of creating a multi-class classifier using the Softmax activation unit in a neural network. The earlier posts in this series were

1. Deep Learning from first principles in Python, R and Octave – Part 1. In this post I implemented logistic regression as a simple Neural Network in vectorized Python, R and Octave
2. Deep Learning from first principles in Python, R and Octave – Part 2. This 2nd part implemented the most elementary neural network with 1 hidden layer and any number of activation units in the hidden layer with sigmoid activation at the output layer
3. Deep Learning from first principles in Python, R and Octave – Part 3. The 3rd implemented a multi-layer Deep Learning network with an arbitrary number if hidden layers and activation units per hidden layer. The output layer was for binary classification which was based on the sigmoid unit. This multi-layer deep network was implemented in vectorized Python, R and Octave.

Checkout my book ‘Deep Learning from first principles: Second Edition – In vectorized Python, R and Octave’. My book starts with the implementation of a simple 2-layer Neural Network and works its way to a generic L-Layer Deep Learning Network, with all the bells and whistles. The derivations have been discussed in detail. The code has been extensively commented and included in its entirety in the Appendix sections. My book is available on Amazon as paperback ($18.99) and in kindle version($9.99/Rs449).

This 4th part takes a swing at multi-class classification and uses the Softmax as the activation unit in the output layer. Inclusion of the Softmax activation unit in the activation layer requires us to compute the derivative of Softmax, or rather the “Jacobian” of the Softmax function, besides also computing the log loss for this Softmax activation during back propagation. Since the derivation of the Jacobian of a Softmax and the computation of the Cross Entropy/log loss is very involved, I have implemented a basic neural network with just 1 hidden layer with the Softmax activation at the output layer. I also perform multi-class classification based on the ‘spiral’ data set from CS231n Convolutional Neural Networks Stanford course, to test the performance and correctness of the implementations in Python, R and Octave. You can clone download the code for the Python, R and Octave implementations from Github at Deep Learning – Part 4

Note: A detailed discussion of the derivation below can also be seen in my video presentation Neural Networks 5

The Softmax function takes an N dimensional vector as input and generates a N dimensional vector as output.
The Softmax function is given by
S_{j}= \frac{e_{j}}{\sum_{i}^{N}e_{k}}
There is a probabilistic interpretation of the Softmax, since the sum of the Softmax values of a set of vectors will always add up to 1, given that each Softmax value is divided by the total of all values.

As mentioned earlier, the Softmax takes a vector input and returns a vector of outputs.  For e.g. the Softmax of a vector a=[1, 3, 6]  is another vector S=[0.0063,0.0471,0.9464]. Notice that vector output is proportional to the input vector.  Also, taking the derivative of a vector by another vector, is known as the Jacobian. By the way, The Matrix Calculus You Need For Deep Learning by Terence Parr and Jeremy Howard, is very good paper that distills all the main mathematical concepts for Deep Learning in one place.

Let us take a simple 2 layered neural network with just 2 activation units in the hidden layer is shown below

Z_{1}^{1} =W_{11}^{1}x_{1} + W_{21}^{1}x_{2} + b_{1}^{1}
Z_{2}^{1} =W_{12}^{1}x_{1} + W_{22}^{1}x_{2} + b_{2}^{1}
and
A_{1}^{1} = g'(Z_{1}^{1})
A_{2}^{1} = g'(Z_{2}^{1})
where g'() is the activation unit in the hidden layer which can be a relu, sigmoid or a
tanh function

Note: The superscript denotes the layer. The above denotes the equation for layer 1
of the neural network. For layer 2 with the Softmax activation, the equations are
Z_{1}^{2} =W_{11}^{2}x_{1} + W_{21}^{2}x_{2} + b_{1}^{2}
Z_{2}^{2} =W_{12}^{2}x_{1} + W_{22}^{2}x_{2} + b_{2}^{2}
and
A_{1}^{2} = S(Z_{1}^{2})
A_{2}^{2} = S(Z_{2}^{2})
where S() is the Softmax activation function
S=\begin{pmatrix} S(Z_{1}^{2})\\ S(Z_{2}^{2}) \end{pmatrix}
S=\begin{pmatrix} \frac{e^{Z1}}{e^{Z1}+e^{Z2}}\\ \frac{e^{Z2}}{e^{Z1}+e^{Z2}} \end{pmatrix}

The Jacobian of the softmax ‘S’ is given by
\begin{pmatrix} \frac {\partial S_{1}}{\partial Z_{1}} & \frac {\partial S_{1}}{\partial Z_{2}}\\ \frac {\partial S_{2}}{\partial Z_{1}} & \frac {\partial S_{2}}{\partial Z_{2}} \end{pmatrix}
\begin{pmatrix} \frac{\partial}{\partial Z_{1}} \frac {e^{Z1}}{e^{Z1}+ e^{Z2}} & \frac{\partial}{\partial Z_{2}} \frac {e^{Z1}}{e^{Z1}+ e^{Z2}}\\ \frac{\partial}{\partial Z_{1}} \frac {e^{Z2}}{e^{Z1}+ e^{Z2}} & \frac{\partial}{\partial Z_{2}} \frac {e^{Z2}}{e^{Z1}+ e^{Z2}} \end{pmatrix}     – (A)

Now the ‘division-rule’  of derivatives is as follows. If u and v are functions of x, then
\frac{d}{dx} \frac {u}{v} =\frac {vdu -udv}{v^{2}}
Using this to compute each element of the above Jacobian matrix, we see that
when i=j we have
\frac {\partial}{\partial Z1}\frac{e^{Z1}}{e^{Z1}+e^{Z2}} = \frac {\sum e^{Z1} - e^{Z1^{2}}}{\sum ^{2}}
and when i \neq j
\frac {\partial}{\partial Z1}\frac{e^{Z2}}{e^{Z1}+e^{Z2}} = \frac {0 - e^{z1}e^{Z2}}{\sum ^{2}}
This is of the general form
\frac {\partial S_{j}}{\partial z_{i}} = S_{i}( 1-S_{j})  when i=j
and
\frac {\partial S_{j}}{\partial z_{i}} = -S_{i}S_{j}  when i \neq j
Note: Since the Softmax essentially gives the probability the following
notation is also used
\frac {\partial p_{j}}{\partial z_{i}} = p_{i}( 1-p_{j}) when i=j
and
\frac {\partial p_{j}}{\partial z_{i}} = -p_{i}p_{j} when i \neq j
If you throw the “Kronecker delta” into the equation, then the above equations can be expressed even more concisely as
\frac {\partial p_{j}}{\partial z_{i}} = p_{i} (\delta_{ij} - p_{j})
where \delta_{ij} = 1 when i=j and 0 when i \neq j

This reduces the Jacobian of the simple 2 output softmax vectors  equation (A) as
\begin{pmatrix} p_{1}(1-p_{1}) & -p_{1}p_{2} \\ -p_{2}p_{1} & p_{2}(1-p_{2}) \end{pmatrix}
The loss of Softmax is given by
L = -\sum y_{i} log(p_{i})
For the 2 valued Softmax output this is
\frac {dL}{dp1} = -\frac {y_{1}}{p_{1}}
\frac {dL}{dp2} = -\frac {y_{2}}{p_{2}}
Using the chain rule we can write
\frac {\partial L}{\partial w_{pq}} = \sum _{i}\frac {\partial L}{\partial p_{i}} \frac {\partial p_{i}}{\partial w_{pq}} (1)
and
\frac {\partial p_{i}}{\partial w_{pq}} = \sum _{k}\frac {\partial p_{i}}{\partial z_{k}} \frac {\partial z_{k}}{\partial w_{pq}} (2)
In expanded form this is
\frac {\partial L}{\partial w_{pq}} = \sum _{i}\frac {\partial L}{\partial p_{i}} \sum _{k}\frac {\partial p_{i}}{\partial z_{k}} \frac {\partial z_{k}}{\partial w_{pq}}
Also
\frac {\partial L}{\partial Z_{i}} =\sum _{i} \frac {\partial L}{\partial p} \frac {\partial p}{\partial Z_{i}}
Therefore
\frac {\partial L}{\partial Z_{1}} =\frac {\partial L}{\partial p_{1}} \frac {\partial p_{1}}{\partial Z_{1}} +\frac {\partial L}{\partial p_{2}} \frac {\partial p_{2}}{\partial Z_{1}}
\frac {\partial L}{\partial z_{1}}=-\frac {y1}{p1} p1(1-p1) - \frac {y2}{p2}*(-p_{2}p_{1})
Since
\frac {\partial p_{j}}{\partial z_{i}} = p_{i}( 1-p_{j}) when i=j
and
\frac {\partial p_{j}}{\partial z_{i}} = -p_{i}p_{j} when i \neq j
which simplifies to
\frac {\partial L}{\partial Z_{1}} = -y_{1} + y_{1}p_{1} + y_{2}p_{1} =
p_{1}\sum (y_{1} + y_2) - y_{1}
\frac {\partial L}{\partial Z_{1}}= p_{1} - y_{1}
Since
\sum_{i} y_{i} =1
Similarly
\frac {\partial L}{\partial Z_{2}} =\frac {\partial L}{\partial p_{1}} \frac {\partial p_{1}}{\partial Z_{2}} +\frac {\partial L}{\partial p_{2}} \frac {\partial p_{2}}{\partial Z_{2}}
\frac {\partial L}{\partial z_{2}}=-\frac {y1}{p1}*(p_{1}p_{2}) - \frac {y2}{p2}*p_{2}(1-p_{2})
y_{1}p_{2} + y_{2}p_{2} - y_{2}
\frac {\partial L}{\partial Z_{2}} =p_{2}\sum (y_{1} + y_2) - y_{2}\\ = p_{2} - y_{2}
In general this is of the form
\frac {\partial L}{\partial z_{i}} = p_{i} -y_{i}
For e.g if the probabilities computed were p=[0.1, 0.7, 0.2] then this implies that the class with probability 0.7 is the likely class. This would imply that the ‘One hot encoding’ for  yi  would be yi=[0,1,0] therefore the gradient pi-yi = [0.1,-0.3,0.2]

<strong>Note: Further, we could extend this derivation for a Softmax activation output that outputs 3 classes
S=\begin{pmatrix} \frac{e^{z1}}{e^{z1}+e^{z2}+e^{z3}}\\ \frac{e^{z2}}{e^{z1}+e^{z2}+e^{z3}} \\ \frac{e^{z3}}{e^{z1}+e^{z2}+e^{z3}} \end{pmatrix}

We could derive
\frac {\partial L}{\partial z1}= \frac {\partial L}{\partial p_{1}} \frac {\partial p_{1}}{\partial z_{1}} +\frac {\partial L}{\partial p_{2}} \frac {\partial p_{2}}{\partial z_{1}} +\frac {\partial L}{\partial p_{3}} \frac {\partial p_{3}}{\partial z_{1}} which similarly reduces to
\frac {\partial L}{\partial z_{1}}=-\frac {y1}{p1} p1(1-p1) - \frac {y2}{p2}*(-p_{2}p_{1}) - \frac {y3}{p3}*(-p_{3}p_{1})
-y_{1}+ y_{1}p_{1} + y_{2}p_{1} + y_{3}p1 = p_{1}\sum (y_{1} + y_2 + y_3) - y_{1} = p_{1} - y_{1}
Interestingly, despite the lengthy derivations the final result is simple and intuitive!

As seen in my post ‘Deep Learning from first principles with Python, R and Octave – Part 3 the key equations for forward and backward propagation are

Forward propagation equations layer 1
Z_{1} = W_{1}X +b_{1}     and  A_{1} = g(Z_{1})
Forward propagation equations layer 1
Z_{2} = W_{2}A_{1} +b_{2}  and  A_{2} = S(Z_{2})

Using the result (A) in the back propagation equations below we have
Backward propagation equations layer 2
\partial L/\partial W_{2} =\partial L/\partial Z_{2}*A_{1}=(p_{2}-y_{2})*A_{1}
\partial L/\partial b_{2} =\partial L/\partial Z_{2}=p_{2}-y_{2}
\partial L/\partial A_{1} = \partial L/\partial Z_{2} * W_{2}=(p_{2}-y_{2})*W_{2}
Backward propagation equations layer 1
\partial L/\partial W_{1} =\partial L/\partial Z_{1} *A_{0}=(p_{1}-y_{1})*A_{0}
\partial L/\partial b_{1} =\partial L/\partial Z_{1}=(p_{1}-y_{1})

2.0 Spiral data set

As I mentioned earlier, I will be using the ‘spiral’ data from CS231n Convolutional Neural Networks to ensure that my vectorized implementations in Python, R and Octave are correct. Here is the ‘spiral’ data set.

import numpy as np
import matplotlib.pyplot as plt
import os
os.chdir("C:/junk/dl-4/dl-4")
exec(open("././DLfunctions41.py").read())

# Create an input data set - Taken from CS231n Convolutional Neural networks
# http://cs231n.github.io/neural-networks-case-study/
N = 100 # number of points per class
D = 2 # dimensionality
K = 3 # number of classes
X = np.zeros((N*K,D)) # data matrix (each row = single example)
y = np.zeros(N*K, dtype='uint8') # class labels
for j in range(K):
  ix = range(N*j,N*(j+1))
  r = np.linspace(0.0,1,N) # radius
  t = np.linspace(j*4,(j+1)*4,N) + np.random.randn(N)*0.2 # theta
  X[ix] = np.c_[r*np.sin(t), r*np.cos(t)]
  y[ix] = j
# Plot the data
plt.scatter(X[:, 0], X[:, 1], c=y, s=40, cmap=plt.cm.Spectral)
plt.savefig("fig1.png", bbox_inches='tight')


The implementations of the vectorized Python, R and Octave code are shown diagrammatically below

2.1 Multi-class classification with Softmax – Python code

A simple 2 layer Neural network with a single hidden layer , with 100 Relu activation units in the hidden layer and the Softmax activation unit in the output layer is used for multi-class classification. This Deep Learning Network, plots the non-linear boundary of the 3 classes as shown below

import numpy as np
import matplotlib.pyplot as plt
import os
os.chdir("C:/junk/dl-4/dl-4")
exec(open("././DLfunctions41.py").read())

# Read the input data
N = 100 # number of points per class
D = 2 # dimensionality
K = 3 # number of classes
X = np.zeros((N*K,D)) # data matrix (each row = single example)
y = np.zeros(N*K, dtype='uint8') # class labels
for j in range(K):
  ix = range(N*j,N*(j+1))
  r = np.linspace(0.0,1,N) # radius
  t = np.linspace(j*4,(j+1)*4,N) + np.random.randn(N)*0.2 # theta
  X[ix] = np.c_[r*np.sin(t), r*np.cos(t)]
  y[ix] = j

# Set the number of features, hidden units in hidden layer and number of classess
numHidden=100 # No of hidden units in hidden layer
numFeats= 2 # dimensionality
numOutput = 3 # number of classes

# Initialize the model
parameters=initializeModel(numFeats,numHidden,numOutput)
W1= parameters['W1']
b1= parameters['b1']
W2= parameters['W2']
b2= parameters['b2']

# Set the learning rate
learningRate=0.6

# Initialize losses
losses=[]
# Perform Gradient descent
for i in range(10000):
    # Forward propagation through hidden layer with Relu units
    A1,cache1= layerActivationForward(X.T,W1,b1,'relu')

    # Forward propagation through output layer with Softmax
    A2,cache2 = layerActivationForward(A1,W2,b2,'softmax')

    # No of training examples
    numTraining = X.shape[0]
    # Compute log probs. Take the log prob of correct class based on output y
    correct_logprobs = -np.log(A2[range(numTraining),y])
    # Conpute loss
    loss = np.sum(correct_logprobs)/numTraining

    # Print the loss
    if i % 1000 == 0:
        print("iteration %d: loss %f" % (i, loss))
        losses.append(loss)

    dA=0

    # Backward  propagation through output layer with Softmax
    dA1,dW2,db2 = layerActivationBackward(dA, cache2, y, activationFunc='softmax')
    # Backward  propagation through hidden layer with Relu unit
    dA0,dW1,db1 = layerActivationBackward(dA1.T, cache1, y, activationFunc='relu')

    #Update paramaters with the learning rate
    W1 += -learningRate * dW1
    b1 += -learningRate * db1
    W2 += -learningRate * dW2.T
    b2 += -learningRate * db2.T

#Plot losses vs iterations
i=np.arange(0,10000,1000)
plt.plot(i,losses)

plt.xlabel('Iterations')
plt.ylabel('Loss')
plt.title('Losses vs Iterations')
plt.savefig("fig2.png", bbox="tight")

#Compute the multi-class Confusion Matrix
from sklearn.metrics import confusion_matrix
from sklearn.metrics import accuracy_score, precision_score, recall_score, f1_score

# We need to determine the predicted values from the learnt data
# Forward propagation through hidden layer with Relu units
A1,cache1= layerActivationForward(X.T,W1,b1,'relu')

# Forward propagation through output layer with Softmax
A2,cache2 = layerActivationForward(A1,W2,b2,'softmax')
#Compute predicted values from weights and biases
yhat=np.argmax(A2, axis=1)

a=confusion_matrix(y.T,yhat.T)
print("Multi-class Confusion Matrix")
print(a)
## iteration 0: loss 1.098507
## iteration 1000: loss 0.214611
## iteration 2000: loss 0.043622
## iteration 3000: loss 0.032525
## iteration 4000: loss 0.025108
## iteration 5000: loss 0.021365
## iteration 6000: loss 0.019046
## iteration 7000: loss 0.017475
## iteration 8000: loss 0.016359
## iteration 9000: loss 0.015703
## Multi-class Confusion Matrix
## [[ 99   1   0]
##  [  0 100   0]
##  [  0   1  99]]

Check out my compact and minimal book  “Practical Machine Learning with R and Python:Second edition- Machine Learning in stereo”  available in Amazon in paperback($10.99) and kindle($7.99) versions. My book includes implementations of key ML algorithms and associated measures and metrics. The book is ideal for anybody who is familiar with the concepts and would like a quick reference to the different ML algorithms that can be applied to problems and how to select the best model. Pick your copy today!!

2.2 Multi-class classification with Softmax – R code

The spiral data set created with Python was saved, and is used as the input with R code. The R Neural Network seems to perform much,much slower than both Python and Octave. Not sure why! Incidentally the computation of loss and the softmax derivative are identical for both R and Octave. yet R is much slower. To compute the softmax derivative I create matrices for the One Hot Encoded yi and then stack them before subtracting pi-yi. I am sure there is a more elegant and more efficient way to do this, much like Python. Any suggestions?

library(ggplot2)
library(dplyr)
library(RColorBrewer)
source("DLfunctions41.R")
# Read the spiral dataset
Z <- as.matrix(read.csv("spiral.csv",header=FALSE))
Z1=data.frame(Z)
#Plot the dataset
ggplot(Z1,aes(x=V1,y=V2,col=V3)) +geom_point() +
  scale_colour_gradientn(colours = brewer.pal(10, "Spectral"))

# Setup the data
X <- Z[,1:2]
y <- Z[,3]
X1 <- t(X)
Y1 <- t(y)

# Initialize number of features, number of hidden units in hidden layer and
# number of classes
numFeats<-2 # No features
numHidden<-100 # No of hidden units
numOutput<-3 # No of classes

# Initialize model
parameters <-initializeModel(numFeats, numHidden,numOutput)

W1 <-parameters[['W1']]
b1 <-parameters[['b1']]
W2 <-parameters[['W2']]
b2 <-parameters[['b2']]

# Set the learning rate
learningRate <- 0.5
# Initialize losses
losses <- NULL
# Perform gradient descent
for(i in 0:9000){

# Forward propagation through hidden layer with Relu units
retvals <- layerActivationForward(X1,W1,b1,'relu')
A1 <- retvals[['A']]
cache1 <- retvals[['cache']]
forward_cache1 <- cache1[['forward_cache1']]
activation_cache <- cache1[['activation_cache']]

# Forward propagation through output layer with Softmax units
retvals = layerActivationForward(A1,W2,b2,'softmax')
A2 <- retvals[['A']]
cache2 <- retvals[['cache']]
forward_cache2 <- cache2[['forward_cache1']]
activation_cache2 <- cache2[['activation_cache']]

# No oftraining examples
numTraining <- dim(X)[1]
dA <-0

# Select the elements where the y values are 0, 1 or 2 and make a vector
a=c(A2[y==0,1],A2[y==1,2],A2[y==2,3])
# Take log
correct_probs = -log(a)
# Compute loss
loss= sum(correct_probs)/numTraining

if(i %% 1000 == 0){
sprintf("iteration %d: loss %f",i, loss)
print(loss)
}
# Backward propagation through output layer with Softmax units
retvals = layerActivationBackward(dA, cache2, y, activationFunc='softmax')
dA1 = retvals[['dA_prev']]
dW2= retvals[['dW']]
db2= retvals[['db']]
# Backward propagation through hidden layer with Relu units
retvals = layerActivationBackward(t(dA1), cache1, y, activationFunc='relu')
dA0 = retvals[['dA_prev']]
dW1= retvals[['dW']]
db1= retvals[['db']]

# Update parameters
W1 <- W1 - learningRate * dW1
b1 <- b1 - learningRate * db1
W2 <- W2 - learningRate * t(dW2)
b2 <- b2 - learningRate * t(db2)
}
## [1] 1.212487
## [1] 0.5740867
## [1] 0.4048824
## [1] 0.3561941
## [1] 0.2509576
## [1] 0.7351063
## [1] 0.2066114
## [1] 0.2065875
## [1] 0.2151943
## [1] 0.1318807



#Create iterations
iterations <- seq(0,10)
#df=data.frame(iterations,losses)
ggplot(df,aes(x=iterations,y=losses)) + geom_point() + geom_line(color="blue") +
    ggtitle("Losses vs iterations") + xlab("Iterations") + ylab("Loss")

plotDecisionBoundary(Z,W1,b1,W2,b2)



Multi-class Confusion Matrix

library(caret)
library(e1071)

# Forward propagation through hidden layer with Relu units
retvals <- layerActivationForward(X1,W1,b1,'relu')
A1 <- retvals[['A']]

# Forward propagation through output layer with Softmax units
retvals = layerActivationForward(A1,W2,b2,'softmax')
A2 <- retvals[['A']]
yhat <- apply(A2, 1,which.max) -1
Confusion Matrix and Statistics
          Reference
Prediction  0  1  2
         0 97  0  1
         1  2 96  4
         2  1  4 95

Overall Statistics
               Accuracy : 0.96
                 95% CI : (0.9312, 0.9792)
    No Information Rate : 0.3333
    P-Value [Acc > NIR] : <2e-16

                  Kappa : 0.94
 Mcnemar's Test P-Value : 0.5724
Statistics by Class:

                     Class: 0 Class: 1 Class: 2
Sensitivity            0.9700   0.9600   0.9500
Specificity            0.9950   0.9700   0.9750
Pos Pred Value         0.9898   0.9412   0.9500
Neg Pred Value         0.9851   0.9798   0.9750
Prevalence             0.3333   0.3333   0.3333
Detection Rate         0.3233   0.3200   0.3167
Detection Prevalence   0.3267   0.3400   0.3333
Balanced Accuracy      0.9825   0.9650   0.9625

My book “Practical Machine Learning with R and Python” includes the implementation for many Machine Learning algorithms and associated metrics. Pick up your copy today!

2.3 Multi-class classification with Softmax – Octave code

A 2 layer Neural network with the Softmax activation unit in the output layer is constructed in Octave. The same spiral data set is used for Octave also

source("DL41functions.m")
# Read the spiral data
data=csvread("spiral.csv");
# Setup the data
X=data(:,1:2);
Y=data(:,3);
# Set the number of features, number of hidden units in hidden layer and number of classes
numFeats=2; #No features
numHidden=100; # No of hidden units
numOutput=3; # No of classes
# Initialize model
[W1 b1 W2 b2] = initializeModel(numFeats,numHidden,numOutput);
# Initialize losses
losses=[]
#Initialize learningRate
learningRate=0.5;
for k =1:10000
# Forward propagation through hidden layer with Relu units
[A1,cache1 activation_cache1]= layerActivationForward(X',W1,b1,activationFunc ='relu');
# Forward propagation through output layer with Softmax units
[A2,cache2 activation_cache2] =
layerActivationForward(A1,W2,b2,activationFunc='softmax');
# No of training examples
numTraining = size(X)(1);
# Select rows where Y=0,1,and 2 and concatenate to a long vector
a=[A2(Y==0,1) ;A2(Y==1,2) ;A2(Y==2,3)];
#Select the correct column for log prob
correct_probs = -log(a);
#Compute log loss
loss= sum(correct_probs)/numTraining;
if(mod(k,1000) == 0)
disp(loss);
losses=[losses loss];
endif
dA=0;
# Backward propagation through output layer with Softmax units
[dA1 dW2 db2] = layerActivationBackward(dA, cache2, activation_cache2,Y,activationFunc='softmax');
# Backward propagation through hidden layer with Relu units
[dA0,dW1,db1] = layerActivationBackward(dA1', cache1, activation_cache1, Y, activationFunc='relu');
#Update parameters
W1 += -learningRate * dW1;
b1 += -learningRate * db1;
W2 += -learningRate * dW2';
b2 += -learningRate * db2';
endfor
# Plot Losses vs Iterations
iterations=0:1000:9000
plotCostVsIterations(iterations,losses)
# Plot the decision boundary
plotDecisionBoundary( X,Y,W1,b1,W2,b2)

The code for the Python, R and Octave implementations can be downloaded from Github at Deep Learning – Part 4

Conclusion

In this post I have implemented a 2 layer Neural Network with the Softmax classifier. In Part 3, I implemented a multi-layer Deep Learning Network. I intend to include the Softmax activation unit into the generalized multi-layer Deep Network along with the other activation units of sigmoid,tanh and relu.

Stick around, I’ll be back!!
Watch this space!

References
1. Deep Learning Specialization
2. Neural Networks for Machine Learning
3. CS231 Convolutional Neural Networks for Visual Recognition
4. Eli Bendersky’s Website – The Softmax function and its derivative
5. Cross Validated – Backpropagation with Softmax / Cross Entropy
6. Stackoverflow – CS231n: How to calculate gradient for Softmax loss function?
7. Math Stack Exchange – Derivative of Softmax
8. The Matrix Calculus for Deep Learning

You may like
1.My book ‘Practical Machine Learning with R and Python’ on Amazon
2. My travels through the realms of Data Science, Machine Learning, Deep Learning and (AI)
3. Deblurring with OpenCV: Weiner filter reloaded
4. A method to crowd source pothole marking on (Indian) roads
5. Rock N’ Roll with Bluemix, Cloudant & NodeExpress
6. Sea shells on the seashore
7. Design Principles of Scalable, Distributed Systems

To see all post click Index of posts

Deep Learning from first principles in Python, R and Octave – Part 3


“Once upon a time, I, Chuang Tzu, dreamt I was a butterfly, fluttering hither and thither, to all intents and purposes a butterfly. I was conscious only of following my fancies as a butterfly, and was unconscious of my individuality as a man. Suddenly, I awoke, and there I lay, myself again. Now I do not know whether I was then a man dreaming I was a butterfly, or whether I am now a butterfly dreaming that I am a man.”
from The Brain: The Story of you – David Eagleman

“Thought is a great big vector of neural activity”
Prof Geoffrey Hinton

Introduction

This is the third part in my series on Deep Learning from first principles in Python, R and Octave. In the first part Deep Learning from first principles in Python, R and Octave-Part 1, I implemented logistic regression as a 2 layer neural network. The 2nd part Deep Learning from first principles in Python, R and Octave-Part 2, dealt with the implementation of 3 layer Neural Networks with 1 hidden layer to perform classification tasks, where the 2 classes cannot be separated by a linear boundary. In this third part, I implement a multi-layer, Deep Learning (DL) network of arbitrary depth (any number of hidden layers) and arbitrary height (any number of activation units in each hidden layer). The implementations of these Deep Learning networks, in all the 3 parts, are based on vectorized versions in Python, R and Octave. The implementation in the 3rd part is for a L-layer Deep Netwwork, but without any regularization, early stopping, momentum or learning rate adaptation techniques. However even the barebones multi-layer DL, is a handful and has enough hyperparameters to fine-tune and adjust.

Checkout my book ‘Deep Learning from first principles: Second Edition – In vectorized Python, R and Octave’. My book starts with the implementation of a simple 2-layer Neural Network and works its way to a generic L-Layer Deep Learning Network, with all the bells and whistles. The derivations have been discussed in detail. The code has been extensively commented and included in its entirety in the Appendix sections. My book is available on Amazon as paperback ($18.99) and in kindle version($9.99/Rs449).

The implementation of the vectorized L-layer Deep Learning network in Python, R and Octave were both exhausting, and exacting!! Keeping track of the indices, layer number and matrix dimensions required quite bit of focus. While the implementation was demanding, it was also very exciting to get the code to work. The trick was to be able to shift gears between the slight quirkiness between the languages. Here are some of challenges I faced.

1. Python and Octave allow multiple return values to be unpacked in a single statement. With R, unpacking multiple return values from a list, requires the list returned, to be unpacked separately. I did see that there is a package gsubfn, which does this.  I hope this feature becomes a base R feature.
2. Python and R allow dissimilar elements to be saved and returned from functions using dictionaries or lists respectively. However there is no real equivalent in Octave. The closest I got to this functionality in Octave, was the ‘cell array’. But the cell array can be accessed only by the index, and not with the key as in a Python dictionary or R list. This makes things just a bit more difficult in Octave.
3. Python and Octave include implicit broadcasting. In R, broadcasting is not implicit, but R has a nifty function, the sweep(), with which we can broadcast either by columns or by rows
4. The closest equivalent of Python’s dictionary, or R’s list, in Octave is the cell array. However I had to manage separate cell arrays for weights and biases and during gradient descent and separate gradients dW and dB
5. In Python the rank-1 numpy arrays can be annoying at times. This issue is not present in R and Octave.

Though the number of lines of code for Deep Learning functions in Python, R and Octave are about ~350 apiece, they have been some of the most difficult code I have implemented. The current vectorized implementation supports the relu, sigmoid and tanh activation functions as of now. I will be adding other activation functions like the ‘leaky relu’, ‘softmax’ and others, to the implementation in the weeks to come.

While testing with different hyper-parameters namely i) the number of hidden layers, ii) the number of activation units in each layer, iii) the activation function and iv) the number iterations, I found the L-layer Deep Learning Network to be very sensitive to these hyper-parameters. It is not easy to tune the parameters. Adding more hidden layers, or more units per layer, does not help and mostly results in gradient descent getting stuck in some local minima. It does take a fair amount of trial and error and very close observation on how the DL network performs for logical changes. We then can zero in on the most the optimal solution. Feel free to download/fork my code from Github DeepLearning-Part 3 and play around with the hyper-parameters for your own problems.

Derivation of a Multi Layer Deep Learning Network

Note: A detailed discussion of the derivation below is available in my video presentation Neural Network 4
Lets take a simple 3 layer Neural network with 3 hidden layers and an output layer

In the forward propagation cycle the equations are

Z_{1} = W_{1}A_{0} +b_{1}  and  A_{1} = g(Z_{1})
Z_{2} = W_{2}A_{1} +b_{2}  and  A_{2} = g(Z_{2})
Z_{3} = W_{3}A_{2} +b_{3}  and A_{3} = g(Z_{3})

The loss function is given by
L = -(ylogA3 + (1-y)log(1-A3))
and dL/dA3 = -(Y/A_{3} + (1-Y)/(1-A_{3}))

For a binary classification the output activation function is the sigmoid function given by
A_{3} = 1/(1+ e^{-Z3}). It can be shown that
dA_{3}/dZ_{3} = A_{3}(1-A_3) see equation 2 in Part 1

\partial L/\partial Z_{3} = \partial L/\partial A_{3}* \partial A_{3}/\partial Z_{3} = A3-Y see equation (f) in  Part 1
and since
\partial L/\partial A_{2} = \partial L/\partial Z_{3} * \partial Z_{3}/\partial A_{2} = (A_{3} -Y) * W_{3} because \partial Z_{3}/\partial A_{2} = W_{3} -(1a)
and \partial L/\partial Z_{2} =\partial L/\partial A_{2} * \partial A_{2}/\partial Z_{2} = (A_{3} -Y) * W_{3} *g'(Z_{2}) -(1b)
\partial L/\partial W_{2} = \partial L/\partial Z_{2} * A_{1} -(1c)
since \partial Z_{2}/\partial W_{2} = A_{1}
and
\partial L/\partial b_{2} = \partial L/\partial Z_{2} -(1d)
because
\partial Z_{2}/\partial b_{2} =1

Also

\partial L/\partial A_{1} =\partial L/\partial Z_{2} * \partial Z_{2}/\partial A_{1} = \partial L/\partial Z_{2} * W_{2}     – (2a)
\partial L/\partial Z_{1} =\partial L/\partial A_{1} * \partial A_{1}/\partial Z_{1} = \partial L/\partial A_{1} * W_{2} *g'(Z_{1})          – (2b)
\partial L/\partial W_{1} = \partial L/\partial Z_{1} * A_{0} – (2c)
\partial L/\partial b_{1} = \partial L/\partial Z_{1} – (2d)

Inspecting the above equations (1a – 1d & 2a-2d), our ‘Uber deep, bottomless’ brain  can easily discern the pattern in these equations. The equation for any layer ‘l’ is of the form
Z_{l} = W_{l}A_{l-1} +b_{l}     and  A_{l} = g(Z_{l})
The equation for the backward propagation have the general form
\partial L/\partial A_{l} = \partial L/\partial Z_{l+1} * W^{l+1}
\partial L/\partial Z_{l}=\partial L/\partial A_{l} *g'(Z_{l})
\partial L/\partial W_{l} =\partial L/\partial Z_{l} *A^{l-1}
\partial L/\partial b_{l} =\partial L/\partial Z_{l}

Some other important results The derivatives of the activation functions in the implemented Deep Learning network
g(z) = sigmoid(z) = 1/(1+e^{-z}) = a g’(z) = a(1-a) – See Part 1
g(z) = tanh(z) = a g’(z) = 1 - a^{2}
g(z) = relu(z) = z  when z>0 and 0 when z 0 and 0 when z <= 0
While it appears that there is a discontinuity for the derivative at 0 the small value at the discontinuity does not present a problem

The implementation of the multi layer vectorized Deep Learning Network for Python, R and Octave is included below. For all these implementations, initially I create the size and configuration of the the Deep Learning network with the layer dimennsions So for example layersDimension Vector ‘V’ of length L indicating ‘L’ layers where

V (in Python)= [v_{0}, v_{1}, v_{2}, … v_{L-1}]
V (in R)= c(v_{1}, v_{2}, v_{3} , … v_{L})
V (in Octave)= [ v_{1} v_{2} v_{3}v_{L}]

In all of these implementations the first element is the number of input features to the Deep Learning network and the last element is always a ‘sigmoid’ activation function since all the problems deal with binary classification.

The number of elements between the first and the last element are the number of hidden layers and the magnitude of each v_{i} is the number of activation units in each hidden layer, which is specified while actually executing the Deep Learning network using the function L_Layer_DeepModel(), in all the implementations Python, R and Octave

1a. Classification with Multi layer Deep Learning Network – Relu activation(Python)

In the code below a 4 layer Neural Network is trained to generate a non-linear boundary between the classes. In the code below the ‘Relu’ Activation function is used. The number of activation units in each layer is 9. The cost vs iterations is plotted in addition to the decision boundary. Further the accuracy, precision, recall and F1 score are also computed

import os
import numpy as np
import matplotlib.pyplot as plt
import matplotlib.colors
import sklearn.linear_model

from sklearn.model_selection import train_test_split
from sklearn.datasets import make_classification, make_blobs
from matplotlib.colors import ListedColormap
import sklearn
import sklearn.datasets

#from DLfunctions import plot_decision_boundary
execfile("./DLfunctions34.py") #
os.chdir("C:\\software\\DeepLearning-Posts\\part3")

# Create clusters of 2 classes
X1, Y1 = make_blobs(n_samples = 400, n_features = 2, centers = 9,
                       cluster_std = 1.3, random_state = 4)
#Create 2 classes
Y1=Y1.reshape(400,1)
Y1 = Y1 % 2
X2=X1.T
Y2=Y1.T
# Set the dimensions of DL Network
#  Below we have
#  2 - 2 input features
#  9,9 - 2 hidden layers with 9 activation units per layer and
#  1 - 1 sigmoid activation unit in the output layer as this is a binary classification
# The activation in the hidden layer is the 'relu' specified in L_Layer_DeepModel

layersDimensions = [2, 9, 9,1] #  4-layer model
parameters = L_Layer_DeepModel(X2, Y2, layersDimensions,hiddenActivationFunc='relu', learning_rate = 0.3,num_iterations = 2500, fig="fig1.png")
#Plot the decision boundary
plot_decision_boundary(lambda x: predict(parameters, x.T), X2,Y2,str(0.3),"fig2.png")

# Compute the confusion matrix
yhat = predict(parameters,X2)
from sklearn.metrics import confusion_matrix
a=confusion_matrix(Y2.T,yhat.T)
from sklearn.metrics import accuracy_score, precision_score, recall_score, f1_score
print('Accuracy: {:.2f}'.format(accuracy_score(Y2.T, yhat.T)))
print('Precision: {:.2f}'.format(precision_score(Y2.T, yhat.T)))
print('Recall: {:.2f}'.format(recall_score(Y2.T, yhat.T)))
print('F1: {:.2f}'.format(f1_score(Y2.T, yhat.T)))
## Accuracy: 0.90
## Precision: 0.91
## Recall: 0.87
## F1: 0.89

For more details on metrics like Accuracy, Recall, Precision etc. used in classification take a look at my post Practical Machine Learning with R and Python – Part 2. More details about these and other metrics besides implementation of the most common machine learning algorithms are available in my book My book ‘Practical Machine Learning with R and Python’ on Amazon

1b. Classification with Multi layer Deep Learning Network – Relu activation(R)

In the code below, binary classification is performed on the same data set as above using the Relu activation function. The DL network is same as above

library(ggplot2)
# Read the data
z <- as.matrix(read.csv("data.csv",header=FALSE))
x <- z[,1:2]
y <- z[,3]
X1 <- t(x)
Y1 <- t(y)

# Set the dimensions of the Deep Learning network
# No of input features =2, 2 hidden layers with 9 activation units and 1 output layer
layersDimensions = c(2, 9, 9,1)
# Execute the Deep Learning Neural Network
retvals = L_Layer_DeepModel(X1, Y1, layersDimensions,
                               hiddenActivationFunc='relu',
                               learningRate = 0.3,
                               numIterations = 5000,
                               print_cost = True)
library(ggplot2)
source("DLfunctions33.R")
# Get the computed costs
costs <- retvals[['costs']]
# Create a sequence of iterations
numIterations=5000
iterations <- seq(0,numIterations,by=1000)
df <-data.frame(iterations,costs)
# Plot the Costs vs number of iterations
ggplot(df,aes(x=iterations,y=costs)) + geom_point() +geom_line(color="blue") +
    xlab('No of iterations') + ylab('Cost') + ggtitle("Cost vs No of iterations")

# Plot the decision boundary
plotDecisionBoundary(z,retvals,hiddenActivationFunc="relu",0.3)

library(caret)
# Predict the output for the data values
yhat <-predict(retvals$parameters,X1,hiddenActivationFunc="relu")
yhat[yhat==FALSE]=0
yhat[yhat==TRUE]=1
# Compute the confusion matrix
confusionMatrix(yhat,Y1)
## Confusion Matrix and Statistics
##
##           Reference
## Prediction   0   1
##          0 201  10
##          1  21 168
##
##                Accuracy : 0.9225
##                  95% CI : (0.8918, 0.9467)
##     No Information Rate : 0.555
##     P-Value [Acc > NIR] : < 2e-16
##
##                   Kappa : 0.8441
##  Mcnemar's Test P-Value : 0.07249
##
##             Sensitivity : 0.9054
##             Specificity : 0.9438
##          Pos Pred Value : 0.9526
##          Neg Pred Value : 0.8889
##              Prevalence : 0.5550
##          Detection Rate : 0.5025
##    Detection Prevalence : 0.5275
##       Balanced Accuracy : 0.9246
##
##        'Positive' Class : 0
##

1c. Classification with Multi layer Deep Learning Network – Relu activation(Octave)

Included below is the code for performing classification. Incidentally Octave does not seem to have implemented the confusion matrix,  but confusionmat is available in Matlab.
# Read the data
data=csvread("data.csv");
X=data(:,1:2);
Y=data(:,3);
# Set layer dimensions
layersDimensions = [2 9 7 1] #tanh=-0.5(ok), #relu=0.1 best!
# Execute Deep Network
[weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions,
hiddenActivationFunc='relu',
learningRate = 0.1,
numIterations = 10000);
plotCostVsIterations(10000,costs);
plotDecisionBoundary(data,weights, biases,hiddenActivationFunc="tanh")


2a. Classification with Multi layer Deep Learning Network – Tanh activation(Python)

Below the Tanh activation function is used to perform the same classification. I found the Tanh activation required a simpler Neural Network of 3 layers.

# Tanh activation
import os
import numpy as np
import matplotlib.pyplot as plt
import matplotlib.colors
import sklearn.linear_model

from sklearn.model_selection import train_test_split
from sklearn.datasets import make_classification, make_blobs
from matplotlib.colors import ListedColormap
import sklearn
import sklearn.datasets

#from DLfunctions import plot_decision_boundary
os.chdir("C:\\software\\DeepLearning-Posts\\part3")
execfile("./DLfunctions34.py")
# Create the dataset
X1, Y1 = make_blobs(n_samples = 400, n_features = 2, centers = 9,
                       cluster_std = 1.3, random_state = 4)
#Create 2 classes
Y1=Y1.reshape(400,1)
Y1 = Y1 % 2
X2=X1.T
Y2=Y1.T
# Set the dimensions of the Neural Network
layersDimensions = [2, 4, 1] #  3-layer model
# Compute the DL network
parameters = L_Layer_DeepModel(X2, Y2, layersDimensions, hiddenActivationFunc='tanh', learning_rate = .5,num_iterations = 2500,fig="fig3.png")
#Plot the decision boundary
plot_decision_boundary(lambda x: predict(parameters, x.T), X2,Y2,str(0.5),"fig4.png")

2b. Classification with Multi layer Deep Learning Network – Tanh activation(R)

R performs better with a Tanh activation than the Relu as can be seen below

 #Set the dimensions of the Neural Network
layersDimensions = c(2, 9, 9,1)
library(ggplot2)
# Read the data
z <- as.matrix(read.csv("data.csv",header=FALSE))
x <- z[,1:2]
y <- z[,3]
X1 <- t(x)
Y1 <- t(y)
# Execute the Deep Model
retvals = L_Layer_DeepModel(X1, Y1, layersDimensions,
                            hiddenActivationFunc='tanh',
                            learningRate = 0.3,
                            numIterations = 5000,
                            print_cost = True)
# Get the costs
costs <- retvals[['costs']]
iterations <- seq(0,numIterations,by=1000)
df <-data.frame(iterations,costs)
# Plot Cost vs number of iterations
ggplot(df,aes(x=iterations,y=costs)) + geom_point() +geom_line(color="blue") +
    xlab('No of iterations') + ylab('Cost') + ggtitle("Cost vs No of iterations")

#Plot the decision boundary
plotDecisionBoundary(z,retvals,hiddenActivationFunc="tanh",0.3)

2c. Classification with Multi layer Deep Learning Network – Tanh activation(Octave)

The code below uses the   Tanh activation in the hidden layers for Octave
# Read the data
data=csvread("data.csv");
X=data(:,1:2);
Y=data(:,3);
# Set layer dimensions
layersDimensions = [2 9 7 1] #tanh=-0.5(ok), #relu=0.1 best!
# Execute Deep Network
[weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions,
hiddenActivationFunc='tanh',
learningRate = 0.1,
numIterations = 10000);
plotCostVsIterations(10000,costs);
plotDecisionBoundary(data,weights, biases,hiddenActivationFunc="tanh")


3. Bernoulli’s Lemniscate

To make things  more interesting, I create a 2D figure of the Bernoulli’s lemniscate to perform non-linear classification. The Lemniscate is given by the equation
(x^{2} + y^{2})^{2} = 2a^{2}*(x^{2}-y^{2})

3a. Classifying a lemniscate with Deep Learning Network – Relu activation(Python)

import os
import numpy as np
import matplotlib.pyplot as plt
os.chdir("C:\\software\\DeepLearning-Posts\\part3")
execfile("./DLfunctions33.py")
x1=np.random.uniform(0,10,2000).reshape(2000,1)
x2=np.random.uniform(0,10,2000).reshape(2000,1)

X=np.append(x1,x2,axis=1)
X.shape

# Create a subset of values where squared is <0,4. Perform ravel() to flatten this vector
# Create the equation
# (x^{2} + y^{2})^2 - 2a^2*(x^{2}-y^{2}) <= 0
a=np.power(np.power(X[:,0]-5,2) + np.power(X[:,1]-5,2),2)
b=np.power(X[:,0]-5,2) - np.power(X[:,1]-5,2)
c= a - (b*np.power(4,2)) <=0
Y=c.reshape(2000,1)
# Create a scatter plot of the lemniscate
plt.scatter(X[:,0], X[:,1], c=Y, marker= 'o', s=15,cmap="viridis")
Z=np.append(X,Y,axis=1)
plt.savefig("fig50.png",bbox_inches='tight')
plt.clf()

# Set the data for classification
X2=X.T
Y2=Y.T
# These settings work the best
# Set the Deep Learning layer dimensions for a Relu activation
layersDimensions = [2,7,4,1]
#Execute the DL network
parameters = L_Layer_DeepModel(X2, Y2, layersDimensions, hiddenActivationFunc='relu', learning_rate = 0.5,num_iterations = 10000, fig="fig5.png")
#Plot the decision boundary
plot_decision_boundary(lambda x: predict(parameters, x.T), X2, Y2,str(2.2),"fig6.png")

# Compute the Confusion matrix
yhat = predict(parameters,X2)
from sklearn.metrics import confusion_matrix
a=confusion_matrix(Y2.T,yhat.T)
from sklearn.metrics import accuracy_score, precision_score, recall_score, f1_score
print('Accuracy: {:.2f}'.format(accuracy_score(Y2.T, yhat.T)))
print('Precision: {:.2f}'.format(precision_score(Y2.T, yhat.T)))
print('Recall: {:.2f}'.format(recall_score(Y2.T, yhat.T)))
print('F1: {:.2f}'.format(f1_score(Y2.T, yhat.T)))
## Accuracy: 0.93
## Precision: 0.77
## Recall: 0.76
## F1: 0.76

We could get better performance by tuning further. Do play around if you fork the code.
Note:: The lemniscate data is saved as a CSV and then read in R and also in Octave. I do this instead of recreating the lemniscate shape

3b. Classifying a lemniscate with Deep Learning Network – Relu activation(R code)

The R decision boundary for the Bernoulli’s lemniscate is shown below

Z <- as.matrix(read.csv("lemniscate.csv",header=FALSE))
Z1=data.frame(Z)
# Create a scatter plot of the lemniscate
ggplot(Z1,aes(x=V1,y=V2,col=V3)) +geom_point()
#Set the data for the DL network
X=Z[,1:2]
Y=Z[,3]

X1=t(X)
Y1=t(Y)

# Set the layer dimensions for the tanh activation function
layersDimensions = c(2,5,4,1)
# Execute the Deep Learning network with Tanh activation
retvals = L_Layer_DeepModel(X1, Y1, layersDimensions,
                               hiddenActivationFunc='tanh',
                               learningRate = 0.3,
                               numIterations = 20000, print_cost = True)
# Plot cost vs iteration
costs <- retvals[['costs']]
numIterations = 20000
iterations <- seq(0,numIterations,by=1000)
df <-data.frame(iterations,costs)
ggplot(df,aes(x=iterations,y=costs)) + geom_point() +geom_line(color="blue") +
    xlab('No of iterations') + ylab('Cost') + ggtitle("Cost vs No of iterations")

#Plot the decision boundary
plotDecisionBoundary(Z,retvals,hiddenActivationFunc="tanh",0.3)

3c. Classifying a lemniscate with Deep Learning Network – Relu activation(Octave code)

Octave is used to generate the non-linear lemniscate boundary.

# Read the data
data=csvread("lemniscate.csv");
X=data(:,1:2);
Y=data(:,3);
# Set the dimensions of the layers
layersDimensions = [2 9 7 1]
# Compute the DL network
[weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions,
hiddenActivationFunc='relu',
learningRate = 0.20,
numIterations = 10000);
plotCostVsIterations(10000,costs);
plotDecisionBoundary(data,weights, biases,hiddenActivationFunc="relu")


4a. Binary Classification using MNIST – Python code

Finally I perform a simple classification using the MNIST handwritten digits, which according to Prof Geoffrey Hinton is “the Drosophila of Deep Learning”.

The Python code for reading the MNIST data is taken from Alex Kesling’s github link MNIST.

In the Python code below, I perform a simple binary classification between the handwritten digit ‘5’ and ‘not 5’ which is all other digits. I will perform the proper classification of all digits using the  Softmax classifier some time later.

import os
import numpy as np
import matplotlib.pyplot as plt
os.chdir("C:\\software\\DeepLearning-Posts\\part3")
execfile("./DLfunctions34.py")
execfile("./load_mnist.py")
training=list(read(dataset='training',path="./mnist"))
test=list(read(dataset='testing',path="./mnist"))
lbls=[]
pxls=[]
print(len(training))

# Select the first 10000 training data and the labels
for i in range(10000):
       l,p=training[i]
       lbls.append(l)
       pxls.append(p)
labels= np.array(lbls)
pixels=np.array(pxls)

#  Sey y=1  when labels == 5 and 0 otherwise
y=(labels==5).reshape(-1,1)
X=pixels.reshape(pixels.shape[0],-1)

# Create the necessary feature and target variable
X1=X.T
Y1=y.T

# Create the layer dimensions. The number of features are 28 x 28 = 784 since the 28 x 28
# pixels is flattened to single vector of length 784.
layersDimensions=[784, 15,9,7,1] # Works very well
parameters = L_Layer_DeepModel(X1, Y1, layersDimensions, hiddenActivationFunc='relu', learning_rate = 0.1,num_iterations = 1000, fig="fig7.png")

# Test data
lbls1=[]
pxls1=[]
for i in range(800):
       l,p=test[i]
       lbls1.append(l)
       pxls1.append(p)

testLabels=np.array(lbls1)
testData=np.array(pxls1)

ytest=(testLabels==5).reshape(-1,1)
Xtest=testData.reshape(testData.shape[0],-1)
Xtest1=Xtest.T
Ytest1=ytest.T

yhat = predict(parameters,Xtest1)
from sklearn.metrics import confusion_matrix
a=confusion_matrix(Ytest1.T,yhat.T)
from sklearn.metrics import accuracy_score, precision_score, recall_score, f1_score
print('Accuracy: {:.2f}'.format(accuracy_score(Ytest1.T, yhat.T)))
print('Precision: {:.2f}'.format(precision_score(Ytest1.T, yhat.T)))
print('Recall: {:.2f}'.format(recall_score(Ytest1.T, yhat.T)))
print('F1: {:.2f}'.format(f1_score(Ytest1.T, yhat.T)))

probs=predict_proba(parameters,Xtest1)
from sklearn.metrics import precision_recall_curve

precision, recall, thresholds = precision_recall_curve(Ytest1.T, probs.T)
closest_zero = np.argmin(np.abs(thresholds))
closest_zero_p = precision[closest_zero]
closest_zero_r = recall[closest_zero]
plt.xlim([0.0, 1.01])
plt.ylim([0.0, 1.01])
plt.plot(precision, recall, label='Precision-Recall Curve')
plt.plot(closest_zero_p, closest_zero_r, 'o', markersize = 12, fillstyle = 'none', c='r', mew=3)
plt.xlabel('Precision', fontsize=16)
plt.ylabel('Recall', fontsize=16)
plt.savefig("fig8.png",bbox_inches='tight')

## Accuracy: 0.99
## Precision: 0.96
## Recall: 0.89
## F1: 0.92

In addition to plotting the Cost vs Iterations, I also plot the Precision-Recall curve to show how the Precision and Recall, which are complementary to each other vary with respect to the other. To know more about Precision-Recall, please check my post Practical Machine Learning with R and Python – Part 4.

Check out my compact and minimal book  “Practical Machine Learning with R and Python:Second edition- Machine Learning in stereo”  available in Amazon in paperback($10.99) and kindle($7.99) versions. My book includes implementations of key ML algorithms and associated measures and metrics. The book is ideal for anybody who is familiar with the concepts and would like a quick reference to the different ML algorithms that can be applied to problems and how to select the best model. Pick your copy today!!

A physical copy of the book is much better than scrolling down a webpage. Personally, I tend to use my own book quite frequently to refer to R, Python constructs,  subsetting, machine Learning function calls and the necessary parameters etc. It is useless to commit any of this to memory, and a physical copy of a book is much easier to thumb through for the relevant code snippet. Pick up your copy today!

4b. Binary Classification using MNIST – R code

In the R code below the same binary classification of the digit ‘5’ and the ‘not 5’ is performed. The code to read and display the MNIST data is taken from Brendan O’ Connor’s github link at MNIST

source("mnist.R")
load_mnist()
#show_digit(train$x[2,]
layersDimensions=c(784, 7,7,3,1) # Works at 1500
x <- t(train$x)
# Choose only 5000 training data
x2 <- x[,1:5000]
y <-train$y
# Set labels for all digits that are 'not 5' to 0
y[y!=5] <- 0
# Set labels of digit 5 as 1
y[y==5] <- 1
# Set the data
y1 <- as.matrix(y)
y2 <- t(y1)
# Choose the 1st 5000 data
y3 <- y2[,1:5000]

#Execute the Deep Learning Model
retvals = L_Layer_DeepModel(x2, y3, layersDimensions,
                               hiddenActivationFunc='tanh',
                               learningRate = 0.3,
                               numIterations = 3000, print_cost = True)
# Plot cost vs iteration
costs <- retvals[['costs']]
numIterations = 3000
iterations <- seq(0,numIterations,by=1000)
df <-data.frame(iterations,costs)
ggplot(df,aes(x=iterations,y=costs)) + geom_point() +geom_line(color="blue") +
    xlab('No of iterations') + ylab('Cost') + ggtitle("Cost vs No of iterations")

# Compute probability scores
scores <- computeScores(retvals$parameters, x2,hiddenActivationFunc='relu')
a=y3==1
b=y3==0

# Compute probabilities of class 0 and class 1
class1=scores[a]
class0=scores[b]

# Plot ROC curve
pr <-pr.curve(scores.class0=class1,
        scores.class1=class0,
       curve=T)

plot(pr)

The AUC curve hugs the top left corner and hence the performance of the classifier is quite good.

4c. Binary Classification using MNIST – Octave code

This code to load MNIST data was taken from Daniel E blog.
Precision recall curves are available in Matlab but are yet to be implemented in Octave’s statistics package.

load('./mnist/mnist.txt.gz'); % load the dataset
# Subset the 'not 5' digits
a=(trainY != 5);
# Subset '5'
b=(trainY == 5);
#make a copy of trainY
#Set 'not 5' as 0 and '5' as 1
y=trainY;
y(a)=0;
y(b)=1;
X=trainX(1:5000,:);
Y=y(1:5000);
# Set the dimensions of layer
layersDimensions=[784, 7,7,3,1];
# Compute the DL network
[weights biases costs]=L_Layer_DeepModel(X', Y', layersDimensions,
hiddenActivationFunc='relu',
learningRate = 0.1,
numIterations = 5000);

Conclusion

It was quite a challenge coding a Deep Learning Network in Python, R and Octave. The Deep Learning network implementation, in this post,is the base Deep Learning network, without any of the regularization methods included. Here are some key learning that I got while playing with different multi-layer networks on different problems

a. Deep Learning Networks come with many levers, the hyper-parameters,
– learning rate
– activation unit
– number of hidden layers
– number of units per hidden layer
– number of iterations while performing gradient descent
b. Deep Networks are very sensitive. A change in any of the hyper-parameter makes it perform very differently
c. Initially I thought adding more hidden layers, or more units per hidden layer will make the DL network better at learning. On the contrary, there is a performance degradation after the optimal DL configuration
d. At a sub-optimal number of hidden layers or number of hidden units, gradient descent seems to get stuck at a local minima
e. There were occasions when the cost came down, only to increase slowly as the number of iterations were increased. Probably early stopping would have helped.
f. I also did come across situations of ‘exploding/vanishing gradient’, cost went to Inf/-Inf. Here I would think inclusion of ‘momentum method’ would have helped

I intend to add the additional hyper-parameters of L1, L2 regularization, momentum method, early stopping etc. into the code in my future posts.
Feel free to fork/clone the code from Github Deep Learning – Part 3, and take the DL network apart and play around with it.

I will be continuing this series with more hyper-parameters to handle vanishing and exploding gradients, early stopping and regularization in the weeks to come. I also intend to add some more activation functions to this basic Multi-Layer Network.
Hang around, there are more exciting things to come.

Watch this space!

References
1. Deep Learning Specialization
2. Neural Networks for Machine Learning
3. Deep Learning, Ian Goodfellow, Yoshua Bengio and Aaron Courville
4. Neural Networks: The mechanics of backpropagation
5. Machine Learning

Also see
1.My book ‘Practical Machine Learning with R and Python’ on Amazon
2. My travels through the realms of Data Science, Machine Learning, Deep Learning and (AI)
3. Designing a Social Web Portal
4. GooglyPlus: yorkr analyzes IPL players, teams, matches with plots and tables
4. Introducing QCSimulator: A 5-qubit quantum computing simulator in R
6. Presentation on “Intelligent Networks, CAMEL protocol, services & applications
7. Design Principles of Scalable, Distributed Systems

To see all posts see Index of posts

Deep Learning from first principles in Python, R and Octave – Part 1


“You don’t perceive objects as they are. You perceive them as you are.”
“Your interpretation of physical objects has everything to do with the historical trajectory of your brain – and little to do with the objects themselves.”
“The brain generates its own reality, even before it receives information coming in from the eyes and the other senses. This is known as the internal model”

                          David Eagleman - The Brain: The Story of You

This is the first in the series of posts, I intend to write on Deep Learning. This post is inspired by the Deep Learning Specialization by Prof Andrew Ng on Coursera and Neural Networks for Machine Learning by Prof Geoffrey Hinton also on Coursera. In this post I implement Logistic regression with a 2 layer Neural Network i.e. a Neural Network that just has an input layer and an output layer and with no hidden layer.I am certain that any self-respecting Deep Learning/Neural Network would consider a Neural Network without hidden layers as no Neural Network at all!

This 2 layer network is implemented in Python, R and Octave languages. I have included Octave, into the mix, as Octave is a close cousin of Matlab. These implementations in Python, R and Octave are equivalent vectorized implementations. So, if you are familiar in any one of the languages, you should be able to look at the corresponding code in the other two. You can download this R Markdown file and Octave code from DeepLearning -Part 1

Check out my video presentation which discusses the derivations in detail
1. Elements of Neural Networks and Deep Le- Part 1
2. Elements of Neural Networks and Deep Learning – Part 2

To start with, Logistic Regression is performed using sklearn’s logistic regression package for the cancer data set also from sklearn. This is shown below

1. Logistic Regression

import numpy as np
import pandas as pd
import os
import matplotlib.pyplot as plt
from sklearn.model_selection import train_test_split
from sklearn.linear_model import LogisticRegression
from sklearn.datasets import make_classification, make_blobs

from sklearn.metrics import confusion_matrix
from matplotlib.colors import ListedColormap
from sklearn.datasets import load_breast_cancer
# Load the cancer data
(X_cancer, y_cancer) = load_breast_cancer(return_X_y = True)
X_train, X_test, y_train, y_test = train_test_split(X_cancer, y_cancer,
                                                   random_state = 0)
# Call the Logisitic Regression function
clf = LogisticRegression().fit(X_train, y_train)
print('Accuracy of Logistic regression classifier on training set: {:.2f}'
     .format(clf.score(X_train, y_train)))
print('Accuracy of Logistic regression classifier on test set: {:.2f}'
     .format(clf.score(X_test, y_test)))
## Accuracy of Logistic regression classifier on training set: 0.96
## Accuracy of Logistic regression classifier on test set: 0.96

To check on other classification algorithms, check my post Practical Machine Learning with R and Python – Part 2.

Checkout my book ‘Deep Learning from first principles: Second Edition – In vectorized Python, R and Octave’. My book starts with the implementation of a simple 2-layer Neural Network and works its way to a generic L-Layer Deep Learning Network, with all the bells and whistles. The derivations have been discussed in detail. The code has been extensively commented and included in its entirety in the Appendix sections. My book is available on Amazon as paperback ($14.99) and in kindle version($9.99/Rs449).

You may also like my companion book “Practical Machine Learning with R and Python:Second Edition- Machine Learning in stereo” available in Amazon in paperback($10.99) and Kindle($7.99/Rs449) versions. This book is ideal for a quick reference of the various ML functions and associated measurements in both R and Python which are essential to delve deep into Deep Learning.

2. Logistic Regression as a 2 layer Neural Network

In the following section Logistic Regression is implemented as a 2 layer Neural Network in Python, R and Octave. The same cancer data set from sklearn will be used to train and test the Neural Network in Python, R and Octave. This can be represented diagrammatically as below



The cancer data set has 30 input features, and the target variable ‘output’ is either 0 or 1. Hence the sigmoid activation function will be used in the output layer for classification.

This simple 2 layer Neural Network is shown below
At the input layer there are 30 features and the corresponding weights of these inputs which are initialized to small random values.
Z= w_{1}x_{1} +w_{2}x_{2} +..+ w_{30}x_{30} + b
where ‘b’ is the bias term

The Activation function is the sigmoid function which is a= 1/(1+e^{-z})
The Loss, when the sigmoid function is used in the output layer, is given by
L=-(ylog(a) + (1-y)log(1-a)) (1)

Gradient Descent

Forward propagation

In forward propagation cycle of the Neural Network the output Z and the output of activation function, the sigmoid function, is first computed. Then using the output ‘y’ for the given features, the ‘Loss’ is computed using equation (1) above.

Backward propagation

The backward propagation cycle determines how the ‘Loss’ is impacted for small variations from the previous layers upto the input layer. In other words, backward propagation computes the changes in the weights at the input layer, which will minimize the loss. Several cycles of gradient descent are performed in the path of steepest descent to find the local minima. In other words the set of weights and biases, at the input layer, which will result in the lowest loss is computed by gradient descent. The weights at the input layer are decreased by a parameter known as the ‘learning rate’. Too big a ‘learning rate’ can overshoot the local minima, and too small a ‘learning rate’ can take a long time to reach the local minima. This is done for ‘m’ training examples.

Chain rule of differentiation
Let y=f(u)
and u=g(x) then
\partial y/\partial x = \partial y/\partial u * \partial u/\partial x

Derivative of sigmoid
\sigma=1/(1+e^{-z})
Let x= 1 + e^{-z}  then
\sigma = 1/x
\partial \sigma/\partial x = -1/x^{2}
\partial x/\partial z = -e^{-z}
Using the chain rule of differentiation we get
\partial \sigma/\partial z = \partial \sigma/\partial x * \partial x/\partial z
=-1/(1+e^{-z})^{2}* -e^{-z} = e^{-z}/(1+e^{-z})^{2}
Therefore \partial \sigma/\partial z = \sigma(1-\sigma)        -(2)

The 3 equations for the 2 layer Neural Network representation of Logistic Regression are
L=-(y*log(a) + (1-y)*log(1-a))      -(a)
a=1/(1+e^{-Z})      -(b)
Z= w_{1}x_{1} +w_{2}x_{2} +...+ w_{30}x_{30} +b = Z = \sum_{i} w_{i}*x_{i} + b -(c)

The back propagation step requires the computation of dL/dw_{i} and dL/db_{i}. In the case of regression it would be dE/dw_{i} and dE/db_{i} where dE is the Mean Squared Error function.
Computing the derivatives for back propagation we have
dL/da = -(y/a + (1-y)/(1-a))          -(d)
because d/dx(logx) = 1/x
Also from equation (2) we get
da/dZ = a (1-a)                                  – (e)
By chain rule
\partial L/\partial Z = \partial L/\partial a * \partial a/\partial Z
therefore substituting the results of (d) & (e) we get
\partial L/\partial Z = -(y/a + (1-y)/(1-a)) * a(1-a) = a-y         (f)
Finally
\partial L/\partial w_{i}= \partial L/\partial a * \partial a/\partial Z * \partial Z/\partial w_{i}                                                           -(g)
\partial Z/\partial w_{i} = x_{i}            – (h)
and from (f) we have  \partial L/\partial Z =a-y
Therefore  (g) reduces to
\partial L/\partial w_{i} = x_{i}* (a-y) -(i)
Also
\partial L/\partial b = \partial L/\partial a * \partial a/\partial Z * \partial Z/\partial b -(j)
Since
\partial Z/\partial b = 1 and using (f) in (j)
\partial L/\partial b = a-y

The gradient computes the weights at the input layer and the corresponding bias by using the values
of dw_{i} and db
w_{i} := w_{i} -\alpha * dw_{i}
b := b -\alpha * db
I found the computation graph representation in the book Deep Learning: Ian Goodfellow, Yoshua Bengio, Aaron Courville, very useful to visualize and also compute the backward propagation. For the 2 layer Neural Network of Logistic Regression the computation graph is shown below

3. Neural Network for Logistic Regression -Python code (vectorized)

import numpy as np
import pandas as pd
import os
import matplotlib.pyplot as plt
from sklearn.model_selection import train_test_split

# Define the sigmoid function
def sigmoid(z):
    a=1/(1+np.exp(-z))
    return a

# Initialize
def initialize(dim):
    w = np.zeros(dim).reshape(dim,1)
    b = 0
    return w

# Compute the loss
def computeLoss(numTraining,Y,A):
    loss=-1/numTraining *np.sum(Y*np.log(A) + (1-Y)*(np.log(1-A)))
    return(loss)

# Execute the forward propagation
def forwardPropagation(w,b,X,Y):
    # Compute Z
    Z=np.dot(w.T,X)+b
    # Determine the number of training samples
    numTraining=float(len(X))
    # Compute the output of the sigmoid activation function
    A=sigmoid(Z)
    #Compute the loss
    loss = computeLoss(numTraining,Y,A)
    # Compute the gradients dZ, dw and db
    dZ=A-Y
    dw=1/numTraining*np.dot(X,dZ.T)
    db=1/numTraining*np.sum(dZ)

    # Return the results as a dictionary
    gradients = {"dw": dw,
             "db": db}
    loss = np.squeeze(loss)
    return gradients,loss

# Compute Gradient Descent
def gradientDescent(w, b, X, Y, numIerations, learningRate):
    losses=[]
    idx =[]
    # Iterate
    for i in range(numIerations):
        gradients,loss=forwardPropagation(w,b,X,Y)
        #Get the derivates
        dw = gradients["dw"]
        db = gradients["db"]
        w = w-learningRate*dw
        b = b-learningRate*db

        # Store the loss
        if i % 100 == 0:
            idx.append(i)
            losses.append(loss)
        # Set params and grads
        params = {"w": w,
                  "b": b}
        grads = {"dw": dw,
                 "db": db}

    return params, grads, losses,idx

# Predict the output for a training set
def predict(w,b,X):
    size=X.shape[1]
    yPredicted=np.zeros((1,size))
    Z=np.dot(w.T,X)
    # Compute the sigmoid
    A=sigmoid(Z)
    for i in range(A.shape[1]):
        #If the value is > 0.5 then set as 1
        if(A[0][i] > 0.5):
            yPredicted[0][i]=1
        else:
        # Else set as 0
            yPredicted[0][i]=0

    return yPredicted

#Normalize the data
def normalize(x):
    x_norm = None
    x_norm = np.linalg.norm(x,axis=1,keepdims=True)
    x= x/x_norm
    return x


# Run the 2 layer Neural Network on the cancer data set

from sklearn.datasets import load_breast_cancer
# Load the cancer data
(X_cancer, y_cancer) = load_breast_cancer(return_X_y = True)
# Create train and test sets
X_train, X_test, y_train, y_test = train_test_split(X_cancer, y_cancer,
                                                   random_state = 0)
# Normalize the data for better performance
X_train1=normalize(X_train)


# Create weight vectors of zeros. The size is the number of features in the data set=30
w=np.zeros((X_train.shape[1],1))
#w=np.zeros((30,1))
b=0

#Normalize the training data so that gradient descent performs better
X_train1=normalize(X_train)
#Transpose X_train so that we have a matrix as (features, numSamples)
X_train2=X_train1.T

# Reshape to remove the rank 1 array and then transpose
y_train1=y_train.reshape(len(y_train),1)
y_train2=y_train1.T

# Run gradient descent for 4000 times and compute the weights
parameters, grads, costs,idx = gradientDescent(w, b, X_train2, y_train2, numIerations=4000, learningRate=0.75)
w = parameters["w"]
b = parameters["b"]


# Normalize X_test
X_test1=normalize(X_test)
#Transpose X_train so that we have a matrix as (features, numSamples)
X_test2=X_test1.T

#Reshape y_test
y_test1=y_test.reshape(len(y_test),1)
y_test2=y_test1.T

# Predict the values for
yPredictionTest = predict(w, b, X_test2)
yPredictionTrain = predict(w, b, X_train2)

# Print the accuracy
print("train accuracy: {} %".format(100 - np.mean(np.abs(yPredictionTrain - y_train2)) * 100))
print("test accuracy: {} %".format(100 - np.mean(np.abs(yPredictionTest - y_test)) * 100))

# Plot the Costs vs the number of iterations
fig1=plt.plot(idx,costs)
fig1=plt.title("Gradient descent-Cost vs No of iterations")
fig1=plt.xlabel("No of iterations")
fig1=plt.ylabel("Cost")
fig1.figure.savefig("fig1", bbox_inches='tight')
## train accuracy: 90.3755868545 %
## test accuracy: 89.5104895105 %

Note: It can be seen that the Accuracy on the training and test set is 90.37% and 89.51%. This is comparatively poorer than the 96% which the logistic regression of sklearn achieves! But this is mainly because of the absence of hidden layers which is the real power of neural networks.

4. Neural Network for Logistic Regression -R code (vectorized)

source("RFunctions-1.R")
# Define the sigmoid function
sigmoid <- function(z){
    a <- 1/(1+ exp(-z))
    a
}

# Compute the loss
computeLoss <- function(numTraining,Y,A){
    loss <- -1/numTraining* sum(Y*log(A) + (1-Y)*log(1-A))
    return(loss)
}

# Compute forward propagation
forwardPropagation <- function(w,b,X,Y){
    # Compute Z
    Z <- t(w) %*% X +b
    #Set the number of samples
    numTraining <- ncol(X)
    # Compute the activation function
    A=sigmoid(Z)

    #Compute the loss
    loss <- computeLoss(numTraining,Y,A)

    # Compute the gradients dZ, dw and db
    dZ<-A-Y
    dw<-1/numTraining * X %*% t(dZ)
    db<-1/numTraining*sum(dZ)

    fwdProp <- list("loss" = loss, "dw" = dw, "db" = db)
    return(fwdProp)
}

# Perform one cycle of Gradient descent
gradientDescent <- function(w, b, X, Y, numIerations, learningRate){
    losses <- NULL
    idx <- NULL
    # Loop through the number of iterations
    for(i in 1:numIerations){
        fwdProp <-forwardPropagation(w,b,X,Y)
        #Get the derivatives
        dw <- fwdProp$dw
        db <- fwdProp$db
        #Perform gradient descent
        w = w-learningRate*dw
        b = b-learningRate*db
        l <- fwdProp$loss
        # Stoe the loss
        if(i %% 100 == 0){
            idx <- c(idx,i)
            losses <- c(losses,l)
        }
    }

    # Return the weights and losses
    gradDescnt <- list("w"=w,"b"=b,"dw"=dw,"db"=db,"losses"=losses,"idx"=idx)

    return(gradDescnt)
}

# Compute the predicted value for input
predict <- function(w,b,X){
    m=dim(X)[2]
    # Create a ector of 0's
    yPredicted=matrix(rep(0,m),nrow=1,ncol=m)
    Z <- t(w) %*% X +b
    # Compute sigmoid
    A=sigmoid(Z)
    for(i in 1:dim(A)[2]){
        # If A > 0.5 set value as 1
        if(A[1,i] > 0.5)
        yPredicted[1,i]=1
       else
        # Else set as 0
        yPredicted[1,i]=0
    }

    return(yPredicted)
}

# Normalize the matrix
normalize <- function(x){
    #Create the norm of the matrix.Perform the Frobenius norm of the matrix
    n<-as.matrix(sqrt(rowSums(x^2)))
    #Sweep by rows by norm. Note '1' in the function which performing on every row
    normalized<-sweep(x, 1, n, FUN="/")
    return(normalized)
}

# Run the 2 layer Neural Network on the cancer data set
# Read the data (from sklearn)
cancer <- read.csv("cancer.csv")
# Rename the target variable
names(cancer) <- c(seq(1,30),"output")
# Split as training and test sets
train_idx <- trainTestSplit(cancer,trainPercent=75,seed=5)
train <- cancer[train_idx, ]
test <- cancer[-train_idx, ]

# Set the features
X_train <-train[,1:30]
y_train <- train[,31]
X_test <- test[,1:30]
y_test <- test[,31]
# Create a matrix of 0's with the number of features
w <-matrix(rep(0,dim(X_train)[2]))
b <-0
X_train1 <- normalize(X_train)
X_train2=t(X_train1)

# Reshape  then transpose
y_train1=as.matrix(y_train)
y_train2=t(y_train1)

# Perform gradient descent
gradDescent= gradientDescent(w, b, X_train2, y_train2, numIerations=3000, learningRate=0.77)


# Normalize X_test
X_test1=normalize(X_test)
#Transpose X_train so that we have a matrix as (features, numSamples)
X_test2=t(X_test1)

#Reshape y_test and take transpose
y_test1=as.matrix(y_test)
y_test2=t(y_test1)

# Use the values of the weights generated from Gradient Descent
yPredictionTest = predict(gradDescent$w, gradDescent$b, X_test2)
yPredictionTrain = predict(gradDescent$w, gradDescent$b, X_train2)

sprintf("Train accuracy: %f",(100 - mean(abs(yPredictionTrain - y_train2)) * 100))
## [1] "Train accuracy: 90.845070"
sprintf("test accuracy: %f",(100 - mean(abs(yPredictionTest - y_test)) * 100))
## [1] "test accuracy: 87.323944"
df <-data.frame(gradDescent$idx, gradDescent$losses)
names(df) <- c("iterations","losses")
ggplot(df,aes(x=iterations,y=losses)) + geom_point() + geom_line(col="blue") +
    ggtitle("Gradient Descent - Losses vs No of Iterations") +
    xlab("No of iterations") + ylab("Losses")

4. Neural Network for Logistic Regression -Octave code (vectorized)


1;
# Define sigmoid function
function a = sigmoid(z)
a = 1 ./ (1+ exp(-z));
end
# Compute the loss
function loss=computeLoss(numtraining,Y,A)
loss = -1/numtraining * sum((Y .* log(A)) + (1-Y) .* log(1-A));
end


# Perform forward propagation
function [loss,dw,db,dZ] = forwardPropagation(w,b,X,Y)
% Compute Z
Z = w' * X + b;
numtraining = size(X)(1,2);
# Compute sigmoid
A = sigmoid(Z);


#Compute loss. Note this is element wise product
loss =computeLoss(numtraining,Y,A);
# Compute the gradients dZ, dw and db
dZ = A-Y;
dw = 1/numtraining* X * dZ';
db =1/numtraining*sum(dZ);

end

# Compute Gradient Descent
function [w,b,dw,db,losses,index]=gradientDescent(w, b, X, Y, numIerations, learningRate)
#Initialize losses and idx
losses=[];
index=[];
# Loop through the number of iterations
for i=1:numIerations,
[loss,dw,db,dZ] = forwardPropagation(w,b,X,Y);
# Perform Gradient descent
w = w - learningRate*dw;
b = b - learningRate*db;
if(mod(i,100) ==0)
# Append index and loss
index = [index i];
losses = [losses loss];
endif

end
end

# Determine the predicted value for dataset
function yPredicted = predict(w,b,X)
m = size(X)(1,2);
yPredicted=zeros(1,m);
# Compute Z
Z = w' * X + b;
# Compute sigmoid
A = sigmoid(Z);
for i=1:size(X)(1,2),
# Set predicted as 1 if A > 0,5
if(A(1,i) >= 0.5)
yPredicted(1,i)=1;
else
yPredicted(1,i)=0;
endif
end
end


# Normalize by dividing each value by the sum of squares
function normalized = normalize(x)
# Compute Frobenius norm. Square the elements, sum rows and then find square root
a = sqrt(sum(x .^ 2,2));
# Perform element wise division
normalized = x ./ a;
end


# Split into train and test sets
function [X_train,y_train,X_test,y_test] = trainTestSplit(dataset,trainPercent)
# Create a random index
ix = randperm(length(dataset));
# Split into training
trainSize = floor(trainPercent/100 * length(dataset));
train=dataset(ix(1:trainSize),:);
# And test
test=dataset(ix(trainSize+1:length(dataset)),:);
X_train = train(:,1:30);
y_train = train(:,31);
X_test = test(:,1:30);
y_test = test(:,31);
end


cancer=csvread("cancer.csv");
[X_train,y_train,X_test,y_test] = trainTestSplit(cancer,75);
w=zeros(size(X_train)(1,2),1);
b=0;
X_train1=normalize(X_train);
X_train2=X_train1';
y_train1=y_train';
[w1,b1,dw,db,losses,idx]=gradientDescent(w, b, X_train2, y_train1, numIerations=3000, learningRate=0.75);
# Normalize X_test
X_test1=normalize(X_test);
#Transpose X_train so that we have a matrix as (features, numSamples)
X_test2=X_test1';
y_test1=y_test';
# Use the values of the weights generated from Gradient Descent
yPredictionTest = predict(w1, b1, X_test2);
yPredictionTrain = predict(w1, b1, X_train2);


trainAccuracy=100-mean(abs(yPredictionTrain - y_train1))*100
testAccuracy=100- mean(abs(yPredictionTest - y_test1))*100
trainAccuracy = 90.845
testAccuracy = 89.510
graphics_toolkit('gnuplot')
plot(idx,losses);
title ('Gradient descent- Cost vs No of iterations');
xlabel ("No of iterations");
ylabel ("Cost");

Conclusion
This post starts with a simple 2 layer Neural Network implementation of Logistic Regression. Clearly the performance of this simple Neural Network is comparatively poor to the highly optimized sklearn’s Logistic Regression. This is because the above neural network did not have any hidden layers. Deep Learning & Neural Networks achieve extraordinary performance because of the presence of deep hidden layers

The Deep Learning journey has begun… Don’t miss the bus!
Stay tuned for more interesting posts in Deep Learning!!

References
1. Deep Learning Specialization
2. Neural Networks for Machine Learning
3. Deep Learning, Ian Goodfellow, Yoshua Bengio and Aaron Courville
4. Neural Networks: The mechanics of backpropagation
5. Machine Learning

Also see
1. My book ‘Practical Machine Learning with R and Python’ on Amazon
2. Simplifying Machine Learning: Bias, Variance, regularization and odd facts – Part 4
3. The 3rd paperback & kindle editions of my books on Cricket, now on Amazon
4. Practical Machine Learning with R and Python – Part 4
5. Introducing QCSimulator: A 5-qubit quantum computing simulator in R
6. A Bluemix recipe with MongoDB and Node.js
7. My travels through the realms of Data Science, Machine Learning, Deep Learning and (AI)

To see all posts check Index of posts

The 3rd paperback & kindle editions of my books on Cricket, now on Amazon


The 3rd  paperback & kindle edition of both my books on cricket is now available on Amazon

a) Cricket analytics with cricketr, Third Edition. The paperback edition is $12.99 and the kindle edition is $4.99/Rs320.  This book is based on my R package ‘cricketr‘, available on CRAN and uses ESPN Cricinfo Statsguru

b) Beaten by sheer pace! Cricket analytics with yorkr, 3rd edition . The paperback is $12.99 and the kindle version is $6.99/Rs448. This is based on my R package ‘yorkr‘ on CRAN and uses data from Cricsheet
Pick up your copies today!!

Note: In the 3rd edition of  the paperback book, the charts will be in black and white. If you would like the charts to be in color, please check out the 2nd edition of these books see More book, more cricket! 2nd edition of my books now on Amazon

You may also like
1. My book ‘Practical Machine Learning with R and Python’ on Amazon
2. A crime map of India in R: Crimes against women
3.  What’s up Watson? Using IBM Watson’s QAAPI with Bluemix, NodeExpress – Part 1
4.  Bend it like Bluemix, MongoDB with autoscaling – Part 2
5. Informed choices through Machine Learning : Analyzing Kohli, Tendulkar and Dravid
6. Thinking Web Scale (TWS-3): Map-Reduce – Bring compute to data

To see all posts see Index of posts

My book ‘Practical Machine Learning with R and Python’ on Amazon


Note: The 3rd edition of this book is now available My book ‘Practical Machine Learning in R and Python: Third edition’ on Amazon

My book ‘Practical Machine Learning with R and Python: Second Edition – Machine Learning in stereo’ is now available in both paperback ($10.99) and kindle ($7.99/Rs449) versions. In this book I implement some of the most common, but important Machine Learning algorithms in R and equivalent Python code. This is almost like listening to parallel channels of music in stereo!
1. Practical machine with R and Python: Third Edition – Machine Learning in Stereo(Paperback-$12.99)
2. Practical machine with R and Python Third Edition – Machine Learning in Stereo(Kindle- $8.99/Rs449)
This book is ideal both for beginners and the experts in R and/or Python. Those starting their journey into datascience and ML will find the first 3 chapters useful, as they touch upon the most important programming constructs in R and Python and also deal with equivalent statements in R and Python. Those who are expert in either of the languages, R or Python, will find the equivalent code ideal for brushing up on the other language. And finally,those who are proficient in both languages, can use the R and Python implementations to internalize the ML algorithms better.

Here is a look at the topics covered

Table of Contents
Essential R …………………………………….. 7
Essential Python for Datascience ………………..   54
R vs Python ……………………………………. 77
Regression of a continuous variable ………………. 96
Classification and Cross Validation ……………….113
Regression techniques and regularization …………. 134
SVMs, Decision Trees and Validation curves …………175
Splines, GAMs, Random Forests and Boosting …………202
PCA, K-Means and Hierarchical Clustering …………. 234

Pick up your copy today!!
Hope you have a great time learning as I did while implementing these algorithms!
